MADISON, WI · 2 FAA charts · cycle 6 Aug 2026
1 published instrument approach: 1 VOR.
| Chart | Amendment | ||
|---|---|---|---|
 | VOR OR GPS-A | 0F |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 122.7 | |
| Approach | 120.1 | Madison |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 04/22 | 2,814 ft | 57 ft | Asphalt Poor | |
| 04 40°T | right-hand circuit | |||
| 22 220°T | displaced threshold 260 ft | |||
| 09/27 | 2,150 ft | 56 ft | Asphalt Fair | Non-standard |
| 27 270°T | displaced threshold 180 ft · right-hand circuit | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
43.1047040, -89.1854280
920 ft10 nm EPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Blackhawk’s instrument provision is concentrated in a single VOR approach, with no separate airport diagram. This provides one published instrument arrival method rather than a choice of procedure types. Both runways are shorter than 3,000 ft, narrowing the range of aircraft that can realistically use the field.
