Terminal Procedures

KRDR — Grand Forks AFB

GRAND FORKS, ND · 7 FAA charts · cycle 6 Aug 2026

FAA RDRElevation 910 ft1 runwayLongest 12,351 ftToweredVolume NC-1Not for navigation
KRDR airport diagram — runways, taxiways and ramp layout
KRDR airport diagram The official FAA airport diagram — runways, taxiways, ramp layout and hold-short positions. Download PDF

6 published instrument approaches: 2 ILS approaches, 2 RNAV (GPS), serving 2 runway ends.

All 7 KRDR charts in one download Every approach, departure, arrival and minimums page for this airport, sorted into folders, as a single ZIP. Taken one at a time on the free tier, 7 charts is roughly 44 sec of downloading — they queue one behind another.
PRO members only

Instrument approach procedures

ChartAmendment
ILS OR LOC RWY 18 chart previewILS OR LOC RWY 18—PDF
ILS OR LOC RWY 36 chart previewILS OR LOC RWY 36—PDF
RNAV (GPS) RWY 18 chart previewRNAV (GPS) RWY 18—PDF
RNAV (GPS) RWY 36 chart previewRNAV (GPS) RWY 36—PDF
TACAN RWY 18 chart previewTACAN RWY 18—PDF
TACAN RWY 36 chart previewTACAN RWY 36—PDF

KRDR airport information

Control tower
Yes
Attendance
Continuous
ARTCC
Minneapolis Center
Flight service
Grand Forks
NOTAM facility
GFK (NOTAM-D available)
Magnetic variation
3E
Traffic pattern altitude
1,500 ft
Beacon
Split-white-green (military airport), sunset to sunrise
Wind indicator
Yes
Airframe service
Major
Powerplant service
Major
Bottled oxygen
None
Customs
Landing rights airport
Ownership
Privately owned
Sectional
Twin Cities

From the FAA NASR 28-day subscription, cycle 6 Aug 2026.

KRDR radio frequencies

ServiceFrequencyCall sign
Tower124.9Red River
Ground119.15Red River
Approach118.1Red River
Emergency121.5Red River

Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.

Runways

12,351 × 150 ft1836N1,000 ft
Runway layout at KRDR, drawn to scale from FAA published runway-end coordinates and true alignments. Runways served by an ILS are highlighted.
RunwayLengthWidth SurfaceLighting
18/3612,351 ft150 ftAsphalt GoodHigh intensity
  18 180°TLOC/GS · PAPI (4-box) 2.6° · ALSF-1 approach lighting · right-hand circuit
  36ILS · PAPI (4-box) 2.6° · ALSF-1 approach lighting

Runway and approach-aid data from the FAA NASR 28-day subscription.

Where KRDR is

Latitude, longitude47.9612800, -97.4008140
Elevation910 ft
From Grand Forks13 nm W

Paste the coordinates into a simulator’s world map to drop straight onto the field.

