Terminal Procedures

KSEA — Seattle-Tacoma Intl

SEATTLE, WA · 63 FAA charts · cycle 6 Aug 2026

FAA SEAElevation 432 ft3 runwaysLongest 11,901 ftToweredFuel Jet A, Jet A-1Volume NW-1Not for navigation
KSEA airport diagram — runways, taxiways and ramp layout
KSEA airport diagram The official FAA airport diagram — runways, taxiways, ramp layout and hold-short positions. Download PDF

35 published instrument approaches: 16 ILS approaches including CAT II/III minima, 14 RNAV (GPS), serving 8 runway ends.

All 63 KSEA charts in one download Every approach, departure, arrival and minimums page for this airport, sorted into folders, as a single ZIP. Taken one at a time on the free tier, 63 charts is roughly 7 min of downloading — they queue one behind another.
PRO members only

Instrument approach procedures

ChartAmendment
BAY VISUAL RWY 16 R/C/L chart previewBAY VISUAL RWY 16 R/C/L—PDF
BAY VISUAL RWY 16 R/C/L, CONT.1 chart previewBAY VISUAL RWY 16 R/C/L, CONT.1—PDF
HUSKY VISUAL RWY 16 R/C/L chart previewHUSKY VISUAL RWY 16 R/C/L—PDF
HUSKY VISUAL RWY 16 R/C/L, CONT.1 chart previewHUSKY VISUAL RWY 16 R/C/L, CONT.1—PDF
ILS OR LOC RWY 16C chart previewILS OR LOC RWY 16C17PDF
ILS OR LOC RWY 16C, CONT.1 chart previewILS OR LOC RWY 16C, CONT.117PDF
ILS OR LOC RWY 16L chart previewILS OR LOC RWY 16L8APDF
ILS OR LOC RWY 16R chart previewILS OR LOC RWY 16R5PDF
ILS OR LOC RWY 34C chart previewILS OR LOC RWY 34C3EPDF
ILS OR LOC RWY 34L chart previewILS OR LOC RWY 34L1FPDF
ILS OR LOC RWY 34R chart previewILS OR LOC RWY 34R3PDF
ILS RWY 16C (CAT II - III) chart previewILS RWY 16C (CAT II - III)17PDF
ILS RWY 16C (SA CAT I) chart previewILS RWY 16C (SA CAT I)17PDF
ILS RWY 16L (CAT II - III) chart previewILS RWY 16L (CAT II - III)8APDF
ILS RWY 16L (SA CAT I) chart previewILS RWY 16L (SA CAT I)8APDF
ILS RWY 16R (CAT II - III) chart previewILS RWY 16R (CAT II - III)5PDF
ILS RWY 16R (SA CAT I) chart previewILS RWY 16R (SA CAT I)5PDF
ILS RWY 34C (SA CAT I - II) chart previewILS RWY 34C (SA CAT I - II)3EPDF
ILS RWY 34L (SA CAT I - II) chart previewILS RWY 34L (SA CAT I - II)1FPDF
ILS RWY 34R (SA CAT I - II) chart previewILS RWY 34R (SA CAT I - II)3PDF
MALL VISUAL RWY 34 R/C/L chart previewMALL VISUAL RWY 34 R/C/L—PDF
RNAV (GPS) Y RWY 16C chart previewRNAV (GPS) Y RWY 16C3APDF
RNAV (GPS) Y RWY 16C, CONT.1 chart previewRNAV (GPS) Y RWY 16C, CONT.13APDF
RNAV (GPS) Y RWY 16L chart previewRNAV (GPS) Y RWY 16L5BPDF
RNAV (GPS) Y RWY 16R chart previewRNAV (GPS) Y RWY 16R2APDF
RNAV (GPS) Y RWY 34C chart previewRNAV (GPS) Y RWY 34C2DPDF
RNAV (GPS) Y RWY 34L chart previewRNAV (GPS) Y RWY 34L1CPDF
RNAV (GPS) Y RWY 34R chart previewRNAV (GPS) Y RWY 34R2DPDF
RNAV (RNP) Z RWY 16C chart previewRNAV (RNP) Z RWY 16C1APDF
RNAV (RNP) Z RWY 16C, CONT.1 chart previewRNAV (RNP) Z RWY 16C, CONT.11APDF
RNAV (RNP) Z RWY 16L chart previewRNAV (RNP) Z RWY 16L2APDF
RNAV (RNP) Z RWY 16R chart previewRNAV (RNP) Z RWY 16R1APDF
RNAV (RNP) Z RWY 34C chart previewRNAV (RNP) Z RWY 34C2BPDF
RNAV (RNP) Z RWY 34L chart previewRNAV (RNP) Z RWY 34L2APDF
RNAV (RNP) Z RWY 34R chart previewRNAV (RNP) Z RWY 34R1BPDF

