MODESTO, CA · 5 FAA charts · cycle 6 Aug 2026
2 published instrument approaches: 1 ILS approach, 1 RNAV (GPS).
| Chart | Amendment | ||
|---|---|---|---|
 | ILS OR LOC RWY 28R | 16 | |
 | RNAV (GPS) RWY 28R | 2 |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 125.3 | |
| UNICOM | 122.95 | |
| Ground | 121.7 | Modesto |
| ATIS | 127.7 | Modesto |
| Approach | 120.95 | Modesto |
| Departure | 123.85West125.1North | Modesto |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 10L/28R | 5,904 ft | 150 ft | Asphalt Good | High intensity |
| 10L 124°T | PAPI (4-box) 3° | |||
| 28R 304°T | ILS · MALSR approach lighting · right-hand circuit | |||
| 10R/28L | 3,464 ft | 100 ft | Asphalt Good | Medium intensity |
| 10R 124°T | PAPI (2-box) 3.5° · right-hand circuit | |||
| 28L 304°T | PAPI (2-box) 3° | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
37.6258250, -120.9544300
99 ft2 nm SEPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Modesto’s two approach plates concentrate ILS/localiser and RNAV (GPS) procedures on a single runway end. The other three ends have no published approach, so the instrument coverage is directional rather than distributed across the parallel runways. The airport diagram is particularly useful for distinguishing the two similarly aligned strips.
Runway 10L/28R provides 2,440 ft more length than its parallel, making the two runways materially different when matching available length to an aircraft. Nearby chart coverage is broadest at Stockton Metro, with Tracy Municipal and Castle close behind; Oakdale and especially Turlock Municipal have much thinner procedure sets. The San Francisco Sectional adds regional visual-navigation context that the airport diagram and instrument procedures do not provide.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| O27 | Oakdale | OAKDALE, CA | 11 nm NE | 3 |
| O15 | Turlock Muni | TURLOCK, CA | 15 nm SE | 2 |
| KSCK | Stockton Metro | STOCKTON, CA | 21 nm NW | 8 |
| KTCY | Tracy Muni | TRACY, CA | 23 nm W | 7 |
| KMER | Castle | ATWATER, CA | 24 nm SE | 7 |
| KMCE | Merced Yosemite Rgnl | MERCED, CA | 29 nm SE | 5 |
| KLSN | Los Banos Muni | LOS BANOS, CA | 34 nm S | 3 |
| C83 | Byron | BYRON, CA | 34 nm W | 3 |
5 current FAA charts for Modesto City-County-Harry Sham Fld, including 2 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Ground 121.7; ATIS 127.7; CTAF 125.3; UNICOM 122.95. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Modesto City-County-Harry Sham Fld has 2 runways. The longest is 10L/28R at 5,904 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 1 ILS procedure is published. In total KMOD has 2 published instrument approaches, of which 1 are RNAV (GPS).
The official FAA airport diagram for Modesto City-County-Harry Sham Fld is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Every published approach serves one runway end. There is no instrument procedure to the reciprocal direction, so an arrival in instrument conditions commits to that single approach direction regardless of the wind.
Yes. Modesto City-County-Harry Sham Fld has an operating control tower, within Oakland Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
