Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 36.6 MB | Download |
| Print-ready chart, no georeferencing | 76.9 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 76.9 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROFrom the Yucatán Peninsula and Central American coast to Hispaniola, this sheet brings the western Caribbean’s main island groups and surrounding waters into one view. Coverage includes Cuba, Jamaica, the Cayman Islands, much of the Bahamas, the Turks and Caicos area, and the shores of Belize and Honduras. Its northern reach takes in the Straits of Florida, while the southern edge approaches the western Caribbean coast near the Honduras–Nicaragua border.
The region combines long overwater sectors with sharp contrasts in landform. Cuba, Jamaica and Hispaniola present substantial mountainous interiors, while the Bahamas, Cayman Islands and parts of the Yucatán are markedly lower and flatter. Narrow passages, scattered islands and extended coastlines make the sheet particularly useful for planning routes that move repeatedly between open water and land. Coverage continues eastwards on Caribbean 2, making the adjoining sheet relevant for journeys beyond Hispaniola and the eastern edge of this chart.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| KMIA MIA | Miami Intl | MIAMI, FL | 9 ft | 4 | 13,016 ft |
| KRSW RSW | Southwest Florida Intl | FORT MYERS, FL | 29 ft | 1 | 12,000 ft |
| MYNN | Lynden Pindling Intl | NASSAU | 16 ft | 2 | 11,107 ft |
| MYGF | Grand Bahama Intl | FREEPORT | 6 ft | 1 | 11,018 ft |
| KTNT TNT | Dade-Collier Training And Transition | MIAMI, FL | 12 ft | 1 | 10,499 ft |
| KDJT DJT | President Donald J Trump Intl | WEST PALM BEACH, FL | 19 ft | 3 | 10,001 ft |
| KSRQ SRQ | Sarasota/Bradenton Intl | SARASOTA/BRADENTON, FL | 29 ft | 2 | 9,500 ft |
| KFLL FLL | Fort Lauderdale/Hollywood Intl | FORT LAUDERDALE, FL | 65 ft | 2 | 9,000 ft |
| MYEM | Governors Harbour | GOVERNORS HARBOUR | 27 ft | 1 | 8,035 ft |
| KOPF OPF | Miami-Opa Locka Exec | MIAMI, FL | 8 ft | 3 | 8,002 ft |
| MYSM | San Salvador Intl | COCKBURN TOWN | 24 ft | 1 | 8,000 ft |
| MBPV | Providenciales Intl | PROVIDENCIALES | 13 ft | 1 | 7,598 ft |
| MYER | Rock Sound | ROCK SOUND | 16 ft | 1 | 7,213 ft |
| KPGD PGD | Punta Gorda | PUNTA GORDA, FL | 25 ft | 3 | 7,193 ft |
| MYIG | Matthew Town | MATTHEW TOWN | 17 ft | 1 | 7,020 ft |
| MYAT | Treasure Cay | TREASURE CAY | 10 ft | 1 | 7,001 ft |
| MYCA | Arthurs Town | ARTHURS TOWN | 18 ft | 1 | 7,000 ft |
| MYEF | Exuma Intl | GEORGE TOWN | 9 ft | 1 | 7,000 ft |
| MYMM | Mayaguana | ABRAHAMS BAY | 11 ft | 1 | 6,700 ft |
| KAPF APF | Naples Muni | NAPLES, FL | 8 ft | 3 | 6,600 ft |
| KFPR FPR | Treasure Coast Intl | FORT PIERCE, FL | 23 ft | 3 | 6,492 ft |
| KFMY FMY | Page Fld | FORT MYERS, FL | 17 ft | 2 | 6,406 ft |
| X58 | Indiantown | INDIANTOWN, FL | 30 ft | 1 | 6,300 ft |
| KBCT BCT | Boca Raton | BOCA RATON, FL | 12 ft | 1 | 6,276 ft |
| MYAM | Leonard M Thompson Intl | MARSH HARBOUR | 8 ft | 1 | 6,100 ft |
| MYEH | North Eleuthera | NORTH ELEUTHERA | 27 ft | 1 | 6,019 ft |
| KFXE FXE | Fort Lauderdale Exec | FORT LAUDERDALE, FL | 13 ft | 2 | 6,002 ft |
| KTMB TMB | Miami Exec | MIAMI, FL | 10 ft | 4 | 6,000 ft |
