Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 50.5 MB | Download |
| Print-ready chart, no georeferencing | 104.6 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 104.6 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROYellowstone’s high country and the northern Rocky Mountain foothills occupy the western side of this sheet, while the landscape opens eastwards across Montana’s broad plains and into the western Dakotas. The coverage reaches north to the Canadian border and south across northern Wyoming, including the Black Hills region. It is a marked terrain transition: mountain ranges, upland basins and broken foothills give way to expansive prairie and river country.
The adjoining Great Falls chart continues coverage to the west, with Twin Cities to the east. Southbound routes pass onto Cheyenne, while Salt Lake City meets the south-western edge and Omaha the south-eastern edge. Together these joins make the Billings sheet a central link for routes crossing Montana or running between the northern plains, Wyoming and the interior West.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| KBIL BIL | Billings Logan Intl | BILLINGS, MT | 3,662 ft | 3 | 10,518 ft |
| KBIS BIS | Bismarck Muni | BISMARCK, ND | 1,661 ft | 2 | 8,794 ft |
| KSHR SHR | Sheridan County | SHERIDAN, WY | 4,021 ft | 2 | 8,301 ft |
| KCOD COD | Yellowstone Rgnl | CODY, WY | 5,102 ft | 1 | 8,268 ft |
| KMOT MOT | Minot Intl | MINOT, ND | 1,715 ft | 2 | 7,700 ft |
| KXWA XWA | Williston Basin Intl | WILLISTON, ND | 2,356 ft | 2 | 7,503 ft |
| KGCC GCC | Northeast Wyoming Rgnl | GILLETTE, WY | 4,365 ft | 2 | 7,501 ft |
| KDIK DIK | Dickinson/Theodore Roosevelt Rgnl | DICKINSON, ND | 2,592 ft | 2 | 7,301 ft |
| KGEY GEY | South Big Horn County | GREYBULL, WY | 3,941 ft | 2 | 7,003 ft |
| KPIR PIR | Pierre Rgnl | PIERRE, SD | 1,744 ft | 2 | 6,900 ft |
| S25 | Watford City Muni | WATFORD CITY, ND | 2,135 ft | 1 | 6,550 ft |
| KSPF SPF | Black Hills-Clyde Ice Fld | SPEARFISH, SD | 3,933 ft | 3 | 6,401 ft |
| KPOY POY | Powell Muni | POWELL, WY | 5,096 ft | 3 | 6,200 ft |
| KBYG BYG | Johnson County | BUFFALO, WY | 4,970 ft | 1 | 6,143 ft |
| KLWT LWT | Lewistown Muni | LEWISTOWN, MT | 4,170 ft | 3 | 6,100 ft |
| KBHK BHK | Baker Muni | BAKER, MT | 2,980 ft | 1 | 5,904 ft |
| KMLS MLS | Frank Wiley Fld | MILES CITY, MT | 2,634 ft | 2 | 5,764 ft |
| KSDY SDY | Sidney-Richland Rgnl | SIDNEY, MT | 1,985 ft | 2 | 5,705 ft |
| KGDV GDV | Dawson Community | GLENDIVE, MT | 2,458 ft | 2 | 5,704 ft |
| KBWW BWW | Bowman Rgnl | BOWMAN, ND | 2,965 ft | 1 | 5,701 ft |
| KLVM LVM | Mission Fld | LIVINGSTON, MT | 4,659 ft | 3 | 5,701 ft |
| W43 | Hulett Muni | HULETT, WY | 4,263 ft | 1 | 5,500 ft |
| 6S0 | Big Timber At Howard Fld | BIG TIMBER, MT | 4,493 ft | 2 | 5,285 ft |
| KHVR HVR | Havre City-County | HAVRE, MT | 2,591 ft | 2 | 5,205 ft |
| U68 | North Big Horn County | COWLEY/LOVELL/BYRON, WY | 4,093 ft | 2 | 5,200 ft |
| 6S8 | Laurel Muni | LAUREL, MT | 3,542 ft | 3 | 5,199 ft |
| D60 | Tioga Muni | TIOGA, ND | 2,270 ft | 2 | 5,102 ft |
| M46 | Colstrip | COLSTRIP, MT | 3,427 ft | 1 | 5,100 ft |
| 49B | Sturgis Muni | STURGIS, SD | 3,254 ft | 2 | 5,100 ft |
| KRPX RPX | Roundup | ROUNDUP, MT | 3,490 ft | 2 | 5,099 ft |
