KNOXVILLE, TN · 21 FAA charts · cycle 6 Aug 2026
16 published instrument approaches: 8 ILS approaches including CAT II/III minima, 4 RNAV (GPS), 4 VOR, serving 4 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | KNOXVILLE SEVEN | — |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| UNICOM | 122.95 | |
| Tower | 121.2 | Knoxville |
| Ground | 121.9 | Knoxville |
| Clearance delivery | 121.65 | Knoxville |
| ATIS | 128.35 | Knoxville |
| Approach | 118.0051-229123.9230-050125.525 | Knoxville |
| Emergency | 121.5 | Knoxville |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 05L/23R | 10,000 ft | 150 ft | Concrete Good | High intensity |
| 05L 45°T | ILS · PAPI (4-box) 3° · MALSR approach lighting · displaced threshold 490 ft | |||
| 23R 225°T | ILS · PAPI (4-box) 3° · ALSF-2 approach lighting · displaced threshold 505 ft · right-hand circuit | |||
| 05R/23L | 9,000 ft | 150 ft | Asphalt Poor | High intensity |
| 05R 45°T | PAPI (4-box) 3° · right-hand circuit | |||
| 23L 225°T | ILS/DME · PAPI (4-box) 3° · displaced threshold 397 ft | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
35.8110910, -83.9940670
986 ft10 nm SPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Sixteen instrument approach procedures serve all four ends of Mc Ghee Tyson’s two parallel runways. The mix of ILS, RNAV (GPS), VOR and localiser procedures provides more than one form of guidance, while one ILS includes CAT II/III minima. With only one published departure procedure, the chart set is weighted strongly towards arrivals. The parallel layout provides two 9,000-ft-plus runway options on the same alignment, rather than a second crossing direction.
Nearby procedure coverage is much thinner. Knoxville Downtown Island and Rockwood Municipal have the broadest nearby sets at five charts each, while Colonel Tommy C Stiner Airfield has only two. The Atlanta, Cincinnati and St Louis sectional charts add broad-area VFR context beyond the airport diagram and terminal procedures.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KDKX | Knoxville Downtown Island | KNOXVILLE, TN | 11 nm NE | 5 |
| KGKT | Gatlinburg-Pigeon Forge | SEVIERVILLE, TN | 23 nm E | 4 |
| KMNV | Monroe County | MADISONVILLE, TN | 25 nm SW | 4 |
| KJAU | Colonel Tommy C Stiner Airfield | JACKSBORO, TN | 32 nm N | 2 |
| KRKW | Rockwood Muni | ROCKWOOD, TN | 35 nm W | 5 |
| KMMI | Mcminn County | ATHENS, TN | 37 nm SW | 4 |
| KMOR | Moore-Murrell | MORRISTOWN, TN | 37 nm NE | 4 |
| KRHP | Western Carolina Rgnl | ANDREWS, NC | 38 nm S | 2 |
21 current FAA charts for Mc Ghee Tyson, including 16 instrument approachs, 1 departure procedure, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 121.2; Ground 121.9; ATIS 128.35; UNICOM 122.95; Clearance delivery 121.65. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Mc Ghee Tyson has 2 runways. The longest is 05L/23R at 10,000 ft by 150 ft, concrete. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 8 ILS procedures are published, including CAT II/III minima. In total KTYS has 16 published instrument approaches, of which 4 are RNAV (GPS).
The official FAA airport diagram for Mc Ghee Tyson is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. 1 of the published ILS procedures carry CAT II/III minima, which allow approaches in lower visibility than a standard CAT I ILS. Those plates are listed separately in the approach table above, marked CAT II or CAT III in the chart name.
Yes. Mc Ghee Tyson has an operating control tower, within Atlanta Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
