Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 59.0 MB | Download |
| Print-ready chart, no georeferencing | 121.3 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 121.3 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROBroad Kuskokwim lowlands, Bering Sea margins and the western approaches to the Alaska Range give the McGrath sheet a distinctly varied Alaskan footprint. It covers a large part of the south-western interior, where river valleys, wetlands and open low country contrast with increasingly rugged terrain towards the east and south-east. The southern portion also reaches towards the Bristol Bay region, bringing coastal and inland landscapes onto one chart.
Routes continuing west pass onto the Bethel chart, while Anchorage and Seward provide the eastern continuation. Kodiak adjoins to the south; longer northbound routes meet Fairbanks to the north-east or Nome to the north-west. This arrangement is particularly useful for journeys crossing Alaska rather than remaining within a single valley or coastal district, with the neighbouring sheets following the transition between western lowlands, central interior country and the mountain-dominated south-central region.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| PANC ANC | Ted Stevens Anchorage Intl | ANCHORAGE, AK | 151 ft | 3 | 12,400 ft |
| PAEN ENA | Kenai Muni | KENAI, AK | 99 ft | 5 | 7,855 ft |
| PAHO HOM | Homer | HOMER, AK | 84 ft | 1 | 6,701 ft |
| PABE BET | Bethel | BETHEL, AK | 128 ft | 3 | 6,400 ft |
| PANI ANI | Aniak | ANIAK, AK | 96 ft | 1 | 6,200 ft |
| PASM KSM | St Mary'S | ST MARY'S, AK | 314 ft | 2 | 6,008 ft |
| PAMC MCG | Mc Grath | MC GRATH, AK | 342 ft | 2 | 5,936 ft |
| PAUN UNK | Unalakleet | UNALAKLEET, AK | 27 ft | 2 | 5,900 ft |
| PAIL ILI | Iliamna | ILIAMNA, AK | 192 ft | 4 | 5,086 ft |
| PASX SXQ | Soldotna | SOLDOTNA, AK | 113 ft | 2 | 5,001 ft |
| PAHX SHX | Shageluk | SHAGELUK, AK | 78 ft | 2 | 5,000 ft |
| RDV | Red Devil | RED DEVIL, AK | 180 ft | 1 | 4,820 ft |
| PALH LHD | Lake Hood | ANCHORAGE, AK | 79 ft | 4 | 4,541 ft |
| PFKO 2A9 | Kotlik | KOTLIK, AK | 13 ft | 1 | 4,400 ft |
| PAUO UUO | Willow | WILLOW, AK | 215 ft | 1 | 4,400 ft |
| PAMH MHM | Minchumina | MINCHUMINA, AK | 681 ft | 1 | 4,184 ft |
| FLT | Flat | FLAT, AK | 343 ft | 1 | 4,045 ft |
| PAFS FSP | Nikolai | NIKOLAI, AK | 447 ft | 1 | 4,001 ft |
| PAMK SMK | St Michael | ST MICHAEL, AK | 98 ft | 1 | 4,001 ft |
| PANV ANV | Anvik | ANVIK, AK | 297 ft | 1 | 4,000 ft |
| PAGX KGX | Grayling | GRAYLING, AK | 137 ft | 1 | 4,000 ft |
| PAHC HCA | Holy Cross | HOLY CROSS, AK | 74 ft | 1 | 4,000 ft |
| PAAC 0AK | Pilot Station | PILOT STATION, AK | 473 ft | 1 | 4,000 ft |
| PAQH AQH | Quinhagak | QUINHAGAK, AK | 43 ft | 1 | 4,000 ft |
| PAKX 05K | Wilder Runway | PORT ALSWORTH, AK | 288 ft | 1 | 3,849 ft |
| PARS RSH | Russian Mission | RUSSIAN MISSION, AK | 58 ft | 2 | 3,620 ft |
| PAMO MOU | Mountain Village | MOUNTAIN VILLAGE, AK | 339 ft | 1 | 3,501 ft |
| PATK TKA | Talkeetna | TALKEETNA, AK | 365 ft | 1 | 3,500 ft |
| PACH 9A3 | Chuathbaluk | CHUATHBALUK, AK | 243 ft | 1 | 3,401 ft |
| PASW SKW | Skwentna | SKWENTNA, AK | 148 ft | 1 | 3,400 ft |
| PFZK Z13 | Akiachak | AKIACHAK, AK | 22 ft | 1 | 3,300 ft |
