MERCED, CA · 5 FAA charts · cycle 6 Aug 2026
4 published instrument approaches: 1 ILS approach, 2 RNAV (GPS), serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | ILS OR LOC RWY 30 | 15 | |
 | LOC BC RWY 12 | 11 | |
 | RNAV (GPS) RWY 12 | 1 | |
 | RNAV (GPS) RWY 30 | 1 |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 122.7 | |
| Approach | 120.95 | Norcal |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 12/30 | 5,914 ft | 150 ft | Asphalt Good | High intensity |
| 12 138°T | VASI (4-bar) 3° · right-hand circuit | |||
| 30 318°T | ILS/DME · PAPI (4-box) 3° · MALSR approach lighting | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
37.2847500, -120.5139170
155 ft2 nm SWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Merced Yosemite Regional’s four approach plates serve both ends of its sole 5,914 ft runway, so the procedure set does not favour one direction. The mix includes ILS, RNAV (GPS) and localiser options, providing both satellite-based and ground-based approach coverage. With no airport diagram published, the cycle is compact: approach plates and the minima publication comprise the entire set.
Castle has the broadest nearby procedure set, exceeding Merced’s coverage, while Madera Municipal has a comparably sized collection. Los Banos Municipal is thinner, and Turlock Municipal and Firebaugh each have only two charts. The San Francisco Sectional adds wider visual aviation context beyond the airport-specific instrument procedures.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KMER | Castle | ATWATER, CA | 6 nm NW | 7 |
| O15 | Turlock Muni | TURLOCK, CA | 15 nm NW | 2 |
| KLSN | Los Banos Muni | LOS BANOS, CA | 22 nm SW | 3 |
| F34 | Firebaugh | FIREBAUGH, CA | 26 nm S | 2 |
| KMAE | Madera Muni | MADERA, CA | 26 nm SE | 4 |
| KMPI | Mariposa-Yosemite | MARIPOSA, CA | 26 nm NE | 4 |
| KMOD | Modesto City-County-Harry Sham Fld | MODESTO, CA | 29 nm NW | 5 |
| O27 | Oakdale | OAKDALE, CA | 31 nm NW | 3 |
5 current FAA charts for Merced Yosemite Rgnl, including 4 instrument approachs. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
CTAF 122.7. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Merced Yosemite Rgnl has 1 runway. The longest is 12/30 at 5,914 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 1 ILS procedure is published. In total KMCE has 4 published instrument approaches, of which 2 are RNAV (GPS).
No — Merced Yosemite Rgnl has no control tower. Traffic co-ordinates on a common frequency rather than with a controller, which is listed in the frequencies table on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
