KFLL — Fort Lauderdale/Hollywood Intl

FORT LAUDERDALE, FL · 56 FAA charts · cycle 6 Aug 2026

FAA FLLElevation 65 ft2 runwaysLongest 9,000 ftToweredFuel 100LL avgas, Jet AVolume SE-3Not for navigation
KFLL airport diagram — runways, taxiways and ramp layout
KFLL airport diagram The official FAA airport diagram — runways, taxiways, ramp layout and hold-short positions. Download PDF

10 published instrument approaches: 4 ILS approaches, 6 RNAV (GPS), serving 4 runway ends.

All 56 KFLL charts in one download Every approach, departure, arrival and minimums page for this airport, sorted into folders, as a single ZIP. Taken one at a time on the free tier, 56 charts is roughly 6 min of downloading — they queue one behind another.
PRO members only

Instrument approach procedures

ChartAmendment
ILS OR LOC RWY 10L chart previewILS OR LOC RWY 10L25PDF
ILS OR LOC RWY 10R chart previewILS OR LOC RWY 10R2PDF
ILS OR LOC RWY 28L chart previewILS OR LOC RWY 28L2PDF
ILS OR LOC RWY 28R chart previewILS OR LOC RWY 28R12PDF
RNAV (GPS) RWY 10R chart previewRNAV (GPS) RWY 10R2PDF
RNAV (GPS) RWY 28L chart previewRNAV (GPS) RWY 28L2PDF
RNAV (GPS) Y RWY 28R chart previewRNAV (GPS) Y RWY 28R5APDF
RNAV (GPS) Z RWY 10L chart previewRNAV (GPS) Z RWY 10L5PDF
RNAV (RNP) Y RWY 10L chart previewRNAV (RNP) Y RWY 10L2PDF
RNAV (RNP) Z RWY 28R chart previewRNAV (RNP) Z RWY 28R2PDF

Departure procedures

ChartAmendment
AGERS ONE (RNAV) chart previewAGERS ONE (RNAV)—PDF
AGERS ONE (RNAV), CONT.1 chart previewAGERS ONE (RNAV), CONT.1—PDF
BNICE TWO (RNAV) chart previewBNICE TWO (RNAV)—PDF
BNICE TWO (RNAV), CONT.1 chart previewBNICE TWO (RNAV), CONT.1—PDF
DORRL TWO (RNAV) chart previewDORRL TWO (RNAV)—PDF
FEALX TWO (RNAV) chart previewFEALX TWO (RNAV)—PDF
FEALX TWO (RNAV), CONT.1 chart previewFEALX TWO (RNAV), CONT.1—PDF
FEALX TWO (RNAV), CONT.2 chart previewFEALX TWO (RNAV), CONT.2—PDF
FORT LAUDERDALE TWO chart previewFORT LAUDERDALE TWO—PDF
FORT LAUDERDALE TWO, CONT.1 chart previewFORT LAUDERDALE TWO, CONT.1—PDF
FRSBE TWO (RNAV) chart previewFRSBE TWO (RNAV)—PDF
GLADZ FOUR (RNAV) chart previewGLADZ FOUR (RNAV)—PDF
GLADZ FOUR (RNAV), CONT.1 chart previewGLADZ FOUR (RNAV), CONT.1—PDF
GLADZ FOUR (RNAV), CONT.2 chart previewGLADZ FOUR (RNAV), CONT.2—PDF
HROCK TWO (RNAV) chart previewHROCK TWO (RNAV)—PDF
HROCK TWO (RNAV), CONT.1 chart previewHROCK TWO (RNAV), CONT.1—PDF
LIFRR TWO (RNAV) chart previewLIFRR TWO (RNAV)—PDF
LIFRR TWO (RNAV), CONT.1 chart previewLIFRR TWO (RNAV), CONT.1—PDF
MAYNR THREE (RNAV) chart previewMAYNR THREE (RNAV)—PDF
MAYNR THREE (RNAV), CONT.1 chart previewMAYNR THREE (RNAV), CONT.1—PDF
REGAE TWO (RNAV) chart previewREGAE TWO (RNAV)—PDF
SNAPR TWO (RNAV) chart previewSNAPR TWO (RNAV)—PDF
SNAPR TWO (RNAV), CONT.1 chart previewSNAPR TWO (RNAV), CONT.1—PDF

