ALBUQUERQUE, NM · 42 FAA charts · cycle 6 Aug 2026
13 published instrument approaches: 3 ILS approaches, 8 RNAV (GPS), 1 VOR, serving 4 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — | |
 | RADAR MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| UNICOM | 122.95 | |
| Tower | 120.3123.775 | Albuquerque |
| Ground | 121.9 | Albuquerque |
| Clearance delivery | 119.2 | Albuquerque |
| ATIS | 118.0 | Albuquerque |
| Approach | 123.9South Of V12126.3127.4On Or North Of V12 | Albuquerque |
| Emergency | 121.5 | Albuquerque |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 08/26 | 13,793 ft | 150 ft | Concrete Good | High intensity |
| 08 90°T | ILS/DME · VASI (6-bar) 2.95° · MALSR approach lighting · displaced threshold 1,000 ft · right-hand circuit | |||
| 26 270°T | PAPI (4-box) 3° | |||
| 03/21 | 10,000 ft | 150 ft | Concrete Good | High intensity |
| 03 45°T | ILS · PAPI (4-box) 3° · MALSR approach lighting · right-hand circuit | |||
| 21 225°T | PAPI (4-box) 3° | |||
| 12/30 | 6,000 ft | 150 ft | Concrete Good | Medium intensity |
| 12 129°T | right-hand circuit | |||
| 30 309°T | PAPI (4-box) 3° | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
35.0389320, -106.6082620
5,354 ft3 nm SEPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Albuquerque’s three-runway layout offers markedly different available lengths, from 6,000 ft to 13,793 ft, allowing traffic to be planned around more than one runway scale and alignment. Instrument coverage is selective: four of the six runway ends are served. The published mix combines ILS and localiser procedures with a larger group of RNAV (GPS) approaches, plus one VOR option, providing both precision and satellite-based coverage rather than relying on a single procedure type.
Among nearby fields, Santa Fe Regional has the broadest procedure set, followed by Double Eagle II; Belen Regional, Moriarty Municipal and Los Alamos have much thinner coverage. The Albuquerque Sectional adds the wider visual chart context not shown by airport-specific terminal procedures.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KAEG | Double Eagle II | ALBUQUERQUE, NM | 11 nm NW | 10 |
| KBRG | Belen Rgnl | BELEN, NM | 26 nm SW | 2 |
| 0E0 | Moriarty Muni | MORIARTY, NM | 30 nm E | 3 |
| KSAF | Santa Fe Rgnl | SANTA FE, NM | 43 nm NE | 14 |
| KLAM | Los Alamos | LOS ALAMOS, NM | 53 nm N | 4 |
42 current FAA charts for Albuquerque Intl Sunport, including 13 instrument approachs, 12 departure procedures, 12 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 120.3, 123.775; Ground 121.9; ATIS 118.0; UNICOM 122.95; Clearance delivery 119.2. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Albuquerque Intl Sunport has 3 runways. The longest is 08/26 at 13,793 ft by 150 ft, concrete. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 3 ILS procedures are published. In total KABQ has 13 published instrument approaches, of which 8 are RNAV (GPS).
The official FAA airport diagram for Albuquerque Intl Sunport is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
The field elevation is 5,354 ft. At that height the air is thin enough to matter: take-off and landing distances are longer than the same aircraft would need at sea level, and the effect worsens as temperature rises. The approach charts carry the altitudes that apply.
Yes. Albuquerque Intl Sunport has an operating control tower, within Albuquerque Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
