Terminal Procedures

KSGR — Sugar Land Rgnl

HOUSTON, TX · 45 FAA charts · cycle 6 Aug 2026

FAA SGRElevation 81 ft1 runwayLongest 8,000 ftToweredFuel 100LL avgas, Jet A+Volume SC-5Not for navigation
KSGR airport diagram — runways, taxiways and ramp layout
KSGR airport diagram The official FAA airport diagram — runways, taxiways, ramp layout and hold-short positions. Download PDF

3 published instrument approaches: 1 ILS approach, 2 RNAV (GPS), serving 2 runway ends.

All 45 KSGR charts in one download Every approach, departure, arrival and minimums page for this airport, sorted into folders, as a single ZIP. Taken one at a time on the free tier, 45 charts is roughly 5 min of downloading — they queue one behind another.
PRO members only

Instrument approach procedures

ChartAmendment
ILS OR LOC RWY 35 chart previewILS OR LOC RWY 355PDF
RNAV (GPS) RWY 17 chart previewRNAV (GPS) RWY 173PDF
RNAV (GPS) RWY 35 chart previewRNAV (GPS) RWY 352BPDF

Departure procedures

ChartAmendment
ALEXANDRIA THREE chart previewALEXANDRIA THREE—PDF
ALEXANDRIA THREE, CONT.1 chart previewALEXANDRIA THREE, CONT.1—PDF
BLTWY SEVEN (RNAV) chart previewBLTWY SEVEN (RNAV)—PDF
BORRN SIX (RNAV) chart previewBORRN SIX (RNAV)—PDF
BORRN SIX (RNAV), CONT.1 chart previewBORRN SIX (RNAV), CONT.1—PDF
CRIED ONE chart previewCRIED ONE—PDF
CRIED ONE, CONT.1 chart previewCRIED ONE, CONT.1—PDF
EL DORADO ONE chart previewEL DORADO ONE—PDF
EL DORADO ONE, CONT.1 chart previewEL DORADO ONE, CONT.1—PDF
GIFFA ONE chart previewGIFFA ONE—PDF
GIFFA ONE, CONT.1 chart previewGIFFA ONE, CONT.1—PDF
HOODO SEVEN (RNAV) chart previewHOODO SEVEN (RNAV)—PDF
INDIE EIGHT (RNAV) chart previewINDIE EIGHT (RNAV)—PDF
KARRR SEVEN (RNAV) chart previewKARRR SEVEN (RNAV)—PDF
KARRR SEVEN (RNAV), CONT.1 chart previewKARRR SEVEN (RNAV), CONT.1—PDF
LEONA FOUR chart previewLEONA FOUR—PDF
LEONA FOUR, CONT.1 chart previewLEONA FOUR, CONT.1—PDF
LUFKIN FOUR chart previewLUFKIN FOUR—PDF
LUFKIN FOUR, CONT.1 chart previewLUFKIN FOUR, CONT.1—PDF
LURIC EIGHT (RNAV) chart previewLURIC EIGHT (RNAV)—PDF
MMALT SEVEN (RNAV) chart previewMMALT SEVEN (RNAV)—PDF
STRYA EIGHT (RNAV) chart previewSTRYA EIGHT (RNAV)—PDF
STYCK EIGHT (RNAV) chart previewSTYCK EIGHT (RNAV)—PDF
WATFO SIX (RNAV) chart previewWATFO SIX (RNAV)—PDF
WYLSN EIGHT (RNAV) chart previewWYLSN EIGHT (RNAV)—PDF

Arrival procedures (STAR)

ChartAmendment
CESAN FOUR (RNAV) chart previewCESAN FOUR (RNAV)—PDF
CESAN FOUR (RNAV), CONT.1 chart previewCESAN FOUR (RNAV), CONT.1—PDF
HUDZY FIVE chart previewHUDZY FIVE—PDF
HUDZY FIVE, CONT.1 chart previewHUDZY FIVE, CONT.1—PDF
OHIIO FOUR chart previewOHIIO FOUR—PDF
SNDAY ONE (RNAV) chart previewSNDAY ONE (RNAV)—PDF
TKNIQ THREE (RNAV) chart previewTKNIQ THREE (RNAV)—PDF
TKNIQ THREE (RNAV), CONT.1 chart previewTKNIQ THREE (RNAV), CONT.1—PDF
TSHRT TWO chart previewTSHRT TWO—PDF
TSHRT TWO, CONT.1 chart previewTSHRT TWO, CONT.1—PDF
WAPPL SEVEN (RNAV) chart previewWAPPL SEVEN (RNAV)—PDF
WAPPL SEVEN (RNAV), CONT.1 chart previewWAPPL SEVEN (RNAV), CONT.1—PDF
WAPPL SEVEN (RNAV), CONT.2 chart previewWAPPL SEVEN (RNAV), CONT.2—PDF

Takeoff and alternate minimums

ChartAmendment
TAKEOFF MINIMUMS chart previewTAKEOFF MINIMUMS—PDF
ALTERNATE MINIMUMS chart previewALTERNATE MINIMUMS—PDF

Minimums pages cover a whole volume, so the same document is shared by every airport in it.

Hot spots

ChartAmendment
HOT SPOT chart previewHOT SPOT—PDF

KSGR airport information

Control tower
Yes
Attendance
All all 0500-2300
ARTCC
Houston Center
Flight service
Montgomery County
NOTAM facility
SGR (NOTAM-D available)
Magnetic variation
5E
Beacon
White-green (lighted land airport), sunset to sunrise
Wind indicator
Lighted
Segmented circle
Yes
Fuel
100LL avgas, Jet A+
Airframe service
Major
Powerplant service
Major
Bottled oxygen
None
Parking
Tie-downs
Landing fee
Yes
Customs
Landing rights airport
Airport area
622 acres
Ownership
Publicly owned
Sectional
Houston
Last FAA inspection
2025-11-04

From the FAA NASR 28-day subscription, cycle 6 Aug 2026.

