CHICAGO, IL · 23 FAA charts · cycle 6 Aug 2026
13 published instrument approaches: 3 ILS approaches, 10 RNAV (GPS), serving 5 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | MIDWAY EIGHT | — |
| Chart | Amendment | ||
|---|---|---|---|
 | ENDEE EIGHT (RNAV) | — | |
 | ENDEE EIGHT (RNAV), CONT.1 | — | |
 | FISSK SEVEN (RNAV) | — | |
 | PANGG SEVEN (RNAV) | — | |
 | PANGG SEVEN (RNAV), CONT.1 | — |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| UNICOM | 122.95 | |
| Tower | 135.2 | Midway |
| Ground | 118.075 | Midway |
| Clearance delivery | 124.625 | Midway |
| ATIS | 132.75 | Midway |
| Approach | 126.05128.2 | Midway |
| Emergency | 121.5 | Midway |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 13L/31R | 6,522 ft | 150 ft | Asphalt over concrete Excellent | High intensity |
| 13L 134°T | ILS/DME · PAPI (4-box) 3° · RLLS · displaced threshold 463 ft | |||
| 31R 314°T | ILS/DME · PAPI (4-box) 3° · RLLS · displaced threshold 696 ft | |||
| 04R/22L | 6,445 ft | 150 ft | Asphalt over concrete Excellent | High intensity |
| 04R 43°T | ILS/DME · PAPI (4-box) 3° · displaced threshold 518 ft | |||
| 22L 223°T | PAPI (4-box) 3° · displaced threshold 635 ft | |||
| 04L/22R | 5,507 ft | 150 ft | Asphalt Good | Medium intensity |
| 04L 43°T | PAPI (4-box) 3° · displaced threshold 758 ft | |||
| 22R 223°T | PAPI (4-box) 3° · displaced threshold 878 ft | |||
| 13R/31L | 3,859 ft | 60 ft | Asphalt Excellent | Medium intensity |
Runway and approach-aid data from the FAA NASR 28-day subscription.
41.7856430, -87.7527290
619 ft9 nm SWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Chicago Midway’s procedure set serves five of its eight runway ends, so instrument approach coverage is selective rather than symmetrical. The mix of ILS, localiser and RNAV (GPS) procedures provides both ground-based and satellite-based options. Three runways are between 5,507 and 6,522 ft long, while 13R/31L is materially shorter at 3,859 ft; that difference makes runway assignment significant for aircraft requiring more distance.
Chicago O’Hare has by far the broadest nearby procedure set. Gary/Chicago and Lewis University are closer to Midway in chart coverage, while Lansing Municipal is thinner and Bolingbrook’s Clow International has only minimal published coverage. For visual flying, the Chicago Sectional supplies wider-area context, the Terminal Area Chart adds detail around Chicago, and the Helicopter Route Chart provides the specialised route depiction absent from the instrument procedures.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KORD | Chicago O'Hare Intl | CHICAGO, IL | 13 nm NW | 97 |
| 1C5 | Bolingbrook'S Clow Intl | BOLINGBROOK, IL | 18 nm W | 2 |
| KIGQ | Lansing Muni | CHICAGO, IL | 18 nm SE | 12 |
| KGYY | Gary/Chicago Intl | GARY/CHICAGO, IN | 18 nm SE | 20 |
| KLOT | Lewis University | CHICAGO/ROMEOVILLE, IL | 19 nm SW | 16 |
| KPWK | Chicago Exec | CHICAGO/PROSPECT HEIGHTS/WHEELING, IL | 21 nm N | 13 |
| 05C | Griffith-Merrillville | GRIFFITH, IN | 22 nm SE | 7 |
| KDPA | Dupage | CHICAGO/WEST CHICAGO, IL | 23 nm W | 17 |
23 current FAA charts for Chicago Midway Intl, including 13 instrument approachs, 1 departure procedure, 5 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 135.2; Ground 118.075; ATIS 132.75; UNICOM 122.95; Clearance delivery 124.625. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Chicago Midway Intl has 4 runways. The longest is 13L/31R at 6,522 ft by 150 ft, asphalt over concrete. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 3 ILS procedures are published. In total KMDW has 13 published instrument approaches, of which 10 are RNAV (GPS).
The official FAA airport diagram for Chicago Midway Intl is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. Chicago Midway Intl has an operating control tower, within Chicago Center's airspace. Tower, ground and clearance frequencies are listed on this page.
4, which is why the chart set is as large as it is — each runway end that supports an instrument approach needs its own plates. The runway diagram on this page shows the layout to scale.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
