Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 46.1 MB | Download |
| Print-ready chart, no georeferencing | 97.1 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 97.1 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROHalifax lies near the centre of a sheet shaped by Atlantic Canada’s deeply indented coastline and broad stretches of open water. Coverage extends from eastern Maine and New Brunswick across Prince Edward Island and Nova Scotia towards Cape Breton, while the northern portion takes in the Gaspé Peninsula and the Gulf of St Lawrence.
The landscape shifts from Appalachian uplands in New Brunswick and eastern Quebec to lower coastal country, islands and exposed headlands. Numerous bays, channels and peninsulas make the shoreline visually distinctive, while routes across the Gulf or around Nova Scotia can spend substantial distances away from continuous land.
The Montreal sheet adjoins to the west, providing continuity for routes towards inland Quebec and the St Lawrence corridor. The New York sheet meets the Halifax coverage to the south-west, supporting routes that continue beyond the Gulf of Maine towards the north-eastern United States. Together, these joins matter most where a route moves between the maritime coastline and the more continental terrain farther west.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| KBGR BGR | Bangor Intl | BANGOR, ME | 192 ft | 2 | 11,440 ft |
| KOLD OLD | Dewitt Fld/Old Town Muni | OLD TOWN, ME | 126 ft | 3 | 8,400 ft |
| KBXM BXM | Brunswick Exec | BRUNSWICK, ME | 74 ft | 2 | 8,000 ft |
| CYSU | Summerside | SUMMERSIDE | 56 ft | 1 | 8,000 ft |
| KPQI PQI | Presque Isle Intl | PRESQUE ISLE, ME | 534 ft | 2 | 7,441 ft |
| CYSJ | St John | SAINT JOHN | 357 ft | 2 | 7,000 ft |
| CYRI | Riviere-Du-Loup | RIVIERE-DU-LOUP | 427 ft | 1 | 6,000 ft |
| KWVL WVL | Waterville Rgnl | WATERVILLE, ME | 332 ft | 2 | 5,500 ft |
| KRKD RKD | Knox County Rgnl | ROCKLAND, ME | 55 ft | 2 | 5,412 ft |
| KBHB BHB | Hancock County/Bar Harbor | BAR HARBOR, ME | 83 ft | 2 | 5,200 ft |
| KHUL HUL | Houlton Intl | HOULTON, ME | 489 ft | 2 | 5,015 ft |
| KAUG AUG | Augusta State | AUGUSTA, ME | 351 ft | 2 | 5,002 ft |
| KMLT MLT | Millinocket Muni | MILLINOCKET, ME | 408 ft | 2 | 4,713 ft |
| KFVE FVE | Northern Aroostook Rgnl | FRENCHVILLE, ME | 987 ft | 1 | 4,600 ft |
| 43B | Deblois Flight Strip | DEBLOIS, ME | 217 ft | 1 | 4,500 ft |
| KPNN PNN | Princeton Muni | PRINCETON, ME | 264 ft | 2 | 4,007 ft |
| KCAR CAR | Caribou Muni | CARIBOU, ME | 620 ft | 2 | 4,003 ft |
| 2B7 | Pittsfield Muni | PITTSFIELD, ME | 197 ft | 1 | 4,003 ft |
| KEPM EPM | Eastport Muni | EASTPORT, ME | 45 ft | 1 | 4,002 ft |
| KBST BST | Belfast Muni | BELFAST, ME | 197 ft | 1 | 4,000 ft |
| KOWK OWK | Central Maine/Norridgewock | NORRIDGEWOCK, ME | 270 ft | 2 | 4,000 ft |
| 3B1 | Greenville Muni | GREENVILLE, ME | 1,401 ft | 2 | 4,000 ft |
| CYSL | St Leonard | ST LEONARD | 793 ft | 1 | 4,000 ft |
| KIWI IWI | Wiscasset | WISCASSET, ME | 70 ft | 1 | 3,397 ft |
| 1B0 | Dexter Rgnl | DEXTER, ME | 533 ft | 2 | 3,008 ft |
| ME2 | Cutler Rgnl | CUTLER, ME | 55 ft | 1 | 2,950 ft |
| 44B | Charles A Chase Jr Meml Fld | DOVER/FOXCROFT, ME | 520 ft | 1 | 2,926 ft |
| KMVM MVM | Machias Valley | MACHIAS, ME | 96 ft | 1 | 2,880 ft |
| KLRG LRG | Lincoln Rgnl | LINCOLN, ME | 207 ft | 2 | 2,805 ft |
| PG1 | Griffin Fld | LEVANT, ME | 200 ft | 2 | 2,440 ft |
| 57B | Islesboro | ISLESBORO, ME | 88 ft | 2 | 2,400 ft |
| 7ME | Fort Kent Muni | FORT KENT, ME | 708 ft | 1 | 2,140 ft |
| ME6 | Wales | WALES, ME | 210 ft | 1 | 2,100 ft |
| 93B | Stonington Muni | STONINGTON, ME | 32 ft | 2 | 2,099 ft |
| 65B | Lubec Muni | LUBEC, ME | 85 ft | 1 | 2,024 ft |
| 08B | Merrymeeting Fld | BOWDOINHAM, ME | 61 ft | 1 | 1,935 ft |
| 0B2 | Brewer | BREWER, ME | 124 ft | 1 | 1,730 ft |
| 66B | Gillespie Fld | MEDDYBEMPS, ME | 200 ft | 1 | 1,635 ft |
| ME5 | Banks | SWANS ISLAND, ME | 100 ft | 2 | 1,500 ft |
39 public-use airports within this chart's coverage, ordered by runway length. A further 47 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Maine is available as a single 26.3 MB archive (113 charts) — see the Maine airports.
It spans 43.5°N to 48.3°N and 70.1°W to 60.6°W. Airports on the sheet fall within Maine. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (46.1 MB). Take the PDF to print it or read it on a second screen (97.1 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Montreal to the west and New York to the south-west. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
