COLUMBUS, OH · 17 FAA charts · cycle 6 Aug 2026
3 published instrument approaches: 1 ILS approach, 2 RNAV (GPS), serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | ILS OR LOC RWY 09R | 5D | |
 | RNAV (GPS) RWY 09R | 1C | |
 | RNAV (GPS) RWY 27L | 0C |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 118.8 | |
| UNICOM | 122.95 | |
| Ground | 121.7 | State |
| ATIS | 121.35 | State |
| Approach | 125.95 | State |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 09R/27L | 5,004 ft | 100 ft | Asphalt Good | High intensity |
| 09R 87°T | ILS · PAPI (4-box) 3° · MALSR approach lighting | |||
| 27L 267°T | PAPI (4-box) 3° | |||
| 05/23 | 3,562 ft | 100 ft | Asphalt Good | |
| 09L/27R | 2,994 ft | 100 ft | Asphalt Fair | Medium intensity |
| 09L 87°T | VASI (2-bar) 3° | |||
| 27R 267°T | VASI (2-bar) 3° | |||
| H1 | 40 ft | 40 ft | Asphalt Good | |
Runway and approach-aid data from the FAA NASR 28-day subscription.
40.0795160, -83.0732130
905 ft10 nm NWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Only two runway ends receive instrument approach coverage, despite three paved runways. The set combines ILS, localiser and RNAV (GPS) options, providing both ground-based and satellite-based procedures but concentrating them on a small part of the runway layout. At 5,004 ft, 09R/27L is the clear length option; 05/23 is shorter at 3,562 ft, while parallel 09L/27R remains below 3,000 ft.
Nearby, John Glenn Columbus International and Rickenbacker International have broader chart sets, Bolton Field is closest in overall coverage, and Delaware Municipal/Jim Moore Field and Union County are much thinner. The Cincinnati and Detroit sectionals add broad-area VFR context beyond the airport diagram and terminal procedures.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KCMH | John Glenn Columbus Intl | COLUMBUS, OH | 10 nm SE | 27 |
| KTZR | Bolton Fld | COLUMBUS, OH | 11 nm S | 14 |
| KDLZ | Delaware Muni/Jim Moore Fld | DELAWARE, OH | 12 nm N | 5 |
| KMRT | Union County | MARYSVILLE, OH | 15 nm NW | 4 |
| KLCK | Rickenbacker Intl | COLUMBUS, OH | 17 nm SE | 21 |
| KUYF | Madison County | LONDON, OH | 20 nm SW | 4 |
| KLHQ | Fairfield County | LANCASTER, OH | 27 nm SE | 5 |
| KVTA | Licking County Rgnl | NEWARK, OH | 28 nm E | 6 |
17 current FAA charts for Ohio State University, including 3 instrument approachs, 10 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Ground 121.7; ATIS 121.35; CTAF 118.8; UNICOM 122.95. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Ohio State University has 4 runways. The longest is 09R/27L at 5,004 ft by 100 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 1 ILS procedure is published. In total KOSU has 3 published instrument approaches, of which 2 are RNAV (GPS).
The official FAA airport diagram for Ohio State University is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. Ohio State University has an operating control tower, within Indianapolis Center's airspace. Tower, ground and clearance frequencies are listed on this page.
4, which is why the chart set is as large as it is — each runway end that supports an instrument approach needs its own plates. The runway diagram on this page shows the layout to scale.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
