GREAT BEND, KS · 6 FAA charts · cycle 6 Aug 2026
3 published instrument approaches: 1 ILS approach, 2 RNAV (GPS), serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | ILS OR LOC RWY 35 | 0E | |
 | RNAV (GPS) RWY 17 | 0C | |
 | RNAV (GPS) RWY 35 | 0B |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 122.8 |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 17/35 | 7,852 ft | 100 ft | Concrete Fair | Medium intensity |
| 17 180°T | PAPI (4-box) 3.5° | |||
| 35 360°T | ILS/DME · VASI (4-bar) 3° · MALSR approach lighting | |||
| 11/29 | 4,706 ft | 75 ft | Asphalt Fair | Medium intensity |
| 11 120°T | PAPI (4-box) 3° | |||
| 29 300°T | PAPI (4-box) 3° | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
38.3442510, -98.8591970
1,886 ft4 nm WPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Great Bend’s three approach plates serve two runway ends, combining GPS procedures with ILS and localiser capability. The result is instrument coverage on only part of the four-end runway configuration rather than on every possible alignment. Runway 17/35 is 3,146 ft longer than 11/29, so it provides the field’s principal length advantage for aircraft requiring more than 4,706 ft.
Among nearby fields, Hays Regional has a substantially broader chart set. Lyons-Rice County Municipal and Russell Municipal are closest to Great Bend in overall coverage, while Larned-Pawnee County and Ellsworth Municipal have thinner sets. The Wichita Sectional adds wider-area VFR context beyond the airport diagram and terminal procedures.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KLQR | Larned-Pawnee County | LARNED, KS | 13 nm SW | 4 |
| KLYO | Lyons-Rice County Muni | LYONS, KS | 30 nm E | 5 |
| KRSL | Russell Muni | RUSSELL, KS | 32 nm N | 5 |
| KHYS | Hays Rgnl | HAYS, KS | 36 nm NW | 12 |
| 9K7 | Ellsworth Muni | ELLSWORTH, KS | 38 nm NE | 4 |
| KPTT | Pratt Rgnl | PRATT, KS | 39 nm S | 3 |
| KHUT | Hutchinson Rgnl | HUTCHINSON, KS | 50 nm E | 14 |
| 48K | Ness City Muni | NESS CITY, KS | 50 nm W | 3 |
6 current FAA charts for Great Bend Muni, including 3 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
CTAF 122.8. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Great Bend Muni has 2 runways. The longest is 17/35 at 7,852 ft by 100 ft, concrete. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 1 ILS procedure is published. In total KGBD has 3 published instrument approaches, of which 2 are RNAV (GPS).
The official FAA airport diagram for Great Bend Muni is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
No — Great Bend Muni has no control tower. Traffic co-ordinates on a common frequency rather than with a controller, which is listed in the frequencies table on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
