BEAUFORT, SC · 18 FAA charts · cycle 6 Aug 2026
15 published instrument approaches: 2 ILS approaches, 4 RNAV (GPS), serving 4 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | RADAR MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| Tower | 119.05 | Beaufort |
| Ground | 128.15 | Beaufort |
| Approach | 123.73000 Ft & Blw125.125Abv 3000 Ft | Beaufort |
| Emergency | 121.5 | Beaufort |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 05/23 | 12,202 ft | 200 ft | Porous asphalt | High intensity |
| 05 42°T | PAPI (4-box) 3° · SALSF | |||
| 23 222°T | ILS/DME · PAPI (4-box) 3° · ALSF-1 approach lighting | |||
| 14/32 | 8,001 ft | 200 ft | Porous asphalt | High intensity |
| 14 135°T | PAPI (4-box) 3° | |||
| 32 315°T | PAPI (4-box) 3° | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
32.4805670, -80.7192450
37 ft3 nm NWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Beaufort MCAS has instrument procedures serving all four ends of its two runways. The mix of ILS, localiser and RNAV (GPS) procedures provides more than one form of approach coverage rather than concentrating the chart set on a single alignment. At 12,202 ft and 8,001 ft, both runways are substantial in length, so the crossing configuration offers two usable alignments without the second runway being merely a short auxiliary strip.
Savannah/Hilton Head International has nearly comparable procedure coverage, while Hilton Head, Lowcountry Regional and Hunter AAF have markedly thinner sets. Beaufort Executive, the closest listed field, has the smallest collection. The Charlotte Sectional supplies the wider-area VFR depiction that the airport diagram and terminal procedures do not provide.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KARW | Beaufort Exec | BEAUFORT, SC | 6 nm SE | 5 |
| KHXD | Hilton Head | HILTON HEAD ISLAND, SC | 15 nm S | 8 |
| KRBW | Lowcountry Rgnl | WALTERBORO, SC | 27 nm N | 8 |
| KSAV | Savannah/Hilton Head Intl | SAVANNAH, GA | 32 nm SW | 16 |
| KSVN | Hunter AAF | SAVANNAH, GA | 36 nm SW | 7 |
| KJZI | Charleston Exec | CHARLESTON, SC | 39 nm E | 14 |
| KDYB | Summerville | SUMMERVILLE, SC | 41 nm NE | 4 |
| KAQX | Allendale County | ALLENDALE, SC | 42 nm NW | 5 |
18 current FAA charts for Beaufort MCAS (Merritt Fld), including 15 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 119.05; Ground 128.15. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Beaufort MCAS (Merritt Fld) has 2 runways. The longest is 05/23 at 12,202 ft by 200 ft, porous asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 2 ILS procedures are published. In total KNBC has 15 published instrument approaches, of which 4 are RNAV (GPS).
The official FAA airport diagram for Beaufort MCAS (Merritt Fld) is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. Beaufort MCAS (Merritt Fld) has an operating control tower, within Jacksonville Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
