BOSSIER CITY, LA · 14 FAA charts · cycle 6 Aug 2026
12 published instrument approaches: 6 ILS approaches, 2 VOR, serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | RADAR MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| Tower | 128.25 | Barksdale |
| Ground | 121.8 | Barksdale |
| Approach | 119.9153-319123.75320-152 | Barksdale |
| Emergency | 121.5 | Barksdale |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 15/33 | 11,758 ft | 299 ft | Porous asphalt | High intensity |
| 15 151°T | ILS · PAPI (4-box) 2.5° · ALSF-1 approach lighting | |||
| 33 331°T | ILS · PAPI (4-box) 2.5° · ALSF-1 approach lighting | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
32.5019330, -93.6626280
165 ft3 nm EPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Barksdale AFB’s procedure set is concentrated on both ends of its sole runway. Twelve approach plates provide ILS, localiser and VOR options, with Runway 15 and Runway 33 each served rather than one direction lacking a published approach. Six ILS and six localiser entries make those procedure types the core of the set, while two VOR approaches add another form of guidance. The 11,758 ft runway provides substantial available distance, but there is no second runway alignment.
Shreveport Regional, with 12 published charts, has the nearest comparably broad procedure set. Shreveport Downtown’s eight charts form a smaller collection, while Minden and the two more distant listed fields have markedly thinner coverage. The Memphis Sectional adds the broader visual-navigation context that airport-specific terminal procedures do not provide.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KDTN | Shreveport Downtown | SHREVEPORT, LA | 5 nm NW | 8 |
| KSHV | Shreveport Rgnl | SHREVEPORT, LA | 9 nm W | 12 |
| KMNE | Minden | MINDEN, LA | 20 nm NE | 5 |
| 3F3 | C E 'Rusty' Williams | MANSFIELD, LA | 26 nm S | 3 |
| 3F4 | Vivian | VIVIAN, LA | 28 nm NW | 3 |
| KSPH | Springhill | SPRINGHILL, LA | 32 nm NE | 3 |
| KASL | Harrison County | MARSHALL, TX | 33 nm W | 3 |
| 0R7 | The Red River | COUSHATTA, LA | 36 nm SE | 2 |
14 current FAA charts for Barksdale AFB, including 12 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 128.25; Ground 121.8. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Barksdale AFB has 1 runway. The longest is 15/33 at 11,758 ft by 299 ft, porous asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 6 ILS procedures are published. In total KBAD has 12 published instrument approaches.
The official FAA airport diagram for Barksdale AFB is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. Barksdale AFB has an operating control tower, within Fort Worth Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