FAA remarks for KRDR

  • OIL AVBL IN PACKAGE PRODUCT ONLY, HAND TRANSFER RQR.
  • HVY, LRG, AND HI PER ACFT: OVHD 2500 FT MSL; RECTANGULAR 2000 FT MSL; LGT ACFT AND HEL 1500 FT MSL.
  • RWY: FIRST/LAST 1100 FT OF RWY 18/36 IS CONCRETE; MIDDLE 10150 FT OF RWY 18/36 IS ASPHALT. RWY 18/36 GROOVED.
  • VFR OVERHEAD AND RECTANGULAR TFC PAT RGT HAND RWY 18.
  • JASU: (AM32A-86) (AM32-95)
  • CAUTION: UNCTL VEH TFC ON TWY AND RAMPS.
  • RSTD: ALL INBD PAX/CARGO ACFT MUST CTC COMD POST NO LATER THAN 30 MIN PRIOR TO LDG. ACFT WITH DGR MATERIALS CTC PTD 30 MIN PRIOR TO ETA.
  • FUEL: J8
  • OIL: OIL AVBL IN PACKAGE PRODUCT ONLY, HAND TRANSFER RQR. O-133-148
  • MISC: ACFT WITH VHF RDO EQPT ONLY MAY CTC AM OPS THRU ATC. NO HGR SPACE. ALL ACFT WITH DV ON BOARD CTC COMD POST 60 NM PRIOR LDG.
  • ON BASE LODGING FOR TRANS AIRCREWS UNAVBL.
  • CAUTION: UAV OPS WITHIN 11 DME HALF CIRCLE RDR R-180 THRU RDR R-360 W OF GRAND FORKS AFB, SFC TO FL 180.UAV OPS ENTIRE CLASS D AIRSPACE.
  • SERVICE: TRAN ALERT: OPR 1300-0100Z++ MON-FRI, 1400-2300Z++ SAT AND SUN. NO NML OPR ON FED HOL.
  • AFTER HRS REQ MUST HAVE APVL OF RW/CV.
  • RSTD: PPR ALL TSNT ACFT, CTC AFLD GMT DSN 362-4409, C701-747-4409 FAX EXTN 4212.
  • RSTD: LTD CLASSIFIED STOR FOR TRAN AIRCREWS.
  • MISC: WX SVC AVBL H24 AT DSN 362-4396, C701-747-4396. AN/FMQ-19 AUTOMATED OBSERVING SYS IN USE; AUGMENTED BY HUMAN OBSN WHEN NEC. CTC 15 OWS SCOTT AFB DSN 576-9755, C 618-256-9755 DUR WX FLT CLOSURE OR EVAC. BLDG OBSTN MAY IMPACT PREVAILING VIS 010--220-.
  • MISC: RWY COND CODE & FICON NOT RPT.
  • RSTD: BASH PHASE I & II DTRMD BY BGNG & END OF WATERFOWL MIGRATION; NOTAM WILL BE PUBL WHEN PHASE II IS IMPLEMENTED.
  • CAUTION: RWY SFC DETERIORATED. GROOVES IN RWY MAY NOT PRODUCE EXP BA WHEN THE RWY IS WET.
  • OPR 1200-0530Z++; CLSD HOL.
  • SVC: FLUID: SP PRESAIR.

Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.

Balanced coverage for one long runway

Grand Forks AFB has six approaches serving both ends of its sole 12,351 ft runway. The mix of ILS, RNAV (GPS) and localiser procedures provides precision and non-precision coverage without leaving either runway direction unserved. Its length accommodates aircraft with substantial runway-distance requirements, although the single 18/36 alignment provides no second runway orientation.

Chart coverage nearby

Grand Forks International, nine nautical miles east, has twice as many published charts and is the only nearby field with comparably broad procedure coverage. Northwood, Hutson Field, Park River and Warren have much thinner sets, with only two or three charts each. The Twin Cities Sectional adds the wider visual context around the airport that the airport diagram and instrument procedures do not show.

Airports near KRDR

IDAirportCity DistanceCharts
KGFKGrand Forks IntlGRAND FORKS, ND9 nm E14
4V4Northwood Muni/Vince FldNORTHWOOD, ND16 nm SW2
KGAFHutson FldGRAFTON, ND27 nm N3
Y37Park River - W C Skjerven FldPARK RIVER, ND30 nm NW2
D37Warren MuniWARREN, MN31 nm NE2
KCKNCrookston Muni/Kirkwood FldCROOKSTON, MN32 nm E4
5L0Lakota MuniLAKOTA, ND37 nm W2
3H4Hillsboro MuniHILLSBORO, ND39 nm S3

VFR charts covering KRDR

Twin CitiesSectional Chart

Common questions about KRDR

What charts are available for KRDR?

7 current FAA charts for Grand Forks AFB, including 6 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.

What are the radio frequencies for KRDR?

Tower 124.9; Ground 119.15. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.

How long is the runway at KRDR?

Grand Forks AFB has 1 runway. The longest is 18/36 at 12,351 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.

Does KRDR have an ILS approach?

Yes — 2 ILS procedures are published. In total KRDR has 6 published instrument approaches, of which 2 are RNAV (GPS).

Where can I download the KRDR airport diagram?

The official FAA airport diagram for Grand Forks AFB is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.

Is KRDR a towered airport?

Yes. Grand Forks AFB has an operating control tower, within Minneapolis Center's airspace. Tower, ground and clearance frequencies are listed on this page.

Are these KRDR charts current?

They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
