Terminal Procedures

KSNA — John Wayne/Orange County

SANTA ANA, CA · 41 FAA charts · cycle 6 Aug 2026

FAA SNAElevation 55 ft3 runwaysLongest 5,700 ftToweredFuel 100LL avgas, Jet AVolume SW-3Not for navigation
KSNA airport diagram — runways, taxiways and ramp layout
KSNA airport diagram The official FAA airport diagram — runways, taxiways, ramp layout and hold-short positions. Download PDF

8 published instrument approaches: 2 ILS approaches, 4 RNAV (GPS), serving 2 runway ends.

All 41 KSNA charts in one download Every approach, departure, arrival and minimums page for this airport, sorted into folders, as a single ZIP. Taken one at a time on the free tier, 41 charts is roughly 4 min of downloading — they queue one behind another.
PRO members only

Instrument approach procedures

ChartAmendment
ILS OR LOC RWY 20R chart previewILS OR LOC RWY 20R14CPDF
ILS RWY 20R (SA CAT I) chart previewILS RWY 20R (SA CAT I)14CPDF
LDA RWY 20R chart previewLDA RWY 20R2BPDF
LOC BC RWY 02L chart previewLOC BC RWY 02L14APDF
RNAV (GPS) Y RWY 02L chart previewRNAV (GPS) Y RWY 02L4PDF
RNAV (GPS) Y RWY 20R chart previewRNAV (GPS) Y RWY 20R4PDF
RNAV (RNP) Z RWY 02L chart previewRNAV (RNP) Z RWY 02L0APDF
RNAV (RNP) Z RWY 20R chart previewRNAV (RNP) Z RWY 20R3PDF

Departure procedures

ChartAmendment
ANAHEIM TWO chart previewANAHEIM TWO—PDF
ANAHEIM TWO, CONT.1 chart previewANAHEIM TWO, CONT.1—PDF
CHANNEL THREE chart previewCHANNEL THREE—PDF
EL TORO FIVE chart previewEL TORO FIVE—PDF
EL TORO FIVE, CONT.1 chart previewEL TORO FIVE, CONT.1—PDF
FINZZ THREE (RNAV) chart previewFINZZ THREE (RNAV)—PDF
HAWWC THREE (RNAV) chart previewHAWWC THREE (RNAV)—PDF
HHERO THREE (RNAV) chart previewHHERO THREE (RNAV)—PDF
HOBOW THREE (RNAV) chart previewHOBOW THREE (RNAV)—PDF
IRVINE FIVE chart previewIRVINE FIVE—PDF
IRVINE FIVE, CONT.1 chart previewIRVINE FIVE, CONT.1—PDF
MIKAA ONE (RNAV) chart previewMIKAA ONE (RNAV)—PDF
MUSEL EIGHT chart previewMUSEL EIGHT—PDF
PIGGN THREE (RNAV) chart previewPIGGN THREE (RNAV)—PDF
PIGGN THREE (RNAV), CONT.1 chart previewPIGGN THREE (RNAV), CONT.1—PDF
STAYY FOUR (RNAV) chart previewSTAYY FOUR (RNAV)—PDF
STAYY FOUR (RNAV), CONT.1 chart previewSTAYY FOUR (RNAV), CONT.1—PDF

Arrival procedures (STAR)

ChartAmendment
DSNEE SIX (RNAV) chart previewDSNEE SIX (RNAV)—PDF
DSNEE SIX (RNAV), CONT.1 chart previewDSNEE SIX (RNAV), CONT.1—PDF
EMMLN THREE chart previewEMMLN THREE—PDF
EMMLN THREE, CONT.1 chart previewEMMLN THREE, CONT.1—PDF
KAYOH EIGHT chart previewKAYOH EIGHT—PDF
OHSEA THREE (RNAV) chart previewOHSEA THREE (RNAV)—PDF
OHSEA THREE (RNAV), CONT.1 chart previewOHSEA THREE (RNAV), CONT.1—PDF
ROOBY THREE (RNAV) chart previewROOBY THREE (RNAV)—PDF
ROOBY THREE (RNAV), CONT.1 chart previewROOBY THREE (RNAV), CONT.1—PDF
RUKKI ONE (RNAV) chart previewRUKKI ONE (RNAV)—PDF
TANDY SIX chart previewTANDY SIX—PDF
TANDY SIX, CONT.1 chart previewTANDY SIX, CONT.1—PDF

Takeoff and alternate minimums

ChartAmendment
TAKEOFF MINIMUMS chart previewTAKEOFF MINIMUMS—PDF
ALTERNATE MINIMUMS chart previewALTERNATE MINIMUMS—PDF

Minimums pages cover a whole volume, so the same document is shared by every airport in it.

