TACOMA, WA · 21 FAA charts · cycle 6 Aug 2026
7 published instrument approaches: 3 ILS approaches including CAT II/III minima, 2 RNAV (GPS), serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | ILS OR LOC RWY 16 | — | |
 | ILS OR LOC RWY 34 | — | |
 | ILS RWY 34 (CAT II) | — | |
 | RNAV (GPS) RWY 16 | — | |
 | RNAV (GPS) RWY 34 | — | |
 | TACAN RWY 16 | — | |
 | TACAN RWY 34 | — |
| Chart | Amendment | ||
|---|---|---|---|
 | ALDER TWO | — | |
 | MOCAA FOUR (RNAV) | — | |
 | OLYMPIC FOUR | — | |
 | PUGET SIX | — |
| Chart | Amendment | ||
|---|---|---|---|
 | ADYMS THREE (RNAV) | — | |
 | ADYMS THREE (RNAV), CONT.1 | — | |
 | ARRIE NINE | — | |
 | ELLENSBURG FOUR (RNAV) | — | |
 | GLASR THREE | — | |
 | GLASR THREE, CONT.1 | — | |
 | JAWBN SEVEN | — | |
 | WHYTE SEVEN | — |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| Tower | 124.8 | Mcchord |
| Ground | 118.175 | Mcchord |
| ATIS | 135.825 | Mcchord |
| Approach | 126.5 | Mcchord |
| Emergency | 121.5 | Mcchord |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 16/34 | 10,108 ft | 150 ft | Asphalt over concrete | High intensity |
| 16 180°T | LOC/GS · PAPI (4-box) 3° · ALSF-1 approach lighting | |||
| 34 360°T | ILS · PAPI (4-box) 3° · ALSF-2 approach lighting · right-hand circuit | |||
| 162/342 | 3,000 ft | 60 ft | Asphalt | |
Runway and approach-aid data from the FAA NASR 28-day subscription.
47.1376780, -122.4764750
322 ft3 nm SPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
McChord Field’s seven approaches serve two of its four runway ends. The mix of ILS, localiser and RNAV (GPS) procedures provides several instrument options on the covered ends, while the remaining ends have no published approach. One ILS carries CAT II/III minima, adding a lower-category capability not shared by the other procedures.
The 10,108 ft runway is more than three times the length of the 3,000 ft strip, so they offer distinctly different scope for aircraft with greater runway-length requirements. Among nearby fields, Seattle-Tacoma International has a much broader chart set; Gray AAF and Tacoma Narrows have the closest totals but remain considerably thinner, while Pierce County/Thun Field and Auburn Municipal have fewer still. The Seattle Sectional adds wider VFR context around Tacoma and these neighbouring airports.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KGRF | Gray AAF (Joint Base Lewis-Mcchord) | FORT LEWIS/TACOMA, WA | 6 nm SW | 8 |
| KPLU | Pierce County/Thun Fld | PUYALLUP, WA | 8 nm E | 3 |
| KTIW | Tacoma Narrows | TACOMA, WA | 9 nm NW | 7 |
| S50 | Auburn Muni | AUBURN, WA | 15 nm NE | 4 |
| KSEA | Seattle-Tacoma Intl | SEATTLE, WA | 20 nm N | 63 |
| KOLM | Olympia Rgnl | OLYMPIA, WA | 20 nm SW | 9 |
| KRNT | Renton Muni | RENTON, WA | 24 nm NE | 15 |
| KPWT | Bremerton Ntl | BREMERTON, WA | 24 nm NW | 5 |
21 current FAA charts for Mcchord Fld (Joint Base Lewis-Mcchord), including 7 instrument approachs, 4 departure procedures, 8 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 124.8; Ground 118.175; ATIS 135.825. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Mcchord Fld (Joint Base Lewis-Mcchord) has 2 runways. The longest is 16/34 at 10,108 ft by 150 ft, asphalt over concrete. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 3 ILS procedures are published, including CAT II/III minima. In total KTCM has 7 published instrument approaches, of which 2 are RNAV (GPS).
The official FAA airport diagram for Mcchord Fld (Joint Base Lewis-Mcchord) is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. 1 of the published ILS procedures carry CAT II/III minima, which allow approaches in lower visibility than a standard CAT I ILS. Those plates are listed separately in the approach table above, marked CAT II or CAT III in the chart name.
Yes. Mcchord Fld (Joint Base Lewis-Mcchord) has an operating control tower, within Seattle Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
