PATUXENT RIVER, MD · 18 FAA charts · cycle 6 Aug 2026
13 published instrument approaches: 1 ILS approach, 4 RNAV (GPS), serving 4 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | SWABY ONE (OBSTACLE) | — | |
 | SWABY ONE (OBSTACLE), CONT.1 | — |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | RADAR MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| Tower | 123.7 | Patuxent |
| Ground | 120.6 | Patuxent |
| Clearance delivery | 135.2 | Patuxent |
| Approach | 120.05165-055 Abv 3000 Ft121.0165-055 3000 Ft & Blw127.95056-164 All Alts135.625When Nhk Apch Clsd | Patuxent |
| Emergency | 121.5 | Patuxent |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 06/24 | 11,799 ft | 200 ft | Asphalt Good | High intensity |
| 06 49°T | ILS/DME · ALSF-1 approach lighting | |||
| 14/32 | 9,732 ft | 200 ft | Asphalt Good | High intensity |
| 02/20 | 5,021 ft | 75 ft | Asphalt Good | |
Runway and approach-aid data from the FAA NASR 28-day subscription.
38.2863340, -76.4099710
38 ftPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Patuxent River combines three runway alignments with instrument approaches serving four of the six runway ends. The 13 approach charts include ILS, localiser and RNAV (GPS) procedures, giving both precision and non-precision coverage, while two ends have no published approach. Runways 06/24 and 14/32 provide substantially more available distance than the 5,021 ft runway 02/20, so the configuration offers both differing alignments and markedly different runway lengths.
Nearby procedure coverage is much thinner: Cambridge-Dorchester Regional and Tappahannock/Essex County have the broadest nearby sets at four charts each, while Crisfield-Somerset County has only two. The Washington Sectional adds wider-area VFR context, while the Baltimore-Washington Terminal Area Chart supplies a more detailed VFR depiction around the airport.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| 2W6 | St Mary'S County Rgnl | LEONARDTOWN, MD | 7 nm W | 3 |
| KCGE | Cambridge-Dorchester Rgnl | CAMBRIDGE, MD | 23 nm NE | 4 |
| W41 | Crisfield-Somerset County | CRISFIELD, MD | 32 nm SE | 2 |
| KTGI | Tangier Island | TANGIER, VA | 34 nm SE | 3 |
| KXSA | Tappahannock/Essex County | TAPPAHANNOCK, VA | 34 nm SW | 4 |
| KESN | Easton/Newnam Fld | EASTON, MD | 35 nm NE | 14 |
| 2W5 | Maryland | INDIAN HEAD, MD | 36 nm NW | 3 |
| KVKX | Potomac Airfield | FRIENDLY, MD | 38 nm NW | 3 |
18 current FAA charts for Patuxent River NAS (Trapnell Fld), including 13 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 123.7; Ground 120.6; Clearance delivery 135.2. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Patuxent River NAS (Trapnell Fld) has 3 runways. The longest is 06/24 at 11,799 ft by 200 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 1 ILS procedure is published. In total KNHK has 13 published instrument approaches, of which 4 are RNAV (GPS).
The official FAA airport diagram for Patuxent River NAS (Trapnell Fld) is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. Patuxent River NAS (Trapnell Fld) has an operating control tower, within Washington Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