Hot spots

ChartAmendment
HOT SPOT chart previewHOT SPOT—PDF

KSNA airport information

Control tower
Yes
Attendance
Continuous
ARTCC
Los Angeles Center
Flight service
Riverside
NOTAM facility
SNA (NOTAM-D available)
Magnetic variation
12E
Beacon
White-green (lighted land airport), sunset to sunrise
Wind indicator
Lighted
Segmented circle
Yes
ARFF index
Index C
Fuel
100LL avgas, Jet A
Airframe service
Major
Powerplant service
Major
Bottled oxygen
High/low
Parking
Tie-downs
Customs
Landing rights airport
Activated
November 1941
Airport area
510 acres
Ownership
Publicly owned
Sectional
Los Angeles
Last FAA inspection
2024-05-15

From the FAA NASR 28-day subscription, cycle 6 Aug 2026.

KSNA radio frequencies

ServiceFrequencyCall sign
CTAF126.8
UNICOM122.95
Tower119.9Rwy 02r/20l128.35John Wayne
Ground120.8132.25John Wayne
Clearance delivery118.0121.85John Wayne
ATIS126.0John Wayne
Approach121.3John Wayne
Departure128.1132.7John Wayne

Civil VHF frequencies from the FAA NASR 28-day subscription. Discrete sector and military frequencies are not listed.

Runways

5,700 × 150 ft02L20R2,886 × 75 ft02R20LN1,000 ft
Runway layout at KSNA, drawn to scale from FAA published runway-end coordinates and true alignments. Runways served by an ILS are highlighted.
RunwayLengthWidth SurfaceLighting
02L/20R5,700 ft150 ftAsphalt GoodHigh intensity
  02L 28°TPAPI (4-box) 3°
  20R 208°TILS/DME · PAPI (4-box) 3° · MALSR approach lighting · right-hand circuit
02R/20L2,886 ft75 ftAsphalt GoodMedium intensity
  02R 28°Tright-hand circuit
  20L 208°TPAPI (4-box) 3°
20X——
  20XLDA/DME

Runway and approach-aid data from the FAA NASR 28-day subscription.

Where KSNA is

Latitude, longitude33.6756620, -117.8682330
Elevation55 ft
From Santa Ana4 nm S

Paste the coordinates into a simulator’s world map to drop straight onto the field.

FAA remarks for KSNA

  • WHEN ATCT CLSD ACTVT MALSR RY 20R & PAPI RYS 02L & 20R - CTAF.
  • OVERNIGHT TIE-DOWN FEE.
  • RON MCCLELLAN, MGR, AIRSIDE OPNS 949-252-5247.
  • PCR VALUE: 602/F/A/X/T
  • RWY 02R/20L NOT AVBL FOR PART 121/PART 380 OPS WITH SKED PAX CARRYING OPS MORE THAN 9 PAX SEATS AND NON-SKED PAX CARRYING OPS MORE THAN 30 PAX SEATS. RWY 02R/20L CLSD WHEN ATCT CLSD.
  • RY 20X CREATED TO SUPPORT OJW LDA ASSOCIATED WITH SNA ILS RY 20R.
  • WHEN ATCT CLSD NO LCL TRNG OR TOUCH & GO OPNS.
  • BE ALERT TO BIRDS ON AND IN VICINITY OF ARPT.
  • TWY C GWT LMTD 60000 LBS.
  • MAINTAIN AT OR ABOVE 300 FT AGL UNTIL ESTABLISHED ON FINAL .
  • FBO GENERAL AVIATION APRONS LIMITED TO MAX GWT OF 100,000 LBS (DUAL GEAR) AND WITH WINGSPANS LESS THAN 100 FT. GENERAL AVIATION AIRCRAFT PROHIBITED FROM USING ANY PORTION OF THE AIR CARRIER COMMERCIAL RAMP.
  • NOISE ABATEMENT PROCEDURES IN EFFECT CTC ARPT NOISE OFFICE (949) 252-5185.
  • RWY 02L/20R TPA 1000 FT AGL SMALL ACFT; 1500 FT AGL TURBINE ACFT OVER 12500 LBS; RWY 02R/20L TPA 800 FT AGL SMALL SGL ENG ACFT; 1000 FT AGL TWIN ENG ACFT.
  • FOR CD WHEN ATCT CLSD CTC SOCAL APCH AT 800-448-3724.
  • ACFT LDG RWY 20L, USE CTN FOR JET BLAST FROM ACFT HLDG BTN RWY 20L AND RWY 20R AT TWY L AND CTN WAKE TURB FROM JET ACFT LDG RWY 20R.
  • VFR ACFT: TO AVOID OVERFLIGHT OF RWY 20R, RWY 20L ARRS FLY FINAL AT 15 DEG ANGLE TO RWY; RWY 20L DEPS TURN 15 DEGS LEFT AT DEP END OF RWY. TO AVOID OVERFLIGHT OF RWY 02L, RWY 02R DEPS TURN 15 DEGS RIGHT AT DEP END OF RWY.
  • CTC GND CTL PRIOR TO PUSHBACK ON TWY A AND TWY B.

