HARTFORD, CT · 10 FAA charts · cycle 6 Aug 2026
4 published instrument approaches: 1 RNAV (GPS), 1 VOR.
| Chart | Amendment | ||
|---|---|---|---|
 | LDA RWY 02 | 2C | |
 | RIVER VISUAL RWY 02 | — | |
 | RNAV (GPS) RWY 02 | 0D | |
 | VOR-A | 10B |
| Chart | Amendment | ||
|---|---|---|---|
 | THUMB ONE (RNAV) | — |
| Chart | Amendment | ||
|---|---|---|---|
 | STELA ONE (RNAV) | — |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 119.6 | |
| UNICOM | 122.95 | |
| Ground | 121.6When Twr Clsd | Brainard |
| ATIS | 126.45 | Brainard |
| Approach | 127.8 | Brainard |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 02/20 | 4,417 ft | 150 ft | Asphalt Fair | High intensity |
| 02 9°T | LDA · PAPI (4-box) 3.5° · displaced threshold 411 ft | |||
| 20 189°T | PAPI (4-box) 4° · displaced threshold 560 ft | |||
| NE/SW | 2,323 ft | 150 ft | Grass | |
| 11/29 | 2,314 ft | 71 ft | Asphalt Good | High intensity |
| 29 279°T | displaced threshold 265 ft | |||
| H1 | 70 ft | 77 ft | Asphalt Good | Medium intensity |
| H2 | 44 ft | 44 ft | Asphalt Excellent | Medium intensity |
Runway and approach-aid data from the FAA NASR 28-day subscription.
41.7367100, -72.6494330
18 ft3 nm SEPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Hartford-Brainard’s published approaches are concentrated on a single runway end, with RNAV (GPS) and VOR procedures represented. The opposite end has no published approach, so the instrument chart set does not provide equivalent coverage in both directions. Runway 02/20, at 4,417 ft, is the clear length-dominant alignment: the paved 11/29 and turf NE/SW strips are each little more than half as long. The airport diagram also distinguishes the two helipads from the aeroplane runways.
Among nearby fields, Bradley International has by far the broadest procedure set, while Robertson Field, Meriden Markham Municipal, Windham and Chester have appreciably thinner coverage. The New York Sectional supplies the wider visual-navigation context that the airport-specific terminal procedures do not show.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| 4B8 | Robertson Fld | PLAINVILLE, CT | 10 nm W | 4 |
| KBDL | Bradley Intl | WINDSOR LOCKS, CT | 12 nm N | 21 |
| KMMK | Meriden Markham Muni | MERIDEN, CT | 16 nm SW | 4 |
| KIJD | Windham | WILLIMANTIC, CT | 21 nm E | 5 |
| KSNC | Chester | CHESTER, CT | 22 nm S | 6 |
| KBAF | Westfield-Barnes Rgnl | WESTFIELD/SPRINGFIELD, MA | 25 nm N | 14 |
| KOXC | Waterbury-Oxford | OXFORD, CT | 27 nm SW | 9 |
| KCEF | Westover ARB/Metro | SPRINGFIELD/CHICOPEE, MA | 28 nm N | 11 |
10 current FAA charts for Hartford-Brainard, including 4 instrument approachs, 1 departure procedure, 1 arrival procedure, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Ground 121.6; ATIS 126.45; CTAF 119.6; UNICOM 122.95. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Hartford-Brainard has 5 runways. The longest is 02/20 at 4,417 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
No ILS is published. In total KHFD has 4 published instrument approaches, of which 1 are RNAV (GPS).
The official FAA airport diagram for Hartford-Brainard is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Every published approach serves one runway end. There is no instrument procedure to the reciprocal direction, so an arrival in instrument conditions commits to that single approach direction regardless of the wind.
Yes. Hartford-Brainard has an operating control tower, within Boston Center's airspace. Tower, ground and clearance frequencies are listed on this page.
5, which is why the chart set is as large as it is — each runway end that supports an instrument approach needs its own plates. The runway diagram on this page shows the layout to scale.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
