COLUMBIA, SC · 13 FAA charts · cycle 6 Aug 2026
9 published instrument approaches: 4 ILS approaches including CAT II/III minima, 4 RNAV (GPS), 1 VOR, serving 4 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| UNICOM | 122.95 | |
| Tower | 119.5 | Columbia |
| Ground | 121.9 | Columbia |
| Clearance delivery | 119.75 | Columbia |
| ATIS | 120.15 | Columbia |
| Approach | 124.15110-289133.4290-109 | Columbia |
| Emergency | 121.5 | Columbia |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 11/29 | 8,601 ft | 150 ft | Concrete Excellent | High intensity |
| 11 105°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 29 285°T | ILS · PAPI (4-box) 3° · MALSR approach lighting | |||
| 05/23 | 8,001 ft | 150 ft | Asphalt over concrete Excellent | High intensity |
| 05 45°T | ILS · PAPI (4-box) 3° · MALSR approach lighting | |||
| 23 225°T | PAPI (4-box) 3° · displaced threshold 1,000 ft | |||
| H1 | 50 ft | 50 ft | Concrete Fair | PERI |
Runway and approach-aid data from the FAA NASR 28-day subscription.
33.9388380, -81.1195360
235 ft5 nm SWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Columbia Metro’s nine approach plates serve all four ends of its two runways, so instrument coverage is not concentrated on a single alignment. The set combines ILS, RNAV (GPS), VOR and localiser procedures; one ILS also carries CAT II/III minima. At 8,001 and 8,601 ft, the two runway alignments provide broadly similar lengths rather than leaving one as a markedly shorter secondary option.
Among nearby fields, Mc Entire JNGB comes closest in chart coverage with seven published charts, while North AF Aux has five and the other listed airports four each. None matches Columbia Metro’s 13-chart set. The Atlanta and Charlotte sectionals add wider visual context beyond the airport diagram and terminal procedures, with Columbia Metro covered on both sheets.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KCUB | Jim Hamilton L B Owens | COLUMBIA, SC | 6 nm E | 4 |
| 6J0 | Lexington County | PELION, SC | 11 nm SW | 4 |
| KMMT | Mc Entire Jngb | EASTOVER, SC | 16 nm E | 7 |
| KXNO | North Af Aux | NORTH, SC | 20 nm S | 5 |
| KFDW | Fairfield County | WINNSBORO, SC | 23 nm N | 4 |
| KOGB | Orangeburg Muni | ORANGEBURG, SC | 32 nm SE | 6 |
| KSSC | Shaw AFB | SUMTER, SC | 32 nm E | 12 |
| KAIK | Aiken Rgnl | AIKEN, SC | 33 nm SW | 10 |
13 current FAA charts for Columbia Metro, including 9 instrument approachs, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 119.5; Ground 121.9; ATIS 120.15; UNICOM 122.95; Clearance delivery 119.75. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Columbia Metro has 3 runways. The longest is 11/29 at 8,601 ft by 150 ft, concrete. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 4 ILS procedures are published, including CAT II/III minima. In total KCAE has 9 published instrument approaches, of which 4 are RNAV (GPS).
The official FAA airport diagram for Columbia Metro is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. 1 of the published ILS procedures carry CAT II/III minima, which allow approaches in lower visibility than a standard CAT I ILS. Those plates are listed separately in the approach table above, marked CAT II or CAT III in the chart name.
Yes. Columbia Metro has an operating control tower, within Jacksonville Center's airspace. Tower, ground and clearance frequencies are listed on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