Published verbatim from the FAA NASR subscription. Abbreviations are the FAA's own.

Procedure pattern

John Wayne/Orange County’s eight approaches serve only two runway ends, concentrating instrument arrivals rather than covering every available direction. The mix of two ILS, two localiser and four RNAV (GPS) procedures provides both precision and non-precision options. With 17 departure charts against eight approaches, the procedure set is notably weighted towards outbound routing.

Runways and surrounding coverage

The 5,700 ft 02L/20R is almost twice the length of parallel 02R/20L, so the two runways do not offer equivalent usable length. Among nearby fields, Long Beach has the only similarly broad chart collection; Los Alamitos, Fullerton, Corona and Chino have much thinner coverage. The Los Angeles sectional, terminal area and helicopter route charts add wider visual, terminal and helicopter-routing context beyond the airport-specific procedures.

Airports near KSNA

IDAirportCity DistanceCharts
KSLILos Alamitos AAFLOS ALAMITOS, CA11 nm NW10
KFULFullerton MuniFULLERTON, CA13 nm NW12
KLGBLong Beach (Daugherty Fld)LONG BEACH, CA17 nm NW31
KAJOCorona MuniCORONA, CA19 nm NE7
KCNOChinoCHINO, CA21 nm NE10
KTOAZamperini FldTORRANCE, CA25 nm W12
KPOCBrackett FldLA VERNE, CA25 nm N11
KEMTSan Gabriel ValleyEL MONTE, CA26 nm N9

VFR charts covering KSNA

Los AngelesHelicopter Route ChartLos AngelesSectional ChartLos AngelesTerminal Area Chart

Common questions about KSNA

What charts are available for KSNA?

41 current FAA charts for John Wayne/Orange County, including 8 instrument approachs, 17 departure procedures, 12 arrival procedures, 1 airport diagram. All are free to download as PDFs from this page, from the 6 August 2026 cycle.

What are the radio frequencies for KSNA?

Tower 119.9, 128.35; Ground 120.8, 132.25; ATIS 126.0; CTAF 126.8; UNICOM 122.95; Clearance delivery 118.0, 121.85. Full civil VHF list, with sector notes, is in the frequencies table on this page — from the FAA NASR subscription.

How long is the runway at KSNA?

John Wayne/Orange County has 3 runways. The longest is 02L/20R at 5,700 ft by 150 ft, asphalt. Full runway dimensions, lighting and approach aids are listed on this page.

Does KSNA have an ILS approach?

Yes — 2 ILS procedures are published. In total KSNA has 8 published instrument approaches, of which 4 are RNAV (GPS).

Where can I download the KSNA airport diagram?

The official FAA airport diagram for John Wayne/Orange County is free to download at the top of this page. It shows runways, taxiways, ramp layout and hold-short positions, and is reissued every 28 days.

Is KSNA a towered airport?

Yes. John Wayne/Orange County has an operating control tower, within Los Angeles Center's airspace. Tower, ground and clearance frequencies are listed on this page.

Are these KSNA charts current?

They are from the FAA cycle effective 6 August 2026, which is superseded on 3 September 2026. We publish each new cycle on its effective date. They are for flight simulation and reference only — not for real-world navigation.