| PACJ CJX | Crooked Creek | CROOKED CREEK, AK | 182 ft | 1 | 3,300 ft |
| PAJZ JZZ | Koliganek | KOLIGANEK, AK | 271 ft | 1 | 3,300 ft |
| PPCT TCT | Takotna | TAKOTNA, AK | 423 ft | 1 | 3,300 ft |
| PALT TLT | Tuluksak | TULUKSAK, AK | 35 ft | 1 | 3,300 ft |
| PANW KNW | New Stuyahok | NEW STUYAHOK, AK | 370 ft | 1 | 3,281 ft |
| PANA WNA | Napakiak | NAPAKIAK, AK | 16 ft | 1 | 3,248 ft |
| PAEE EEK | Eek | EEK, AK | 26 ft | 1 | 3,242 ft |
| PFAK AKI | Akiak | AKIAK, AK | 39 ft | 1 | 3,200 ft |
| PAKI IIK | Kipnuk | KIPNUK, AK | 19 ft | 1 | 3,200 ft |
| PADM MDM | Marshall Don Hunter Sr | MARSHALL, AK | 115 ft | 1 | 3,200 ft |
| PFKW KWT | Kwethluk | KWETHLUK, AK | 25 ft | 1 | 3,199 ft |
| PALG KLG | Kalskag | KALSKAG, AK | 63 ft | 1 | 3,198 ft |
| PASL SLQ | Sleetmute | SLEETMUTE, AK | 191 ft | 1 | 3,100 ft |
| PAAJ A61 | Tuntutuliak | TUNTUTULIAK, AK | 16 ft | 1 | 3,005 ft |
| 4K0 | Pedro Bay | PEDRO BAY, AK | 83 ft | 1 | 3,002 ft |
| PAAB 4A2 | Atmautluak | ATMAUTLUAK, AK | 18 ft | 1 | 3,000 ft |
| PFKA Z09 | Kasigluk | KASIGLUK, AK | 47 ft | 1 | 3,000 ft |
| PAPK PKA | Napaskiak | NAPASKIAK, AK | 11 ft | 1 | 3,000 ft |
| PAAS WBB | Stebbins | STEBBINS, AK | 18 ft | 1 | 3,000 ft |
| PANO 5NN | Nondalton | NONDALTON, AK | 314 ft | 1 | 2,800 ft |
| SRV | Stony River 2 | STONY RIVER, AK | 230 ft | 1 | 2,601 ft |
| PPIT 16A | Nunapitchuk | NUNAPITCHUK, AK | 21 ft | 1 | 2,420 ft |
| 5KS | Kasilof | KASILOF, AK | 125 ft | 1 | 2,400 ft |
| PADY DUY | Kongiganak | KONGIGANAK, AK | 39 ft | 1 | 2,400 ft |
| NIN | Ninilchik | NINILCHIK, AK | 276 ft | 1 | 2,400 ft |
| 6AK | Rainy Pass Lodge | RAINY PASS, AK | 1,900 ft | 1 | 2,100 ft |
| PAFL TNW | Tin Creek | FAREWELL LAKE, AK | 1,185 ft | 1 | 2,000 ft |
| Z90 | Stampede | KANTISHNA, AK | 1,852 ft | 1 | 1,960 ft |
| PATM ATM | Taylor Mountain | TAYLOR MOUNTAIN MINE, AK | 1,000 ft | 1 | 1,950 ft |
| Z17 | Ophir | OPHIR, AK | 595 ft | 1 | 1,940 ft |
| 2K5 | Telida | TELIDA, AK | 650 ft | 1 | 1,900 ft |
| PAAH 5Z5 | Kantishna | KANTISHNA, AK | 1,578 ft | 1 | 1,887 ft |
| PASO SOV | Seldovia | SELDOVIA, AK | 29 ft | 1 | 1,845 ft |
| PAGG GGV | Kwigillingok | KWIGILLINGOK, AK | 21 ft | 1 | 1,835 ft |
| Z48 | Bear Creek 3 | BEAR CREEK, AK | 740 ft | 1 | 1,800 ft |
| A77 | Yankee Creek 2 | YANKEE CREEK, AK | 1,120 ft | 1 | 1,560 ft |
| 2AK | Lime Village | LIME VILLAGE, AK | 545 ft | 1 | 1,500 ft |
| 8KA | Tatitna | TATITNA, AK | 1,490 ft | 1 | 1,200 ft |
| 01A | Purkeypile | PURKEYPILE, AK | 2,041 ft | 1 | 1,176 ft |
| 4Z9 | Jakolof Bay | JAKOLOF BAY, AK | 5 ft | 1 | 1,000 ft |
71 public-use airports within this chart's coverage, ordered by runway length. A further 112 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Alaska is available as a single 140.9 MB archive (594 charts) — see the Alaska airports.
It spans 59.4°N to 64.3°N and 164.2°W to 149.9°W. Airports on the sheet fall within Alaska. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (59.0 MB). Take the PDF to print it or read it on a second screen (121.3 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Anchorage to the east, Bethel to the west, Seward to the east, Kodiak to the south, Fairbanks to the north-east and Nome to the north-west. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
