Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 14.1 MB | Download |
| Print-ready chart, no georeferencing | 29.2 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 29.2 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROKiska, Amchitka and the island arc east towards Atka put this sheet astride the International Date Line in the western Aleutians. Its coverage follows a narrow band of the chain, from waters west of Kiska across the Rat Islands and onwards through the central Aleutian islands. The Bering Sea lies to the north and the North Pacific to the south, with the islands forming a broken boundary between them.
The sheet is defined as much by ocean as by land. Steep volcanic islands, ridged interiors, deeply cut shores and small outlying rocks create a fragmented landscape, while substantial stretches of open water separate the main island groups. Elongated coastlines and isolated landforms recur across an otherwise maritime field. It has no adjoining chart of the same type, so its western Aleutian coverage stands alone rather than continuing directly onto another sectional sheet.
It spans 50.8°N to 53.3°N and 177.2°W to 172.4°W. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (14.1 MB). Take the PDF to print it or read it on a second screen (29.2 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