Arrival procedures (STAR)

ChartAmendment
BHHIA THREE (RNAV) chart previewBHHIA THREE (RNAV)—PDF
BHHIA THREE (RNAV), CONT.1 chart previewBHHIA THREE (RNAV), CONT.1—PDF
BHHIA THREE (RNAV), CONT.2 chart previewBHHIA THREE (RNAV), CONT.2—PDF
CUUDA THREE (RNAV) chart previewCUUDA THREE (RNAV)—PDF
CUUDA THREE (RNAV), CONT.1 chart previewCUUDA THREE (RNAV), CONT.1—PDF
DEKAL NINE chart previewDEKAL NINE—PDF
DVALL FOUR chart previewDVALL FOUR—PDF
FORTL NINE chart previewFORTL NINE—PDF
KYAKS THREE (RNAV) chart previewKYAKS THREE (RNAV)—PDF
KYAKS THREE (RNAV), CONT.1 chart previewKYAKS THREE (RNAV), CONT.1—PDF
OLAHS THREE (RNAV) chart previewOLAHS THREE (RNAV)—PDF
OLAHS THREE (RNAV), CONT.1 chart previewOLAHS THREE (RNAV), CONT.1—PDF
OLAHS THREE (RNAV), CONT.2 chart previewOLAHS THREE (RNAV), CONT.2—PDF
TARPN THREE (RNAV) chart previewTARPN THREE (RNAV)—PDF
TEEKY FOUR (RNAV) chart previewTEEKY FOUR (RNAV)—PDF
TEEKY FOUR (RNAV), CONT.1 chart previewTEEKY FOUR (RNAV), CONT.1—PDF
TOREZ ONE (RNAV) chart previewTOREZ ONE (RNAV)—PDF

Takeoff and alternate minimums

ChartAmendment
TAKEOFF MINIMUMS chart previewTAKEOFF MINIMUMS—PDF
ALTERNATE MINIMUMS chart previewALTERNATE MINIMUMS—PDF

Minimums pages cover a whole volume, so the same document is shared by every airport in it.

Hot spots

ChartAmendment
HOT SPOT chart previewHOT SPOT—PDF

Diverse vector area

ChartAmendment
RNAV DP AAUP chart previewRNAV DP AAUP—PDF
RNAV DP AAUP, CONT.1 chart previewRNAV DP AAUP, CONT.1—PDF

KFLL airport information

Control tower
Yes
Attendance
Continuous
ARTCC
Miami Center
Flight service
Miami
NOTAM facility
FLL (NOTAM-D available)
Magnetic variation
6W
Beacon
White-green (lighted land airport), sunset to sunrise
Wind indicator
Yes
ARFF index
Index E
Fuel
100LL avgas, Jet A
Airframe service
Major
Powerplant service
Major
Bottled oxygen
High/low
Parking
Tie-downs
Customs
Landing rights airport
Activated
April 1940
Airport area
1,380 acres
Ownership
Publicly owned
Sectional
Miami
Last FAA inspection
2026-02-14

From the FAA NASR 28-day subscription, cycle 6 Aug 2026.

KFLL radio frequencies

ServiceFrequencyCall sign
UNICOM122.95
Tower119.3120.2Fort Lauderdale
Ground121.4121.7Fort Lauderdale
Clearance delivery128.4Fort Lauderdale
ATIS135.0Fort Lauderdale
Approach118.1271-090 Blw 4000 Ft126.855000 Ft And Abv133.775271-090 4000 Ft & AbvFort Lauderdale
Departure119.7271-090 Blw 4000 Ft126.05271-090 4000 Ft & Abv128.6Fort Lauderdale

Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.