| 2IS | Airglades | CLEWISTON, FL | 20 ft | 1 | 5,902 ft |
| KSUA SUA | Witham Fld | STUART, FL | 16 ft | 3 | 5,828 ft |
| KVNC VNC | Venice Muni | VENICE, FL | 18 ft | 2 | 5,640 ft |
| MYBS | South Bimini | SOUTH BIMINI | 8 ft | 1 | 5,391 ft |
| MYAK | Congo Town | CONGO TOWN | 20 ft | 1 | 5,321 ft |
| X14 | La Belle Muni | LA BELLE, FL | 20 ft | 1 | 5,254 ft |
| KSEF SEF | Sebring Rgnl | SEBRING, FL | 61 ft | 2 | 5,234 ft |
| KEYW EYW | Key West Intl | KEY WEST, FL | 3 ft | 1 | 5,076 ft |
| MYAB | Clarence A Bain | MANGROVE CAY | 12 ft | 1 | 5,015 ft |
| MYAP | Spring Point | SPRING POINT | 12 ft | 1 | 5,010 ft |
| KMTH MTH | The Florida Keys Marathon Intl | MARATHON, FL | 7 ft | 1 | 5,008 ft |
| MYAN | San Andros | NICHOLLS TOWN | 10 ft | 1 | 5,002 ft |
| KIMM IMM | Immokalee Rgnl | IMMOKALEE, FL | 37 ft | 2 | 5,000 ft |
| KMKY MKY | Marco Island Exec | MARCO ISLAND, FL | 5 ft | 1 | 5,000 ft |
| KOBE OBE | Okeechobee County | OKEECHOBEE, FL | 33 ft | 2 | 5,000 ft |
| MYCB | New Bight | NEW BIGHT | 13 ft | 1 | 4,980 ft |
| KPMP PMP | Pompano Beach Airpark | POMPANO BEACH, FL | 19 ft | 3 | 4,918 ft |
| MYBG | Great Harbour Cay | BULLOCKS HARBOUR | 23 ft | 1 | 4,536 ft |
| MYAS | Sandy Point | SANDY POINT | 8 ft | 1 | 4,500 ft |
| MYRP | New Port Nelson | PORT NELSON | 9 ft | 1 | 4,470 ft |
| MYAF | Fresh Creek | FRESH CREEK | 11 ft | 1 | 4,362 ft |
| F45 | North Palm Beach County General Aviation | WEST PALM BEACH, FL | 22 ft | 3 | 4,300 ft |
| MBNC | North Caicos Intl | BOTTLE CREEK AND WHITBY | 12 ft | 1 | 4,193 ft |
| KPHK PHK | Palm Beach County Glades | PAHOKEE, FL | 15 ft | 1 | 4,116 ft |
| MYLD | Deadmans Cay | DEADMANS CAY | 10 ft | 1 | 4,042 ft |
| MYLS | Stella Maris | STELLA MARIS | 10 ft | 1 | 4,019 ft |
| KCHN CHN | Wauchula Muni | WAUCHULA, FL | 107 ft | 1 | 4,005 ft |
| X51 | Miami Homestead General Aviation | HOMESTEAD, FL | 7 ft | 3 | 4,001 ft |
| X06 | Arcadia Muni | ARCADIA, FL | 63 ft | 2 | 3,700 ft |
| MYCI | Colonel Hill | COLONEL HILL | 5 ft | 1 | 3,500 ft |
| KLNA LNA | Palm Beach County Park | WEST PALM BEACH, FL | 14 ft | 3 | 3,489 ft |
| KHWO HWO | North Perry | HOLLYWOOD, FL | 8 ft | 4 | 3,463 ft |
| X10 | Belle Glade State Muni | BELLE GLADE, FL | 10 ft | 1 | 3,449 ft |
| MYES | Staniel Cay | STANIEL CAY | 5 ft | 1 | 3,030 ft |
| F13 | Shell Creek Airpark | PUNTA GORDA, FL | 20 ft | 1 | 2,600 ft |
| X01 | Everglades Airpark | EVERGLADES CITY, FL | 4 ft | 1 | 2,400 ft |
| X36 | Buchan | ENGLEWOOD, FL | 15 ft | 1 | 2,040 ft |
65 public-use airports within this chart's coverage, ordered by runway length. A further 90 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Florida is available as a single 189.2 MB archive (934 charts) — see the Florida airports.
It spans 14.8°N to 27.5°N and 87.0°W to 71.7°W. Airports on the sheet fall within Florida. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (36.6 MB). Take the PDF to print it or read it on a second screen (76.9 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Caribbean 2 to the east. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
FAA public-domain products, mirrored unmodified. Fly Away Simulation is not affiliated with or endorsed by the FAA. Chart licensing and terms.
