SOUTH BEND, IN · 12 FAA charts · cycle 6 Aug 2026
9 published instrument approaches: 3 ILS approaches, 6 RNAV (GPS), serving 6 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 135.675 | |
| Ground | 121.7 | South Bend |
| Clearance delivery | 121.9 | South Bend |
| ATIS | 120.675 | South Bend |
| Approach | 118.55270-099124.1100-269132.05100-269 | South Bend |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 09R/27L | 8,412 ft | 150 ft | Asphalt Good | High intensity |
| 09R 89°T | ILS · PAPI (4-box) 3° · MALSF approach lighting | |||
| 27L 269°T | ILS · PAPI (4-box) 3° · MALSR approach lighting | |||
| 18/36 | 7,101 ft | 150 ft | Asphalt Good | Medium intensity |
| 18 179°T | PAPI (4-box) 3° | |||
| 36 359°T | PAPI (4-box) 3° | |||
| 09L/27R | 4,300 ft | 75 ft | Asphalt Good | Medium intensity |
| 09L 89°T | PAPI (2-box) 3° | |||
| 27R 269°T | PAPI (2-box) 3° | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
41.7082240, -86.3173380
798 ft3 nm NWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
South Bend’s procedure set reaches all six runway ends, so instrument coverage is not confined to the longest runway or a single direction. RNAV (GPS) forms the majority, while three ILS and two localiser approaches add ground-based guidance across the layout. The runway lengths are notably uneven: any operation requiring more than 4,300 ft has only the two longer runways available by length. The airport diagram brings the three-runway ground layout together in one reference.
Elkhart Municipal’s eight-chart set is the closest nearby field in procedure volume. The other listed airports have only three or four charts each, making their published coverage much thinner. The Chicago Sectional adds wider visual-navigation context around South Bend that the airport-specific instrument procedures do not provide.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| 3TR | Jerry Tyler Meml | NILES, MI | 9 nm NE | 3 |
| KEKM | Elkhart Muni | ELKHART, IN | 14 nm E | 8 |
| C20 | Andrews University Airpark | BERRIEN SPRINGS, MI | 15 nm N | 3 |
| C91 | Dowagiac Muni | DOWAGIAC, MI | 19 nm NE | 3 |
| KPPO | La Porte Muni | LA PORTE, IN | 20 nm SW | 4 |
| C65 | Plymouth Muni | PLYMOUTH, IN | 21 nm S | 4 |
| KMGC | Michigan City Muni-Phillips Fld | MICHIGAN CITY, IN | 23 nm W | 3 |
| C03 | Nappanee Muni | NAPPANEE, IN | 23 nm SE | 2 |
12 current FAA charts for South Bend Intl, including 9 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Ground 121.7; ATIS 120.675; CTAF 135.675; Clearance delivery 121.9. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
South Bend Intl has 3 runways. The longest is 09R/27L at 8,412 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 3 ILS procedures are published. In total KSBN has 9 published instrument approaches, of which 6 are RNAV (GPS).
The official FAA airport diagram for South Bend Intl is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. South Bend Intl has an operating control tower, within Chicago Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
