Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 64.5 MB | Download |
| Print-ready chart, no georeferencing | 138.4 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 138.4 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROFrom the eastern end of Lake Ontario to the lower St Lawrence, this sheet follows one of eastern Canada’s defining geographic corridors. It covers southern Quebec around Montreal and Quebec City, with adjoining parts of eastern Ontario and the northern United States. The St Lawrence lowlands provide a strong visual contrast with the more broken country beyond them: forested uplands, extensive lakes and the northern reaches of the Adirondack, Green and White mountain regions. Farther east, the river broadens markedly as the landscape takes on the character of the lower St Lawrence.
The Montreal sheet sits between Lake Huron to the west and Halifax to the east, making those the natural adjoining sheets for longer east–west routes. The New York chart continues coverage southwards, while Detroit meets the south-western edge. This arrangement is particularly useful for journeys that follow the St Lawrence corridor before turning towards Atlantic Canada, or for routes crossing between southern Quebec, New England and the Great Lakes region.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| KPBG PBG | Plattsburgh Intl | PLATTSBURGH, NY | 234 ft | 1 | 11,759 ft |
| KBGR BGR | Bangor Intl | BANGOR, ME | 192 ft | 2 | 11,440 ft |
| CYOW | Ottawa/Macdonald-Cartier Intl | OTTAWA | 374 ft | 3 | 10,000 ft |
| CYVO | Val-D'Or | VAL-D'OR | 1,107 ft | 1 | 10,000 ft |
| CYRQ | Trois-Rivieres | TROIS-RIVIERES | 199 ft | 1 | 9,006 ft |
| CYQB | Quebec/Jean Lesage Intl | QUEBEC | 244 ft | 2 | 9,000 ft |
| KOLD OLD | Dewitt Fld/Old Town Muni | OLD TOWN, ME | 126 ft | 3 | 8,400 ft |
| KBTV BTV | Patrick Leahy Burlington Intl | BURLINGTON, VT | 334 ft | 2 | 8,319 ft |
| KBXM BXM | Brunswick Exec | BRUNSWICK, ME | 74 ft | 2 | 8,000 ft |
| KPWM PWM | Portland Intl Jetport | PORTLAND, ME | 75 ft | 2 | 7,200 ft |
| KART ART | Watertown Intl | WATERTOWN, NY | 330 ft | 2 | 7,001 ft |
| KSLK SLK | Adirondack Rgnl | SARANAC LAKE, NY | 1,662 ft | 2 | 6,573 ft |
| KOGS OGS | Ogdensburg Intl | OGDENSBURG, NY | 301 ft | 1 | 6,400 ft |
| CYND | Ottawa/Gatineau | OTTAWA | 211 ft | 1 | 6,000 ft |
| CYRI | Riviere-Du-Loup | RIVIERE-DU-LOUP | 427 ft | 1 | 6,000 ft |
| CYSC | Sherbrooke | SHERBROOKE | 792 ft | 1 | 6,000 ft |
| KLCI LCI | Laconia Muni | LACONIA, NH | 545 ft | 1 | 5,890 ft |
| KMSS MSS | Massena Intl-Richards Fld | MASSENA, NY | 221 ft | 2 | 5,601 ft |
| KWVL WVL | Waterville Rgnl | WATERVILLE, ME | 332 ft | 2 | 5,500 ft |
