Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 22.9 MB | Download |
| Print-ready chart, no georeferencing | 45.7 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 45.7 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROBoston sits near the centre of a sheet extending from southern New Hampshire across eastern Massachusetts, Rhode Island and eastern Connecticut, then well offshore beyond Cape Cod. It includes Massachusetts Bay, Long Island Sound, the waters south of Rhode Island, and the islands off the Massachusetts coast.
The chart brings together a densely settled coastal corridor and a highly irregular shoreline with quieter inland country. Routes can pass quickly from the Boston metropolitan area to wooded New England hills, or cross long stretches of open water around Cape Cod and the offshore islands. The New York Terminal Area Chart adjoins to the west, continuing coverage towards the southern New England and New York region.
An FAA Helicopter Route Chart also covers this area, serving the more specialised needs of helicopter operations. The Terminal Area Chart remains the broader sheet for viewing Boston and its surrounding coastal and inland setting as one connected operating area.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| KBOS BOS | General Edward Lawrence Logan Intl | BOSTON, MA | 19 ft | 6 | 10,083 ft |
| KMHT MHT | Manchester Boston Rgnl | MANCHESTER, NH | 266 ft | 2 | 9,250 ft |
| KPVD PVD | Rhode Island Tf Green Intl | PROVIDENCE, RI | 54 ft | 2 | 8,700 ft |
| KBED BED | Laurence G Hanscom Fld | BEDFORD, MA | 132 ft | 2 | 7,011 ft |
| KORH ORH | Worcester Rgnl | WORCESTER, MA | 1,009 ft | 2 | 7,001 ft |
| KOQU OQU | Quonset State | NORTH KINGSTOWN, RI | 18 ft | 4 | 7,000 ft |
| KACK ACK | Nantucket Meml | NANTUCKET, MA | 46 ft | 2 | 6,303 ft |
| KEEN EEN | Dillant/Hopkins | KEENE, NH | 488 ft | 2 | 6,201 ft |
| KASH ASH | Boire Fld | NASHUA, NH | 200 ft | 1 | 6,000 ft |
| KMVY MVY | Martha'S Vineyard | VINEYARD HAVEN, MA | 66 ft | 2 | 5,504 ft |
| KHYA HYA | Cape Cod Gateway | HYANNIS, MA | 54 ft | 2 | 5,425 ft |
| KEWB EWB | New Bedford Rgnl | NEW BEDFORD, MA | 79 ft | 2 | 5,400 ft |
| KORE ORE | Orange Muni | ORANGE, MA | 555 ft | 2 | 5,002 ft |
| KBVY BVY | Beverly Rgnl | BEVERLY, MA | 107 ft | 2 | 5,001 ft |
| KFIT FIT | Fitchburg Muni | FITCHBURG, MA | 344 ft | 1 | 5,001 ft |
| KLWM LWM | Lawrence Muni | LAWRENCE, MA | 147 ft | 2 | 5,001 ft |
| KGON GON | Groton-New London | GROTON (NEW LONDON), CT | 9 ft | 3 | 5,000 ft |
| KSFZ SFZ | North Central State | PAWTUCKET, RI | 440 ft | 2 | 5,000 ft |
| KPYM PYM | Plymouth Muni | PLYMOUTH, MA | 148 ft | 2 | 4,650 ft |
| KIJD IJD | Windham | WILLIMANTIC, CT | 246 ft | 2 | 4,271 ft |
| KWST WST | Westerly State | WESTERLY, RI | 81 ft | 2 | 4,010 ft |
| KOWD OWD | Norwood Meml | NORWOOD, MA | 49 ft | 2 | 4,007 ft |
| KGHG GHG | Marshfield Muni - George Harlow Fld | MARSHFIELD, MA | 8 ft | 1 | 3,900 ft |
| 1B2 | Katama Airpark | EDGARTOWN, MA | 18 ft | 3 | 3,700 ft |
| KPVC PVC | Provincetown Muni | PROVINCETOWN, MA | 7 ft | 1 | 3,502 ft |
| 3B0 | Southbridge Muni | SOUTHBRIDGE, MA | 698 ft | 1 | 3,501 ft |
| 1B9 | Mansfield Muni | MANSFIELD, MA | 122 ft | 2 | 3,500 ft |
| KTAN TAN | Taunton Muni/King Fld | TAUNTON, MA | 41 ft | 2 | 3,499 ft |
| 1B6 | Hopedale Industrial Park | HOPEDALE, MA | 269 ft | 1 | 3,172 ft |
| 6B6 | Minute Man Air Fld | STOW, MA | 280 ft | 2 | 3,110 ft |
| 3B3 | Sterling | STERLING, MA | 459 ft | 2 | 3,086 ft |
| KCQX CQX | Chatham Muni | CHATHAM, MA | 63 ft | 1 | 3,001 ft |
| KGDM GDM | Gardner Muni | GARDNER, MA | 954 ft | 1 | 3,001 ft |
| KUUU UUU | Newport State | NEWPORT, RI | 171 ft | 2 | 2,999 ft |
| KAFN AFN | Jaffrey Airfield Silver Ranch | JAFFREY, NH | 1,039 ft | 1 | 2,982 ft |
| 2B1 | Cape Cod | MARSTON MILLS, MA | 103 ft | 3 | 2,700 ft |
| KLZD LZD | Danielson | DANIELSON, CT | 238 ft | 1 | 2,700 ft |
| 1M8 | Myricks | BERKLEY, MA | 73 ft | 1 | 2,466 ft |
| 0B8 | Elizabeth Fld | FISHERS ISLAND, NY | 7 ft | 2 | 2,345 ft |
| 2B2 | Plum Island | NEWBURYPORT, MA | 11 ft | 2 | 2,300 ft |
| 5B6 | Falmouth Airpark | FALMOUTH, MA | 41 ft | 1 | 2,298 ft |
| 08R | Richmond | WEST KINGSTON, RI | 130 ft | 1 | 2,129 ft |
| 60M | Spencer | SPENCER, MA | 1,042 ft | 1 | 1,898 ft |
| 28M | Cranland | HANSON, MA | 71 ft | 1 | 1,760 ft |
| C44 | Toutant | PUTNAM, CT | 770 ft | 1 | 1,756 ft |
45 public-use airports within this chart's coverage, ordered by runway length. A further 35 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Massachusetts is available as a single 42.9 MB archive (193 charts) — see the Massachusetts airports.
It spans 41.2°N to 42.9°N and 72.3°W to 69.0°W. Airports on the sheet fall within Connecticut, Massachusetts, New Hampshire, New York and Rhode Island. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (22.9 MB). Take the PDF to print it or read it on a second screen (45.7 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
New York to the west. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
