Terminal Procedures

Kentucky airport charts

53 airports · 351 charts · cycle 6 Aug 2026

Get all 254 charts in one downloadPRO members · 57.4 MB ZIP
NOT FOR NAVIGATION. For flight simulation and reference use only.
IDAirportCityCharts RwysLongest
KLEX LEXBlue GrassLEXINGTON1127,004 ft
KFTK FTKGodman AAFFORT KNOX925,184 ft
KBWG BWGBowling Green-Warren County RgnlBOWLING GREEN726,501 ft
KFFT FFTCapital CityFRANKFORT615,506 ft
KSME SMELake Cumberland RgnlSOMERSET515,801 ft
KGLW GLWGlasgow MuniGLASGOW415,302 ft
KOWB OWBOwensboro/Daviess County RgnlOWENSBORO1228,000 ft
KPAH PAHBarkley RgnlPADUCAH1126,500 ft
KBYL BYLWilliamsburg-Whitley CountyWILLIAMSBURG515,499 ft
KSYM SYMMorehead-Rowan County Clyde A Thomas RgnlMOREHEAD415,500 ft
KSDF SDFLouisville Muhammad Ali IntlLOUISVILLE47311,887 ft
KEKX EKXAddington FldELIZABETHTOWN616,001 ft
KLOZ LOZLondon/Corbin/MageeLONDON515,750 ft
6I2Lebanon Springfield/George Hoerter FldSPRINGFIELD415,001 ft
KEKQ EKQWayne CountyMONTICELLO414,000 ft
KJKL JKLJulian CarrollJACKSON314,401 ft
M20Leitchfield-Grayson CountyLEITCHFIELD314,000 ft
M21Muhlenberg CountyGREENVILLE314,999 ft
KCVG CVGCincinnati/Northern Kentucky IntlCOVINGTON63412,001 ft
KLOU LOUBowman FldLOUISVILLE1324,358 ft
KHOP HOPCampbell AAF (Fort Campbell)FORT CAMPBELL/HOPKINSVILLE6210,926 ft
KRGA RGACentral Kentucky RgnlRICHMOND615,001 ft
KFGX FGXFleming-MasonFLEMINGSBURG515,002 ft
27KGeorgetown-Scott County RgnlGEORGETOWN515,498 ft
KEHR EHRHenderson City-CountyHENDERSON515,503 ft
M25Mayfield Graves CountyMAYFIELD515,002 ft
KPBX PBXPike County/Hatcher FldPIKEVILLE525,356 ft
KDVK DVKStuart Powell FldDANVILLE535,000 ft
KCPF CPFWendell H FordHAZARD525,499 ft
KDWU DWUAshland RgnlASHLAND415,402 ft
KSJS SJSBig Sandy RgnlPRESTONSBURG415,051 ft
KY8Hancock County/Ron Lewis FldLEWISPORT415,002 ft
KCEY CEYKyle-Oakley FldMURRAY416,202 ft
2I0Madisonville RgnlMADISONVILLE416,051 ft
KGDA GDAMarion-Crittenden County James C Johnson RgnlMARION415,001 ft
KJQD JQDOhio CountyHARTFORD415,003 ft
KBRY BRYSamuels FldBARDSTOWN415,003 ft
KAAS AASTaylor CountyCAMPBELLSVILLE415,004 ft
I93Breckinridge CountyHARDINSBURG314,000 ft
0I8Cynthiana-Harrison CountyCYNTHIANA313,850 ft
K62Gene SnyderFALMOUTH314,002 ft
KHVC HVCHopkinsville-Christian CountyHOPKINSVILLE315,505 ft
18IMc Creary CountyPINE KNOT312,999 ft
1A6Middlesboro/Bell CountyMIDDLESBORO313,633 ft
KIOB IOBMount Sterling/Montgomery CountyMOUNT STERLING315,000 ft
2M0Princeton-Caldwell CountyPRINCETON314,099 ft
K24Russell CountyJAMESTOWN315,010 ft
4M7Russellville-Logan CountyRUSSELLVILLE314,500 ft
KTWT TWTSturgis MuniSTURGIS315,000 ft
KTZV TZVTompkinsville/Monroe CountyTOMPKINSVILLE314,000 ft
I35Tucker-Guthrie MemlHARLAN313,461 ft
1M7FultonFULTON214,001 ft
M34Kentucky Dam State ParkCALVERT CITY213,997 ft

Airport data from the FAA NASR 28-day subscription; charts from the FAA digital Terminal Procedures Publication.

Every Kentucky chart in one download 254 chart files covering all 53 airports — 57.4 MB, sorted by airport. Fewer files than the 351 charts listed above, because a minimums page is shared across a whole volume and is included once.
PRO members only

VFR charts covering Kentucky

Sectional and terminal area charts whose coverage includes airports in Kentucky — free GeoTIFF and PDF:

St LouisSectional Chart
45 airports on this sheetCincinnatiSectional Chart
36 airports on this sheetCincinnatiTerminal Area Chart
3 airports on this sheetAtlantaSectional Chart
2 airports on this sheet

Other public-use airfields in Kentucky

These have no published instrument procedures, so there are no approach charts for them — but they appear on the VFR sectional covering the area and are flyable in a simulator.

IDAirfieldCity ElevRwysLongest
1M9Lake Barkley State ParkCadiz570 ft14,800 ft
8M9Providence-Webster CountyProvidence395 ft13,800 ft
2I3Rough River State ParkFalls-Of-Rough575 ft13,200 ft
I50StantonStanton651 ft12,996 ft
8M7TradewaterDawson Springs405 ft12,875 ft
I96Columbia-Adair CountyColumbia819 ft12,600 ft
9I3West LibertyWest Liberty934 ft12,400 ft

7 public-use airfields in Kentucky without published instrument procedures. Source: FAA NASR 28-day subscription.

Common questions

How many airports in Kentucky have approach charts?

53 airports in Kentucky have published FAA instrument procedures, totalling 351 charts in the current cycle. A further 7 public-use airfields in the state have no published procedures and so have no approach charts, though they appear on the VFR sectional covering the area.

Are the Kentucky charts free to download?

Yes. Every individual approach plate, departure, arrival and airport diagram is free with no account required — they are United States Government works, not subject to copyright in the US under 17 U.S.C. § 105. Guest downloads are speed-capped and run one at a time; PRO members download at full line speed and can take the whole state as a single archive.

How current are these charts?

They are from the FAA cycle effective 6 August 2026. Terminal procedures are reissued every 28 days and we publish each new cycle on its effective date. For flight simulation and reference only — not for real-world navigation.

Can I download every Kentucky chart at once?

Yes — PRO members can take all 254 chart files for the state as a single 57.4 MB ZIP, sorted by airport. Individual charts remain free for everyone.