Departure procedures

ChartAmendment
BANGR NINE (RNAV) chart previewBANGR NINE (RNAV)—PDF
BANGR NINE (RNAV), CONT.1 chart previewBANGR NINE (RNAV), CONT.1—PDF
ELMAA FIVE chart previewELMAA FIVE—PDF
HAROB SIX (RNAV) chart previewHAROB SIX (RNAV)—PDF
HAROB SIX (RNAV), CONT.1 chart previewHAROB SIX (RNAV), CONT.1—PDF
ISBRG ONE (RNAV) chart previewISBRG ONE (RNAV)—PDF
JEFPO ONE (RNAV) chart previewJEFPO ONE (RNAV)—PDF
MOUNTAIN TWO chart previewMOUNTAIN TWO—PDF
MOUNTAIN TWO, CONT.1 chart previewMOUNTAIN TWO, CONT.1—PDF
OZWLD ONE (RNAV) chart previewOZWLD ONE (RNAV)—PDF
SEATTLE ONE chart previewSEATTLE ONE—PDF
SUMMA TWO chart previewSUMMA TWO—PDF
SUMMA TWO, CONT.1 chart previewSUMMA TWO, CONT.1—PDF

Arrival procedures (STAR)

ChartAmendment
CHINS FIVE chart previewCHINS FIVE—PDF
CHINS FIVE, CONT.1 chart previewCHINS FIVE, CONT.1—PDF
GLASR THREE chart previewGLASR THREE—PDF
GLASR THREE, CONT.1 chart previewGLASR THREE, CONT.1—PDF
HAWKZ EIGHT (RNAV) chart previewHAWKZ EIGHT (RNAV)—PDF
HAWKZ EIGHT (RNAV), CONT.1 chart previewHAWKZ EIGHT (RNAV), CONT.1—PDF
JAWBN SEVEN chart previewJAWBN SEVEN—PDF
MARNR EIGHT (RNAV) chart previewMARNR EIGHT (RNAV)—PDF
MARNR EIGHT (RNAV), CONT.1 chart previewMARNR EIGHT (RNAV), CONT.1—PDF
OLYMPIA TWO chart previewOLYMPIA TWO—PDF
OLYMPIA TWO, CONT.1 chart previewOLYMPIA TWO, CONT.1—PDF
SKYKO ONE chart previewSKYKO ONE—PDF

Takeoff and alternate minimums

ChartAmendment
TAKEOFF MINIMUMS chart previewTAKEOFF MINIMUMS—PDF

Minimums pages cover a whole volume, so the same document is shared by every airport in it.

Hot spots

ChartAmendment
HOT SPOT chart previewHOT SPOT—PDF

KSEA airport information

Control tower
Yes
Attendance
Continuous
ARTCC
Seattle Center
Flight service
Seattle
NOTAM facility
SEA (NOTAM-D available)
Magnetic variation
16E
Beacon
White-green (lighted land airport), sunset to sunrise
Wind indicator
Lighted
ARFF index
Index E
Fuel
Jet A, Jet A-1
Bottled oxygen
None
Parking
Tie-downs
Landing fee
Yes
Customs
Landing rights airport
Activated
January 1944
Airport area
2,500 acres
Ownership
Publicly owned
Sectional
Seattle
Last FAA inspection
2026-01-16

From the FAA NASR 28-day subscription, cycle 6 Aug 2026.

KSEA radio frequencies

ServiceFrequencyCall sign
UNICOM122.95
Tower119.9Rwy 16l/34r, 16c/34c120.95Rwy 16r/34lSeattle
Ground121.7Seattle
Clearance delivery128.0Seattle
ATIS118.0Seattle
Approach119.2017-079 Sea Rwy 34120.1223-289 Sea, Rwy 16120.4301-340 Sea, Rwy 34123.9125.6Arr West125.9080-125 Sea, Rwy 34Seattle
Emergency121.5Seattle

Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.

