CHICAGO, IL · 97 FAA charts · cycle 6 Aug 2026
71 published instrument approaches: 48 ILS approaches including CAT II/III minima, 22 RNAV (GPS), serving 15 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | OHARE NINE | — | |
 | OHARE NINE, CONT.1 | — |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — | |
 | ALTERNATE MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
| Chart | Amendment | ||
|---|---|---|---|
 | HOT SPOT | — |
| Chart | Amendment | ||
|---|---|---|---|
 | LAHSO | — |
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| UNICOM | 122.95 | |
| Tower | 120.75Rwy 04r/22l121.15Rwy 09c/27c126.9Rwy 09r/27l128.15Rwy 09l/27r132.7Rwy 10l/28r133.0Rwy 10r/28l | O Hare |
| Ground | 118.05Twr South121.675121.75Twr Center Outbound121.9Twr Center Inbound124.125Twr North134.15Twr Center | O Hare |
| Clearance delivery | 119.25121.6 | O Hare |
| ATIS | 135.4 | O Hare |
| Approach | 119.0360-179124.35125.7180-359133.625180-359 | O Hare |
| Departure | 126.625150-219 South128.575320-149 East/North | O Hare |
| Emergency | 121.5 | O Hare |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 10L/28R | 13,000 ft | 150 ft | Asphalt over concrete Good | High intensity |
| 10L 90°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 28R 270°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 09R/27L | 11,260 ft | 150 ft | Asphalt over concrete Excellent | High intensity |
| 09R 90°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 27L 270°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 09C/27C | 11,245 ft | 200 ft | Concrete Excellent | High intensity |
| 09C 90°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 27C 270°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 10C/28C | 10,800 ft | 200 ft | Concrete Excellent | High intensity |
| 10C 90°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 28C 270°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 04R/22L | 8,075 ft | 150 ft | Asphalt Good | High intensity |
| 04R 42°T | ILS · PAPI (4-box) 3° · MALSR approach lighting | |||
| 22L 222°T | ILS · PAPI (4-box) 3° · MALSR approach lighting | |||
| 04L/22R | 7,500 ft | 150 ft | Asphalt Good | High intensity |
| 22R 219°T | ILS · PAPI (4-box) 3° · MALSR approach lighting | |||
| 09L/27R | 7,500 ft | 150 ft | Concrete Good | High intensity |
| 09L 90°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 27R 270°T | ILS/DME · PAPI (4-box) 3° · ALSF-2 approach lighting | |||
| 10R/28L | 7,500 ft | 150 ft | Concrete Excellent | High intensity |
| 10R 90°T | ILS/DME · ALSF-2 approach lighting | |||
| 28L 270°T | ILS/DME · ALSF-2 approach lighting | |||
| H1 | 200 ft | 100 ft | Concrete | PERI |
| 10X | — | — | ||
| 10X | ILS/DME | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
41.9769400, -87.9081500
680 ft14 nm NWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
O’Hare’s 71 approach plates serve 15 of its 16 runway ends, with multiple procedures available for many alignments. The set is dominated by ILS procedures, including 14 with CAT II/III minima, while RNAV (GPS) and localiser options add further procedural depth. Eight runways provide several east–west alignments, including four measuring at least 10,800 ft; the remaining runways are no shorter than 7,500 ft.
Among nearby fields, Chicago Midway has the broadest chart coverage, followed by DuPage and Chicago Executive. Bolingbrook’s Clow and Campbell have much thinner sets, with only two charts each. The Chicago Sectional supplies wider visual context, the Terminal Area Chart gives more detailed coverage around Chicago, and the Helicopter Route Chart adds routing information specific to helicopter operations.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KPWK | Chicago Exec | CHICAGO/PROSPECT HEIGHTS/WHEELING, IL | 8 nm N | 13 |
| KMDW | Chicago Midway Intl | CHICAGO, IL | 13 nm SE | 23 |
| KDPA | Dupage | CHICAGO/WEST CHICAGO, IL | 16 nm W | 17 |
| 1C5 | Bolingbrook'S Clow Intl | BOLINGBROOK, IL | 20 nm SW | 2 |
| C81 | Campbell | GRAYSLAKE, IL | 22 nm N | 2 |
| 3CK | Lake In The Hills | CHICAGO/LAKE IN THE HILLS, IL | 23 nm NW | 3 |
| KLOT | Lewis University | CHICAGO/ROMEOVILLE, IL | 24 nm S | 16 |
| KUGN | Waukegan Ntl | CHICAGO/WAUKEGAN, IL | 27 nm N | 11 |
97 current FAA charts for Chicago O'Hare Intl, including 71 instrument approachs, 2 departure procedures, 19 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
Tower 120.75, 121.15, 126.9, 128.15, 132.7, 133.0; Ground 118.05, 121.675, 121.75, 121.9, 124.125, 134.15; ATIS 135.4; UNICOM 122.95; Clearance delivery 119.25, 121.6. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Chicago O'Hare Intl has 10 runways. The longest is 10L/28R at 13,000 ft by 150 ft, asphalt over concrete. Full runway dimensions, lighting and approach aids are listed on this page.
Yes — 48 ILS procedures are published, including CAT II/III minima. In total KORD has 71 published instrument approaches, of which 22 are RNAV (GPS).
The official FAA airport diagram for Chicago O'Hare Intl is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.
Yes. 14 of the published ILS procedures carry CAT II/III minima, which allow approaches in lower visibility than a standard CAT I ILS. Those plates are listed separately in the approach table above, marked CAT II or CAT III in the chart name.
Yes. Chicago O'Hare Intl has an operating control tower, within Chicago Center's airspace. Tower, ground and clearance frequencies are listed on this page.
10, which is why the chart set is as large as it is — each runway end that supports an instrument approach needs its own plates. The runway diagram on this page shows the layout to scale.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
