HOUSTON, TX · 41 FAA charts · cycle 6 Aug 2026
3 published instrument approaches: 2 RNAV (GPS), 1 localiser, serving 2 runway ends.
| Chart | Amendment | ||
|---|---|---|---|
 | LOC RWY 09 | 4 | |
 | RNAV (GPS) RWY 09 | 2B | |
 | RNAV (GPS) RWY 27 | 1B |
| Chart | Amendment | ||
|---|---|---|---|
 | TAKEOFF MINIMUMS | — |
Minimums pages cover a whole volume, so the same document is shared by every airport in it.
From the FAA NASR 28-day subscription, cycle 6 Aug 2026.
| Service | Frequency | Call sign |
|---|---|---|
| CTAF | 123.0 | |
| Clearance delivery | 120.8 | Houston |
| Approach | 123.8 | Houston |
Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.
| Runway | Length | Width | Surface | Lighting |
|---|---|---|---|---|
| 09/27 | 5,002 ft | 100 ft | Asphalt Excellent | Medium intensity |
| 09 94°T | LOC/DME · PAPI (2-box) 3.5° | |||
| 27 274°T | PAPI (2-box) 3° | |||
Runway and approach-aid data from the FAA NASR 28-day subscription.
29.5061390, -95.4769170
68 ft15 nm SWPaste the coordinates into a simulator’s world map to drop straight onto the field.
Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.
Houston/Southwest’s 24 departure procedures against three approaches make this a strongly outbound-weighted chart set. The approaches nevertheless serve both ends of the sole 09/27 runway: two use RNAV (GPS), while one uses a localiser. This provides published approach coverage from each runway direction, but a much narrower range of arrival procedures than departure routing. The single 5,002 ft strip also ties every approach to one east–west alignment.
At 41 charts, coverage is close in breadth to Sugar Land Regional and West Houston. William P Hobby and Ellington have broader sets, while Pearland Regional is notably thinner. The Houston Sectional and Terminal Area Chart add wider VFR context, while the two helicopter-route charts provide a dedicated helicopter route picture absent from the instrument procedure collection.
| ID | Airport | City | Distance | Charts |
|---|---|---|---|---|
| KSGR | Sugar Land Rgnl | HOUSTON, TX | 12 nm NW | 45 |
| KLVJ | Pearland Rgnl | HOUSTON, TX | 12 nm E | 30 |
| KHOU | William P Hobby | HOUSTON, TX | 13 nm NE | 59 |
| KEFD | Ellington | HOUSTON, TX | 18 nm E | 57 |
| KIWS | West Houston | HOUSTON, TX | 21 nm NW | 38 |
| T41 | La Porte Muni | LA PORTE, TX | 24 nm NE | 40 |
| KLBX | Texas Gulf Coast Rgnl | ANGLETON/LAKE JACKSON, TX | 24 nm S | 42 |
| KTME | Houston Exec | HOUSTON, TX | 28 nm NW | 39 |
41 current FAA charts for Houston/Southwest, including 3 instrument approachs, 24 departure procedures, 13 arrival procedures. All are free to download as PDFs from this page, from the 6 August 2026 cycle.
CTAF 123.0; Clearance delivery 120.8. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.
Houston/Southwest has 1 runway. The longest is 09/27 at 5,002 ft by 100 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.
No ILS is published. In total KAXH has 3 published instrument approaches, of which 2 are RNAV (GPS).
No — Houston/Southwest has no control tower. Traffic co-ordinates on a common frequency rather than with a controller, which is listed in the frequencies table on this page.
They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