KSGR radio frequencies

ServiceFrequencyCall sign
CTAF118.65
UNICOM122.95
Ground121.4Sugar Land
Clearance delivery119.25When Twr ClsdSugar Land
ATIS118.125Sugar Land
Approach123.8Sugar Land

Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.

Runways

8,000 × 100 ft1735N1,000 ft
Runway layout at KSGR, drawn to scale from FAA published runway-end coordinates and true alignments. Runways served by an ILS are highlighted.
RunwayLengthWidth SurfaceLighting
17/358,000 ft100 ftConcrete ExcellentHigh intensity
  17 175°TPAPI (2-box) 3.5° · displaced threshold 380 ft
  35 355°TILS/DME · PAPI (4-box) 3° · displaced threshold 1,984 ft

Runway and approach-aid data from the FAA NASR 28-day subscription.

Where KSGR is

Latitude, longitude29.6222490, -95.6565340
Elevation81 ft
From Houston17 nm SW

Paste the coordinates into a simulator’s world map to drop straight onto the field.

FAA remarks for KSGR

  • PRVDD THRS DSPLCD TO MAINTAIN CLEAR 20:1 APCH SLOPE OVER ALL OBSTNS AT RWY ENDS.
  • NITROGEN AVBL DURG BUSINESS HRS.
  • NO TGLS AFT TWR CLOSES.
  • WHEN ATCT CLSD ACTVT REIL RWY 17 & 35; HIRL RWY 17/35 - CTAF.
  • RAMP FEE FOR CIVIL ACFT; WAIVED WITH FUEL PURCHASE.
  • JASU - 1(MD-3) 1(C-26) 1(MA-1A)
  • 10 FT RD 0-57 FT DSTC; 50 FT TREES, 0-100 FT DSTC, 488 FT L.
  • 27 FT RR 90 FT DSTC ON CNTRLN; 17 FT RD, 30 PLINE.
  • OBSTN CLNC SLOPE 14:1 TO DSPLCD THR.
  • OBSTN CLNC SLOPE 50:1 TO DSPLCD THLD OVR 27 FT RR TRACKS 2074 FT DSTC.
  • RWY NOT GRVD.
  • MIL AND CORPORATE GND TRANSPORTATION PRVDD.
  • BIRDS ON & INVOF ARPT.
  • NOISE ABATEMENT PROC: NOISE SENSITIVE AREAS - INFO AVBL AT TRML.
  • NO INT DEPS FOR MULTI-ENGINE ACFT.
  • FOR CD WHEN ATCT IS CLSD CTC HOUSTON APCH AT 281-443-5844 TO CNL IFR AT 281-443-5888.
  • SFC CONDS NOT RPRTD 10:00 PM - 6:00 AM DLY.
  • LRA M-F 0800-1200 & 1300-1700. OTR TIMES BY APPT.

Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.

Instrument coverage

Sugar Land Regional’s chart set is notably departure-heavy: 25 departure charts sit alongside three approach plates. The approach coverage is compact but reaches both ends of the sole runway, with ILS, localiser and RNAV (GPS) options represented. Runway 17/35 provides 8,000 ft on one alignment, with no second runway orientation.

Local chart context

Nearby procedure coverage is generally substantial. William P Hobby has the broadest set, while Houston/Southwest, Houston Executive and West Houston are close to Sugar Land’s total; Pearland Regional is distinctly thinner. The Houston Sectional and Terminal Area Chart add wider VFR and terminal-area context, while the two helicopter route charts show specialised route structures not conveyed by the instrument procedure plates.

Airports near KSGR

IDAirportCity DistanceCharts
KAXHHouston/SouthwestHOUSTON, TX12 nm SE41
KIWSWest HoustonHOUSTON, TX12 nm N38
KTMEHouston ExecHOUSTON, TX17 nm NW39
KHOUWilliam P HobbyHOUSTON, TX20 nm E59
KLVJPearland RgnlHOUSTON, TX22 nm E30
KEFDEllingtonHOUSTON, TX26 nm E57
KDWHDavid Wayne Hooks MemlHOUSTON, TX27 nm N38
KIAHGeorge Bush Intcntl/HoustonHOUSTON, TX27 nm NE102

VFR charts covering KSGR

HoustonHelicopter Route ChartUS Gulf CoastHelicopter Route ChartHoustonSectional ChartHoustonTerminal Area Chart

Common questions about KSGR

What charts are available for KSGR?

45 current FAA charts for Sugar Land Rgnl, including 3 instrument approachs, 25 departure procedures, 13 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.

What are the radio frequencies for KSGR?

Ground 121.4; ATIS 118.125; CTAF 118.65; UNICOM 122.95; Clearance delivery 119.25. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.

How long is the runway at KSGR?

Sugar Land Rgnl has 1 runway. The longest is 17/35 at 8,000 ft by 100 ft, concrete. Full runway dimensions, lighting and approach aids are listed on this page.

Does KSGR have an ILS approach?

Yes — 1 ILS procedure is published. In total KSGR has 3 published instrument approaches, of which 2 are RNAV (GPS).

Where can I download the KSGR airport diagram?

The official FAA airport diagram for Sugar Land Rgnl is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.

Is KSGR a towered airport?

Yes. Sugar Land Rgnl has an operating control tower, within Houston Center's airspace. Tower, ground and clearance frequencies are listed on this page.

Are these KSGR charts current?

They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