Runways

11,901 × 150 ft16L34R9,426 × 150 ft16C34C8,500 × 150 ft16R34LN1,000 ft
Runway layout at KSEA, drawn to scale from FAA published runway-end coordinates and true alignments. Runways served by an ILS are highlighted.
RunwayLengthWidth SurfaceLighting
16L/34R11,901 ft150 ftConcrete ExcellentHigh intensity
  16L 180°TILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting
  34RILS/DME · PAPI (4-box) 2.75° · MALSR approach lighting
16C/34C9,426 ft150 ftConcrete ExcellentHigh intensity
  16C 180°TILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting
  34CILS/DME · PAPI (4-box) 3° · MALSR approach lighting
16R/34L8,500 ft150 ftConcrete ExcellentHigh intensity
  16R 180°TILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting
  34LILS/DME · PAPI (4-box) 3° · MALSR approach lighting

Runway and approach-aid data from the FAA NASR 28-day subscription.

Where KSEA is

Latitude, longitude47.4498890, -122.3117780
Elevation432 ft
From Seattle10 nm S

Paste the coordinates into a simulator’s world map to drop straight onto the field.

FAA remarks for KSEA

  • EXISTED PRIOR TO MAY 15, 1959.
  • BIRD FLOCKS ON AND INVOF ARPT - CHECK LCL ADZYS.
  • TDT 817
  • PCR VALUE: 1002/R/B/W/T
  • PCR VALUE: 1147/R/B/W/T
  • PCR VALUE: 866/R/B/W/T
  • FLIGHT NOTIFICATION SERVICE (ADCUS) AVBL.
  • HELICOPTERS LANDING & DEPARTING AVOID OVERFLYING FUEL FARM LCTD AT THE SE CORNER OF THE ARPT.
  • (E110) CONTINUOUS POWER ARPT.
  • (E94) WSO/WSFO.
  • TWY A SOUTH OF TWY G RSTD TO ACFT WITH WINGSPAN 225 FT OR LESS.
  • DO NOT MISTAKE TWY T FOR LDG SFC.
  • ACES TO AIR CARGO 4 PRKG AND CARGO AREAS RSTD TO ACFT WITH WINGSPAN 170 FT OR LESS.
  • TWY FOR CORPORATE HNGR RAMP RSTD TO ACFT WITH WINGSPAN 62 FT OR LESS FOR TAXI OPS. GA CUST PRKG IS VERY LTD.
  • PPR FOR ALL GA PRKG AND SVCS;, CTC 206-433-5481. OPER HRS 0700L - 2100L, WITH A CALL OUT AVBL UPON REQ.
  • TXL W RSTRD TO ACFT WITH WINGSPAN 135 FT OR LESS NORTH OF TWY N AND 167 FT OR LESS SOUTH OF TWY N. SEATTLE RAMP TWR PRVDS ADZY CTL ONLY.
  • GA LDG FEES PAYABLE BY MAJOR CREDIT CARDS ONLY.
  • TXL ON NORTH SIDE OF TWY N STLT RSTD TO ACFT WITH WINGSPAN 118 FT OR LESS. TRI-TXL'S AT NORTH STLT: CNTR (GREEN) TXL RSTD TO ACFT WITH WINGSPAN 135 FT OR LESS. WHEN AN ACFT IS ON THE CNTR (GREEN) OR OTR (ORANGE/BLUE) TXL'S, NO OTR ACFT CAN SIMUL USE THE ADJ TXL(S). ORANGE & BLUE TXL'S ARE RSTD TO ACFT WITH WINGSPAN 118 FT OR LESS. TWO ACFT CAN SIMUL USE THE OUTER TXL'S.
  • RY STATUS LGTS ARE IN OPN.
  • ACFT WITH WINGSPAN OF 171 FT. OR MORE PRKD AT PAX GATES OR CARGO 7 MUST PROVD 30 MIN PPR PRIOR TO PUSHBACK TO SEATTLE RAMP TWR WHEN VIS LESS THAN 2400 RVR.
  • TWY J EAST OF TWY T RSTD TO ACFT WITH WINGSPAN 118 FT OR LESS.
  • RWY 16L/34R RSTD TO ACFT WITH WINGSPAN 260 FT OR LESS.
  • TWY H RSTRD TO ACFT WITH WINGSPAN 118 FT OR LESS.
  • TWY B SOUTH OF TWY S RSTRD TO ACFT WITH WINGSPAN 260 FT OR LESS.
  • AIR CARGO 5 RAMP DUAL ENG TAX ONLY
  • 100LL FUEL NOT AVBL.
  • THE USE OF REVERSE THRUST BYD WHAT IS NEC FOR OPNL OR SAFETY RSNS IS DISCOURAGED AT ALL TIMES. NOISE ABATEMENT FLT PROCS IN EFCT BTN 2200-0600. FOR FURTHER INFO CTC SEA NOISE ABATEMENT OFC AT 206-787-5393.
  • CONS TAXI TO TAKEOFF AT SEA. WHEN PRACTICAL, SAFE AND AVBL, CONS TAXI TO TAKEOFFS ARE ENCOURAGED. CONS TAXI TO TAKEOFFS MAY RDC ACFT NOISE WI NEARBY COMMUNITIES.
  • RPRT BIRD STRIKES TO 206-787-7233
  • SOUTH SATELLITE TXL RSTRD TO ACFT WITH WINGSPAN OF 214 FT OR LESS.
  • CARGO1 RSTRD TO ACFT WITH WINGSPAN OF 170 FT OR LESS.
  • TO MINIMIZE NOISE, FUEL BURN AND JET BLAST, OPERATORS ARE ADVISED TO USE THE MNM RQRD THRUST WHEN TAXIING INVOF THE TRML OR ACFT PRKG AREAS.

Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.

Parallel-runway procedure coverage

Seattle-Tacoma’s three parallel runways are matched by a substantial mix of ILS, RNAV (GPS) and localiser procedures, rather than dependence on a single approach type. Three ILS procedures include CAT II/III minima. The 3,401 ft difference between the shortest and longest runway also makes runway assignment significant to the landing distance available, while the departure and arrival chart sets provide comparable depth in each direction of flight.

Nearby and VFR coverage

Boeing Field has the broadest procedure collection among the nearby airports, followed by Renton Municipal. Auburn Municipal, Tacoma Narrows and Bremerton National have markedly thinner chart coverage. The Seattle Sectional adds broader-area VFR context beyond the airport-specific terminal procedures.

Airports near KSEA

IDAirportCity DistanceCharts
KRNTRenton MuniRENTON, WA5 nm NE15
KBFIBoeing Fld/King County IntlSEATTLE, WA5 nm N23
S50Auburn MuniAUBURN, WA8 nm SE4
KTIWTacoma NarrowsTACOMA, WA15 nm SW7
KPWTBremerton NtlBREMERTON, WA19 nm W5
KTCMMcchord Fld (Joint Base Lewis-Mcchord)TACOMA, WA20 nm S21
KPLUPierce County/Thun FldPUYALLUP, WA21 nm S3
KGRFGray AAF (Joint Base Lewis-Mcchord)FORT LEWIS/TACOMA, WA25 nm SW8

VFR charts covering KSEA

SeattleSectional Chart

Common questions about KSEA

What charts are available for KSEA?

63 current FAA charts for Seattle-Tacoma Intl, including 35 instrument approachs, 13 departure procedures, 12 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.

What are the radio frequencies for KSEA?

Tower 119.9, 120.95; Ground 121.7; ATIS 118.0; UNICOM 122.95; Clearance delivery 128.0. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.

How long is the runway at KSEA?

Seattle-Tacoma Intl has 3 runways. The longest is 16L/34R at 11,901 ft by 150 ft, concrete. Full runway dimensions, lighting and approach aids are listed on this page.

Does KSEA have an ILS approach?

Yes — 16 ILS procedures are published, including CAT II/III minima. In total KSEA has 35 published instrument approaches, of which 14 are RNAV (GPS).

Where can I download the KSEA airport diagram?

The official FAA airport diagram for Seattle-Tacoma Intl is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.

Does KSEA have CAT II or CAT III approaches?

Yes. 3 of the published ILS procedures carry CAT II/III minima, which allow approaches in lower visibility than a standard CAT I ILS. Those plates are listed separately in the approach table above, marked CAT II or CAT III in the chart name.

Is KSEA a towered airport?

Yes. Seattle-Tacoma Intl has an operating control tower, within Seattle Center's airspace. Tower, ground and clearance frequencies are listed on this page.

Are these KSEA charts current?

They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