| KLEB LEB | Lebanon Muni | LEBANON, NH | 603 ft | 2 | 5,496 ft |
| KRKD RKD | Knox County Rgnl | ROCKLAND, ME | 55 ft | 2 | 5,412 ft |
| KRUT RUT | Rutland/Southern Vermont Rgnl | RUTLAND, VT | 787 ft | 2 | 5,304 ft |
| KEFK EFK | Northeast Kingdom Intl | NEWPORT, VT | 933 ft | 2 | 5,301 ft |
| KBML BML | Berlin Rgnl | BERLIN, NH | 1,161 ft | 1 | 5,200 ft |
| KBHB BHB | Hancock County/Bar Harbor | BAR HARBOR, ME | 83 ft | 2 | 5,200 ft |
| CYSG | St Georges | ST GEORGES | 893 ft | 1 | 5,108 ft |
| KAUG AUG | Augusta State | AUGUSTA, ME | 351 ft | 2 | 5,002 ft |
| KLEW LEW | Auburn/Lewiston Muni | AUBURN/LEWISTON, ME | 287 ft | 2 | 5,001 ft |
| KMPV MPV | Edward F Knapp State | BARRE/MONTPELIER, VT | 1,165 ft | 2 | 5,000 ft |
| CPZ3 | Mountain View | MOUNTAIN VIEW | 362 ft | 1 | 5,000 ft |
| CYTA | Pembroke | PEMBROKE | 529 ft | 1 | 5,000 ft |
| CYPQ | Peterborough | PETERBOROUGH | 628 ft | 2 | 5,000 ft |
| KMLT MLT | Millinocket Muni | MILLINOCKET, ME | 408 ft | 2 | 4,713 ft |
| KFVE FVE | Northern Aroostook Rgnl | FRENCHVILLE, ME | 987 ft | 1 | 4,600 ft |
| 8B0 | Stephen A Bean Muni | RANGELEY, ME | 1,821 ft | 1 | 4,299 ft |
| KMVL MVL | Morrisville-Stowe State | MORRISVILLE, VT | 732 ft | 1 | 4,200 ft |
| KIZG IZG | White Mountain Rgnl | FRYEBURG, ME | 454 ft | 1 | 4,200 ft |
| KLKP LKP | Lake Placid | LAKE PLACID, NY | 1,747 ft | 1 | 4,196 ft |
| 4B6 | Ticonderoga Muni | TICONDEROGA, NY | 273 ft | 1 | 4,041 ft |
| 2B7 | Pittsfield Muni | PITTSFIELD, ME | 197 ft | 1 | 4,003 ft |
| KFSO FSO | Franklin County State | HIGHGATE, VT | 227 ft | 1 | 4,001 ft |
| KHIE HIE | Mount Washington Rgnl | WHITEFIELD, NH | 1,072 ft | 1 | 4,001 ft |
| KBST BST | Belfast Muni | BELFAST, ME | 197 ft | 1 | 4,000 ft |
| KOWK OWK | Central Maine/Norridgewock | NORRIDGEWOCK, ME | 270 ft | 2 | 4,000 ft |
| 3B1 | Greenville Muni | GREENVILLE, ME | 1,401 ft | 2 | 4,000 ft |
| CYSH | Montague/Russ Beach | SMITHS FALLS-MONTAGUE | 416 ft | 1 | 4,000 ft |
| CYJN | St Jean | ST JEAN | 136 ft | 3 | 4,000 ft |
| KMAL MAL | Malone-Dufort | MALONE, NY | 789 ft | 2 | 3,994 ft |
| CYRP | Carp | OTTAWA | 382 ft | 1 | 3,937 ft |
| 0B1 | Bethel Rgnl | BETHEL, ME | 674 ft | 1 | 3,818 ft |
| KPTD PTD | Potsdam Muni/Damon Fld | POTSDAM, NY | 474 ft | 1 | 3,704 ft |
| 59B | Newton Fld | JACKMAN, ME | 1,177 ft | 2 | 3,601 ft |
| KERR ERR | Errol | ERROL, NH | 1,248 ft | 2 | 3,600 ft |
| 4MB | Moultonborough | MOULTONBOROUGH, NH | 576 ft | 1 | 3,505 ft |
| KIWI IWI | Wiscasset | WISCASSET, ME | 70 ft | 1 | 3,397 ft |
| KCDA CDA | Caledonia County | LYNDONVILLE, VT | 1,187 ft | 1 | 3,302 ft |
| CYRO | Rockcliffe | OTTAWA | 188 ft | 1 | 3,300 ft |
| 6B0 | Middlebury State | MIDDLEBURY, VT | 494 ft | 1 | 3,206 ft |