| KOLF OLF | L M Clayton | WOLF POINT, MT | 1,988 ft | 1 | 5,091 ft |
| KGGW GGW | Wokal Fld/Glasgow-Valley County | GLASGOW, MT | 2,295 ft | 2 | 5,002 ft |
| KHZE HZE | Mercer County Rgnl | HAZEN, ND | 1,814 ft | 1 | 4,999 ft |
| 1S3 | Tillitt Fld | FORSYTH, MT | 2,729 ft | 1 | 4,799 ft |
| KHEI HEI | Hettinger/Jb Lindquist Rgnl | HETTINGER, ND | 2,705 ft | 2 | 4,652 ft |
| KEFC EFC | Belle Fourche Muni | BELLE FOURCHE, SD | 3,190 ft | 2 | 4,501 ft |
| M75 | Malta | MALTA, MT | 2,253 ft | 1 | 4,500 ft |
| KLEM LEM | Lemmon Muni | LEMMON, SD | 2,572 ft | 2 | 4,499 ft |
| 00U | Big Horn County | HARDIN, MT | 3,025 ft | 1 | 4,491 ft |
| KMBG MBG | Mobridge Muni | MOBRIDGE, SD | 1,716 ft | 2 | 4,410 ft |
| PO1 | Poplar Muni | POPLAR, MT | 2,037 ft | 2 | 4,403 ft |
| 00F | Broadus | BROADUS, MT | 3,282 ft | 1 | 4,400 ft |
| 9S7 | Winifred | WINIFRED, MT | 3,354 ft | 1 | 4,400 ft |
| Y19 | Mandan Rgnl/Lawler Fld | MANDAN, ND | 1,944 ft | 2 | 4,399 ft |
| KJDN JDN | Jordan | JORDAN, MT | 2,667 ft | 1 | 4,300 ft |
| 8U6 | Terry | TERRY, MT | 2,283 ft | 1 | 4,300 ft |
| 20U | Beach | BEACH, ND | 2,755 ft | 1 | 4,200 ft |
| 84D | Cheyenne Eagle Butte | EAGLE BUTTE, SD | 2,448 ft | 1 | 4,200 ft |
| 9Y1 | Dunn County Weydahl Fld | KILLDEER, ND | 2,249 ft | 1 | 4,200 ft |
| S64 | Stanford/Biggerstaff Fld | STANFORD, MT | 4,327 ft | 2 | 4,200 ft |
| KHWQ HWQ | Wheatland County At Harlowton | HARLOWTON, MT | 4,311 ft | 1 | 4,200 ft |
| D07 | Faith Muni | FAITH, SD | 2,584 ft | 1 | 4,191 ft |
| 4U6 | Circle Town County | CIRCLE, MT | 2,441 ft | 2 | 4,100 ft |
| 37S | Fort Peck | FORT PECK, MT | 2,290 ft | 2 | 4,100 ft |
| 48S | Harlem | HARLEM, MT | 2,643 ft | 2 | 4,100 ft |
| 95D | Beulah | BEULAH, ND | 1,791 ft | 1 | 4,030 ft |
| 9S2 | Scobey | SCOBEY, MT | 2,434 ft | 1 | 4,020 ft |
| 3P3 | Mott Muni | MOTT, ND | 2,413 ft | 1 | 4,001 ft |
| S71 | Edgar G Obie | CHINOOK, MT | 2,416 ft | 1 | 4,000 ft |
| KRED RED | Red Lodge | RED LODGE, MT | 5,762 ft | 1 | 4,000 ft |
| 9D2 | Harding County | BUFFALO, SD | 2,891 ft | 1 | 3,900 ft |
| KPWD PWD | Sher-Wood | PLENTYWOOD, MT | 2,263 ft | 2 | 3,900 ft |
| 08D | Stanley Muni | STANLEY, ND | 2,249 ft | 2 | 3,900 ft |
| 3U4 | St Labre Mission | ASHLAND, MT | 2,909 ft | 1 | 3,830 ft |
| 5U7 | Fort Smith Landing Strip | FORT SMITH, MT | 3,242 ft | 1 | 3,827 ft |
| 4E8 | Richardton | RICHARDTON, ND | 2,498 ft | 1 | 3,822 ft |
| S85 | Big Sky Fld | CULBERTSON, MT | 1,953 ft | 1 | 3,800 ft |
| D50 | Crosby Muni | CROSBY, ND | 1,952 ft | 2 | 3,800 ft |
| 6S3 | Woltermann Meml | COLUMBUS, MT | 3,577 ft | 1 | 3,800 ft |
| D57 | Glen Ullin Rgnl | GLEN ULLIN, ND | 2,091 ft | 1 | 3,799 ft |
| 97M | Ekalaka | EKALAKA, MT | 3,504 ft | 1 | 3,798 ft |
| 5P2 | Mc Laughlin Muni | MC LAUGHLIN, SD | 2,008 ft | 1 | 3,789 ft |
| 05D | New Town Muni | NEW TOWN, ND | 1,924 ft | 1 | 3,720 ft |
| D09 | Bottineau Muni | BOTTINEAU, ND | 1,680 ft | 2 | 3,700 ft |
| 7K5 | Kenmare Muni | KENMARE, ND | 1,962 ft | 1 | 3,700 ft |
| 5C8 | Washburn Muni | WASHBURN, ND | 1,908 ft | 2 | 3,700 ft |
| D05 | Garrison Muni | GARRISON, ND | 1,936 ft | 2 | 3,699 ft |
| Y27 | Standing Rock | FORT YATES, ND | 1,633 ft | 1 | 3,699 ft |
| 9U0 | Turner | TURNER, MT | 3,051 ft | 2 | 3,612 ft |
