VAN WERT, OH · 4 FAA charts · cycle 6 Aug 2026
2 published instrument approaches: 2 RNAV (GPS), serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | RNAV (GPS) RWY 09 | 1 | |
 | RNAV (GPS) RWY 27 | 0A |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 123.0 | |
| Approach | 127.2Sw/Nw Of Active Rwy132.15Se/Ne Of Active Rwy | Fort Wayne |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 09/27 | 5,005 ft | 75 ft | Asphalt Good | Medium intensity |
| 09 90°T | PAPI (4-box) 3° | |||
| 27 270°T | PAPI (4-box) 3.5° | |||
| 18/36 | 2,558 ft | 95 ft | Grass Good | |
| 18 179°T | displaced threshold 339 ft | |||
| 36 359°T | displaced threshold 692 ft | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
40.8639410, -84.6079720
786 ft1 nm WSWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Van Wert County’s two RNAV (GPS) approaches serve two runway ends, giving the instrument set balanced arrival coverage rather than concentrating procedures on a single direction. No airport diagram is published, so the collection is limited to approach and minima material rather than ground-layout guidance.
The 5,005 ft asphalt runway provides nearly twice the available length of the 2,558 ft turf runway, making the latter a distinctly shorter second alignment rather than an equivalent parallel choice. Among nearby fields, Fort Wayne International has much broader procedure coverage with 14 charts; Lima Allen County is only slightly broader with five, while Lakefield, Neil Armstrong and Defiance Memorial each have thinner three-chart sets. The Detroit Sectional adds the wider visual-navigation context not supplied by the instrument procedures.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KCQA | Lakefield | CELINA, OH | 23 nm S | 3 |
| KAXV | Neil Armstrong | WAPAKONETA, OH | 26 nm SE | 3 |
| KFWA | Fort Wayne Intl | FORT WAYNE, IN | 28 nm W | 14 |
| KAOH | Lima Allen County | LIMA, OH | 28 nm E | 5 |
| KDFI | Defiance Meml | DEFIANCE, OH | 30 nm N | 3 |
| KSMD | Smith Fld | FORT WAYNE, IN | 30 nm NW | 5 |
| KOWX | Putnam County | OTTAWA, OH | 30 nm E | 3 |
| KPLD | Portland Muni | PORTLAND, IN | 30 nm SW | 4 |
4 current FAA charts for Van Wert County, including 2 instrument approachs. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
CTAF 123.0. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Van Wert County has 2 runways. The longest is 09/27 at 5,005 ft by 75 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
No ILS is published. In total KVNW has 2 published instrument approaches, of which 2 are RNAV (GPS).
No — Van Wert County has no control tower. Traffic co-ordinates on a common frequency rather than with a controller, which is listed in the frequencies table on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