Runways

9,000 × 150 ft10L28R8,000 × 150 ft10R28LN3,000 ft
Runway layout at KFLL, drawn to scale from FAA published runway-end coordinates and true alignments. Runways served by an ILS are highlighted.
RunwayLengthWidth SurfaceLighting
10L/28R9,000 ft150 ftAsphalt over concrete ExcellentHigh intensity
  10L 90°TILS/DME · PAPI (4-box) 3° · MALSR approach lighting · displaced threshold 576 ft
  28R 270°TILS/DME · PAPI (4-box) 3° · MALSR approach lighting · displaced threshold 606 ft · right-hand circuit
10R/28L8,000 ft150 ftConcrete ExcellentHigh intensity
  10R 90°TILS/DME · PAPI (4-box) 3° · MALSF approach lighting · right-hand circuit
  28L 270°TILS/DME · PAPI (4-box) 3° · MALSF approach lighting

Runway and approach-aid data from the FAA NASR 28-day subscription.

Where KFLL is

Latitude, longitude26.0716670, -80.1496940
Elevation65 ft
From Fort Lauderdale3 nm SW

Paste the coordinates into a simulator’s world map to drop straight onto the field.

FAA remarks for KFLL

  • CLSD TO ACR TRAINING.
  • ST 175
  • PCR VALUE: 930/R/A/W/T
  • PCR VALUE: 820/R/A/W/T
  • RWY 10R MALSF NSTD; 370 FT GAP BTN 8+00 & STATION 11+70.
  • +8 FT FENCE 200 FT FM THR & 400 FT R; 40 FT LGT POLES PARL TO RWY BTN TWY Q & A-4 650 FT N.
  • APCH RATIO 50:1 TO DSPLCD THR.
  • APCH RATIO 32:1 TO DSPLCD THR; +43 FT LGTD POLE 1414 FT FM THR 75 FT R; APCH RATIO 46:1.
  • RWY 10R/28L NRS UNGROOVED AREAS.
  • ALL RWYS NOISE SENSITIVE; NOISE ABATEMENT IN EFCT - 954-359-6181.
  • JET RUNUPS NA 2300-0700.
  • BIRDS ON & INVOF ARPT; CONCENTRATION OF BIRDS BLW 500 FT 2.0 NM W OF 10L & 10R AER.
  • PPR FOR ACFT WITH EXPLOSIVES.
  • TWY E BTN TWY C & TWY L CLSD TO ACFT WINGSPAN MORE THAN 118 FT EXC 10 MIN PPR 954-816-3179.
  • ARR FM N & W MNTN 6000 FT UNTIL ABM RWY 28R ON DOWNWIND; ARR FM N MNTN 6000 FT UNTIL ABM RWY 10L ON DOWNWIND.
  • NO VFR APCHS OR BASE LEGS UNTIL OFFSHORE.
  • IR CARRIER ACFT USE RAMP PUSH BACK PROCS PRESCRIBED BY ARPT OPS.
  • EAST SIDE OF CONCOURSE B AVBL TO ACFT WITH WINGSPAN LESS THAN 124.9 FT.
  • ACFT OPRG FROM TRML 1, 2, 3, 4 MUST CTC RAMP CTL. RAMP CTL EFF - CTC ARPT OPS FOR HRS.
  • TURB BLW 1000 FT OVR LANDFILL LCTD 2 NM W.
  • TWY J BGN TO ELEV 900 FT EAST OF TWY Q. DUE TO ELEV ALL ACFT REMAIN ON CNTRLN; TWY T8 & TAXILANE T NOT ACCESSIBLE FM TWY J.
  • RWY STATUS LIGHTS IN OPRN.
  • ACFT LDG RWY 10R & EXITING J9 FOLLOW TWY LEAD OFF LINE ONTO J9.
  • PREFERENTIAL RWY USE PROGRAM IN EFCT; CTC NOISE ABATEMENT OFFICE.
  • NMRS TREES SW QUADRANT OF ARPT.
  • HIGH LIGHT MASTS WNW APCH END RWY 28L.
  • APN TWY T EAST OF TWY T8 CLSD TO ACFT WINGSPAN MORE THAN 118 FT AND TAIL HEIGHT MORE THAN 45FT EXC ACFT UNDER TOW.
  • TXL T BTN T7 AND T8 CLSD TO ACFT WINGSPAN MORE THAN 171 FT.
  • DO NOT MISTAKE TWY B FOR LNDG/TKOF SFC.
  • RWY 10L/28R NRS UNGROOVED AREAS.
  • DO NOT MISTAKE TAXIWAY B FOR LANDING/TAKEOFF SURFACE.
  • TWY B E OF TWY B12 & TXL T E OF TWY T1 CLSD TO ACFT WITH WINGSPAN GTR THAN 118 FT & TAIL HGT GTR THAN 45 FT EXC PPR 954-816-3179.
  • 24 HOUR PPR FOR ACFT EQUIPPED WITH WEATHER MODIFICATION OR GEOENGINEERING EQUIPMENT 954-816-3179

Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.