| KHBC HBC | Mohall Muni | MOHALL, ND | 1,650 ft | 1 | 3,599 ft |
| 3U8 | Big Sandy | BIG SANDY, MT | 2,698 ft | 2 | 3,570 ft |
| 6V5 | Bison Muni | BISON, SD | 2,791 ft | 1 | 3,500 ft |
| 80S | Lavina | LAVINA, MT | 3,512 ft | 1 | 3,460 ft |
| 8U0 | Ryegate | RYEGATE, MT | 3,689 ft | 1 | 3,440 ft |
| 6S1 | Bridger Muni | BRIDGER, MT | 3,720 ft | 1 | 3,400 ft |
| 8U3 | Scobey Border Station/East Poplar Intl | SCOBEY, MT | 2,501 ft | 1 | 3,330 ft |
| D58 | Timber Lake Muni | TIMBER LAKE, SD | 2,193 ft | 1 | 3,300 ft |
| Y74 | Parshall-Hankins | PARSHALL, ND | 2,032 ft | 1 | 3,208 ft |
| U09 | Fort Belknap Agency | HARLEM, MT | 2,374 ft | 2 | 3,200 ft |
| Y99 | Trulson Fld | PLAZA, ND | 2,105 ft | 1 | 3,200 ft |
| 37N | Garrison Dam Recreational Airpark | RIVERDALE, ND | 1,723 ft | 1 | 3,195 ft |
| 91N | Turtle Lake Muni | TURTLE LAKE, ND | 1,916 ft | 1 | 3,148 ft |
| 6U6 | Hogeland | HOGELAND, MT | 3,139 ft | 2 | 3,140 ft |
| 7G2 | Mc Clusky Muni | MC CLUSKY, ND | 1,900 ft | 1 | 3,136 ft |
| 7S2 | Winnett | WINNETT, MT | 2,989 ft | 1 | 3,130 ft |
| 6U7 | Hysham | HYSHAM, MT | 2,624 ft | 1 | 3,060 ft |
| 3Y7 | Isabel Muni | ISABEL, SD | 2,398 ft | 1 | 3,009 ft |
| 5U6 | Fairview | FAIRVIEW, MT | 2,152 ft | 1 | 3,000 ft |
| M42 | Russian Flat | RUSSIAN FLAT, MT | 6,336 ft | 1 | 3,000 ft |
| D64 | Westhope Muni | WESTHOPE, ND | 1,492 ft | 1 | 3,000 ft |
| L51 | Heller Farm | WINIFRED, MT | 2,304 ft | 1 | 2,998 ft |
| 5B4 | Bowbells Muni | BOWBELLS, ND | 1,955 ft | 1 | 2,900 ft |
| 5U8 | Geraldine | GERALDINE, MT | 3,185 ft | 1 | 2,900 ft |
| Y71 | Elgin Muni | ELGIN, ND | 2,355 ft | 1 | 2,842 ft |
| D61 | Towner Muni | TOWNER, ND | 1,484 ft | 3 | 2,810 ft |
| 7U8 | Richey | RICHEY, MT | 2,494 ft | 1 | 2,690 ft |
| S00 | Opheim | OPHEIM, MT | 3,264 ft | 3 | 2,675 ft |
| D49 | Columbus Muni | COLUMBUS, ND | 1,931 ft | 1 | 2,560 ft |
| 5U0 | Denton | DENTON, MT | 3,594 ft | 1 | 2,550 ft |
| 8U1 | Sand Springs Strip | SAND SPRINGS, MT | 3,180 ft | 1 | 2,400 ft |
| 1M6 | Stevens Ranch | ASHLAND, MT | 3,300 ft | 2 | 2,268 ft |
| CW0 | Cow Creek | WINIFRED, MT | 3,300 ft | 1 | 2,200 ft |
| 6U5 | Hinsdale | HINSDALE, MT | 2,220 ft | 3 | 2,200 ft |
| MT3 | Knox Ridge | WINIFRED, MT | 2,950 ft | 1 | 2,100 ft |
| BB0 | Black Butte North | WINIFRED, MT | 3,150 ft | 1 | 1,800 ft |
| LC0 | Left Coulee | WINIFRED, MT | 3,150 ft | 1 | 1,600 ft |
| BW8 | Bullwhacker | WINIFRED, MT | 3,100 ft | 1 | 1,500 ft |
| WH0 | Woodhawk | WINIFRED, MT | 3,100 ft | 1 | 1,200 ft |
118 public-use airports within this chart's coverage, ordered by runway length. A further 147 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Montana is available as a single 58.9 MB archive (205 charts) — see the Montana airports.
It spans 44.3°N to 49.1°N and 110.6°W to 100.3°W. Airports on the sheet fall within Montana, North Dakota, South Dakota and Wyoming. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (50.5 MB). Take the PDF to print it or read it on a second screen (104.6 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Twin Cities to the east, Great Falls to the west, Cheyenne to the south, Omaha to the south-east and Salt Lake City to the south-west. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
