BIRMINGHAM, AL · 18 FAA charts · cycle 6 Aug 2026
11 published instrument approaches: 4 ILS approaches including CAT II/III minima, 6 RNAV (GPS), serving 4 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | BIRMINGHAM EIGHT | — | |
 | BIRMINGHAM EIGHT, CONT.1 | — |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
| Chart | Amendment | ||
|---|---|---|---|
 | LAHSO | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| UNICOM | 122.95 | |
| Tower | 118.25119.9 | Birmingham |
| Ground | 121.7 | Birmingham |
| Clearance delivery | 125.675 | Birmingham |
| ATIS | 119.4 | Birmingham |
| Approach | 123.8050-230127.675231-049 | Birmingham |
| Emergency | 121.5 | Birmingham |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 06/24 | 12,007 ft | 150 ft | Asphalt Good | High intensity |
| 06 55°T | ILS · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 24 235°T | ILS/DME · PAPI (4-box) 3° · MALSR approach lighting · displaced threshold 1,205 ft | |||
| 18/36 | 7,099 ft | 150 ft | Asphalt Good | Medium intensity |
| 18 180°T | LOC/DME · PAPI (4-box) 3.2° | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
33.5638890, -86.7523060
650 ft4 nm NEPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Birmingham-Shuttlesworth’s procedure set serves all four runway ends rather than concentrating instrument access on one alignment. The mix of ILS, RNAV (GPS) and localiser procedures provides both satellite-based and ground-based options; two ILS procedures also publish CAT II/III minima. The crossed runways differ sharply in length: 06/24 extends to 12,007 ft, while 18/36 provides 7,099 ft, so available runway distance changes substantially between alignments.
Nearby procedure coverage is much thinner. Bessemer NTL has the broadest neighbouring set with five charts, while each other listed field has only three or four, against Birmingham-Shuttlesworth’s 18. The Atlanta Sectional adds the wider visual-navigation context around Birmingham, complementing the airport-specific diagram, departures and approaches.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KEKY | Bessemer Ntl | BESSEMER, AL | 17 nm SW | 5 |
| KEET | Shelby County | ALABASTER, AL | 23 nm S | 4 |
| KPLR | St Clair County | PELL CITY, AL | 25 nm E | 4 |
| 20A | Robbins Fld | ONEONTA, AL | 31 nm NE | 3 |
| KSCD | Merkel Fld Sylacauga Muni | SYLACAUGA, AL | 32 nm SE | 4 |
| KJFX | Walker County/Bevill Fld | JASPER, AL | 35 nm NW | 6 |
| KASN | Talladega Muni | TALLADEGA, AL | 35 nm E | 6 |
| KGAD | Northeast Alabama Rgnl | GADSDEN, AL | 41 nm NE | 7 |
18 current FAA charts for Birmingham-Shuttlesworth Intl, including 11 instrument approachs, 2 departure procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 118.25, 119.9; Ground 121.7; ATIS 119.4; UNICOM 122.95; Clearance delivery 125.675. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Birmingham-Shuttlesworth Intl has 2 runways. The longest is 06/24 at 12,007 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 4 ILS procedures are published, including CAT II/III minima. In total KBHM has 11 published instrument approaches, of which 6 are RNAV (GPS).
The official FAA airport diagram for Birmingham-Shuttlesworth Intl is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. 2 of the published ILS procedures carry CAT II/III minima, which allow approaches in lower visibility than a standard CAT I ILS. Those plates are listed separately in the approach table above, marked CAT II or CAT III in the chart name.
Yes. Birmingham-Shuttlesworth Intl has an operating control tower, within Atlanta Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