Procedure coverage

At Fort Lauderdale/Hollywood International, instrument approaches serve all four runway ends, so the procedure set is not concentrated on one direction. ILS, RNAV (GPS) and localiser options are represented, while the large body of departure and arrival charts shows that routing into and away from the runway environment forms much of the published coverage. At 9,000 and 8,000 ft, the parallel runways differ by only 1,000 ft; the second is not a markedly shorter strip.

Surrounding chart context

Miami International has a broader procedure set, while Miami-Opa Locka Executive, Pompano Beach Airpark and Fort Lauderdale Executive also have substantial coverage. North Perry’s set is much thinner. The Miami Terminal Area Chart adds detailed local VFR context, the Miami Sectional broadens the regional view, and Caribbean 1 extends that VFR coverage beyond the immediate terminal area.

Airports near KFLL

IDAirportCity DistanceCharts
KHWONorth PerryHOLLYWOOD, FL6 nm SW13
KFXEFort Lauderdale ExecFORT LAUDERDALE, FL8 nm N40
KPMPPompano Beach AirparkPOMPANO BEACH, FL11 nm N41
KOPFMiami-Opa Locka ExecMIAMI, FL12 nm SW44
KMIAMiami IntlMIAMI, FL18 nm SW75
KBCTBoca RatonBOCA RATON, FL19 nm N23
KTMBMiami ExecMIAMI, FL30 nm SW39
KLNAPalm Beach County ParkWEST PALM BEACH, FL31 nm N10

VFR charts covering KFLL

Caribbean 1Caribbean ChartMiamiSectional ChartMiamiTerminal Area Chart

Common questions about KFLL

What charts are available for KFLL?

56 current FAA charts for Fort Lauderdale/Hollywood Intl, including 10 instrument approachs, 23 departure procedures, 17 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.

What are the radio frequencies for KFLL?

Tower 119.3, 120.2; Ground 121.4, 121.7; ATIS 135.0; UNICOM 122.95; Clearance delivery 128.4. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.

How long is the runway at KFLL?

Fort Lauderdale/Hollywood Intl has 2 runways. The longest is 10L/28R at 9,000 ft by 150 ft, asphalt over concrete. Full runway dimensions, lighting and approach aids are listed on this page.

Does KFLL have an ILS approach?

Yes — 4 ILS procedures are published. In total KFLL has 10 published instrument approaches, of which 6 are RNAV (GPS).

Where can I download the KFLL airport diagram?

The official FAA airport diagram for Fort Lauderdale/Hollywood Intl is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.

Is KFLL a towered airport?

Yes. Fort Lauderdale/Hollywood Intl has an operating control tower, within Miami Center's airspace. Tower, ground and clearance frequencies are listed on this page.

Are these KFLL charts current?

They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.

Wider chart sets

This airport56 chartsEvery KFLL plate, one ZIP
All of Florida934 charts189.2 MB · every airport in the stateEvery US airport16,522 charts3.51 GB · the whole country offline

Bulk archives are a PRO benefit. Individual charts are free for everyone, always.

Flying into KFLL? PRO members take all 56 charts as one ZIP instead of 56 separate downloads, at full line speed with no cap — plus every chart family archive and all 24,000+ add-ons in the library.

Go PRO
Ian StephensReviewed by Ian Stephens · Editor-in-ChiefChart sourcing and page templates reviewed for accuracy. The charts themselves are unmodified FAA publications.

Not for navigation. For flight simulation and reference use only. Procedures are superseded on a 28-day cycle — obtain current official charts from the FAA for real-world flight.
