TULLAHOMA, TN · 3 FAA charts · cycle 6 Aug 2026
2 published instrument approaches: 2 RNAV (GPS), serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | RNAV (GPS) RWY 03 | — | |
 | RNAV (GPS) RWY 21 | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 126.2 |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 03/21 | 6,000 ft | 150 ft | Asphalt Excellent | High intensity |
Runway and approach-aid data from the FAA NASR 28-day subscription.
35.3924650, -86.0857770
1,065 ftPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Arnold AFB’s instrument set is compact but balanced: its two RNAV (GPS) approaches serve both ends of runway 03/21, so coverage is not concentrated on a single direction. There is no second runway alignment; the 6,000 ft runway is the sole strip, while the published airport diagram supplies ground-layout detail alongside the two procedures.
Every listed nearby field has a larger procedure set than AYX. KSYI is the clear outlier for breadth, with 13 charts; KTHA has six, KBGF and KFYM five each, and KRNC four, making the latter group much closer to AYX’s limited coverage. The Atlanta Sectional adds the wider visual-navigation setting around Tullahoma that the airport diagram and runway-specific instrument procedures do not provide.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KTHA | Tullahoma Rgnl/Wm Northern Fld | TULLAHOMA, TN | 8 nm W | 6 |
| KBGF | Winchester Muni | WINCHESTER, TN | 13 nm S | 5 |
| KSYI | Bomar Fld/Shelbyville Muni | SHELBYVILLE, TN | 20 nm NW | 13 |
| KRNC | Warren County Meml | MC MINNVILLE, TN | 22 nm NE | 4 |
| KFYM | Fayetteville Muni | FAYETTEVILLE, TN | 31 nm SW | 5 |
| KAPT | Marion County/Brown Fld | JASPER, TN | 32 nm SE | 2 |
| KMBT | Murfreesboro Muni | MURFREESBORO, TN | 32 nm NW | 9 |
| KLUG | Ellington | LEWISBURG, TN | 36 nm W | 5 |
3 current FAA charts for Arnold AFB, including 2 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
CTAF 126.2. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Arnold AFB has 1 runway. The longest is 03/21 at 6,000 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
No ILS is published. In total KAYX has 2 published instrument approaches, of which 2 are RNAV (GPS).
The official FAA airport diagram for Arnold AFB is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
No — Arnold AFB has no control tower. Traffic co-ordinates on a common frequency rather than with a controller, which is listed in the frequencies table on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