| VT8 | Shelburne | SHELBURNE, VT | 325 ft | 1 | 3,077 ft |
| 1B0 | Dexter Rgnl | DEXTER, ME | 533 ft | 2 | 3,008 ft |
| B06 | Basin Harbor | VERGENNES, VT | 124 ft | 1 | 3,000 ft |
| 4B7 | Schroon Lake | SCHROON LAKE, NY | 834 ft | 1 | 3,000 ft |
| 81B | Oxford County Rgnl | OXFORD, ME | 345 ft | 1 | 2,997 ft |
| 63B | Limington-Harmon | LIMINGTON, ME | 292 ft | 1 | 2,973 ft |
| 44B | Charles A Chase Jr Meml Fld | DOVER/FOXCROFT, ME | 520 ft | 1 | 2,926 ft |
| 2B9 | Post Mills | POST MILLS, VT | 696 ft | 2 | 2,900 ft |
| 2G8 | Gorham | GORHAM, NH | 835 ft | 1 | 2,828 ft |
| KLRG LRG | Lincoln Rgnl | LINCOLN, ME | 207 ft | 2 | 2,805 ft |
| B21 | Sugarloaf Rgnl | CARRABASSETT, ME | 880 ft | 1 | 2,797 ft |
| 8B2 | Twin Mountain | TWIN MOUNTAIN, NH | 1,459 ft | 1 | 2,660 ft |
| 5B1 | John H Boylan State (Island Pond) | ISLAND POND, VT | 1,194 ft | 1 | 2,650 ft |
| 0B7 | Warren-Sugarbush | WARREN, VT | 1,470 ft | 1 | 2,575 ft |
| 5B9 | Dean Meml | HAVERHILL, NH | 581 ft | 1 | 2,511 ft |
| PG1 | Griffin Fld | LEVANT, ME | 200 ft | 2 | 2,440 ft |
| 4C4 | Gifford Fld | COLEBROOK, NH | 1,017 ft | 1 | 2,423 ft |
| 57B | Islesboro | ISLESBORO, ME | 88 ft | 2 | 2,400 ft |
| 1I1 | Marcy Fld | KEENE, NY | 985 ft | 1 | 2,390 ft |
| 1P1 | Plymouth Muni | PLYMOUTH, NH | 506 ft | 1 | 2,347 ft |
| 1B5 | Franconia | FRANCONIA, NH | 975 ft | 1 | 2,300 ft |
| B10 | Bowman Fld | LIVERMORE FALLS, ME | 324 ft | 1 | 2,201 ft |
| 1E8 | Degrasse Moores | DEGRASSE, NY | 815 ft | 1 | 2,200 ft |
| 98M | Greaton Airfield | SACO, ME | 170 ft | 1 | 2,200 ft |
| 7ME | Fort Kent Muni | FORT KENT, ME | 708 ft | 1 | 2,140 ft |
| ME6 | Wales | WALES, ME | 210 ft | 1 | 2,100 ft |
| 93B | Stonington Muni | STONINGTON, ME | 32 ft | 2 | 2,099 ft |
| 08B | Merrymeeting Fld | BOWDOINHAM, ME | 61 ft | 1 | 1,935 ft |
| 2N2 | Newfound Valley | BRISTOL, NH | 510 ft | 1 | 1,900 ft |
| 0B2 | Brewer | BREWER, ME | 124 ft | 1 | 1,730 ft |
| ME5 | Banks | SWANS ISLAND, ME | 100 ft | 2 | 1,500 ft |
89 public-use airports within this chart's coverage, ordered by runway length. A further 126 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Maine is available as a single 26.3 MB archive (113 charts) — see the Maine airports.
It spans 43.5°N to 48.3°N and 78.5°W to 68.3°W. Airports on the sheet fall within Maine, New Hampshire, New York and Vermont. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (64.5 MB). Take the PDF to print it or read it on a second screen (138.4 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Lake Huron to the west, Halifax to the east, New York to the south and Detroit to the south-west. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
