| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 74.0 MB | Download |
| Print-ready chart, no georeferencing | 153.2 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 153.2 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROSouthern and central Wyoming form the core of this sheet, with coverage stretching west into eastern Utah and east across the Nebraska Panhandle to central South Dakota and Nebraska. Its southern margin takes in northern Colorado and a narrow part of northern Kansas. The landscape changes markedly across the chart: rugged Rocky Mountain terrain and broad intermontane basins give way to rolling plains, while the Black Hills provide a distinct upland area in the north-east.
Routes continuing west pass onto the Salt Lake City chart, while Omaha carries coverage east across the Plains. Billings adjoins to the north and Denver to the south-west, with Wichita covering the south-east continuation. At the corners, Great Falls lies north-west and Twin Cities north-east. These joins make the Cheyenne sheet particularly useful for routes crossing Wyoming or transitioning between the central Rockies and the open country of Nebraska and South Dakota.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| KDEN DEN | Denver Intl | DENVER, CO | 5,433 ft | 6 | 16,000 ft |
| KCPR CPR | Casper/Natrona County Intl | CASPER, WY | 5,344 ft | 2 | 10,165 ft |
| KRKS RKS | Southwest Wyoming Rgnl | ROCK SPRINGS, WY | 6,764 ft | 2 | 10,002 ft |
| KGXY GXY | Greeley-Weld County | GREELEY, CO | 4,696 ft | 4 | 10,000 ft |
| KHDN HDN | Yampa Valley | HAYDEN, CO | 6,606 ft | 1 | 10,000 ft |
| KCYS CYS | Cheyenne Rgnl/Jerry Olson Fld | CHEYENNE, WY | 6,159 ft | 2 | 9,270 ft |
| KAIA AIA | Alliance Muni | ALLIANCE, NE | 3,930 ft | 3 | 9,203 ft |
| KBJC BJC | Rocky Mountain Metro | DENVER, CO | 5,673 ft | 3 | 9,000 ft |
| KPNA PNA | Ralph Wenz Fld | PINEDALE, WY | 7,096 ft | 1 | 8,900 ft |
| KSAA SAA | Shively Fld | SARATOGA, WY | 7,014 ft | 1 | 8,801 ft |
| KRAP RAP | Rapid City Rgnl | RAPID CITY, SD | 3,203 ft | 2 | 8,701 ft |
| KLAR LAR | Laramie Rgnl | LARAMIE, WY | 7,283 ft | 2 | 8,503 ft |
| KFNL FNL | Northern Colorado Rgnl | FORT COLLINS/LOVELAND, CO | 5,020 ft | 2 | 8,500 ft |
| KBFF BFF | Scottsbluff/Western Nebraska Rgnl/Wm B Heilig Fld | SCOTTSBLUFF, NE | 3,967 ft | 2 | 8,279 ft |
| KCOD COD | Yellowstone Rgnl | CODY, WY | 5,102 ft | 1 | 8,268 ft |
| KRIW RIW | Central Wyoming Rgnl | RIVERTON, WY | 5,516 ft | 2 | 8,204 ft |
| KLBF LBF | North Platte Rgnl/Lee Bird Fld | NORTH PLATTE, NE | 2,777 ft | 2 | 8,001 ft |
| KGCC GCC | Northeast Wyoming Rgnl | GILLETTE, WY | 4,365 ft | 2 | 7,501 ft |
| KRWL RWL | Rawlins Muni/Harvey Fld | RAWLINS, WY | 6,816 ft | 2 | 7,008 ft |
| KGEY GEY | South Big Horn County | GREYBULL, WY | 3,941 ft | 2 | 7,003 ft |
| KAKO AKO | Colorado Plains Rgnl | AKRON, CO | 4,716 ft | 1 | 7,001 ft |
| KDWX DWX | Dixon | DIXON, WY | 6,548 ft | 1 | 7,000 ft |
| KVEL VEL | Vernal Rgnl | VERNAL, UT | 5,274 ft | 1 | 7,000 ft |
| KWRL WRL | Worland Muni | WORLAND, WY | 4,251 ft | 3 | 7,000 ft |
| KBPI BPI | Miley Meml Fld | BIG PINEY, WY | 6,993 ft | 2 | 6,803 ft |
| KDUB DUB | Dubois Muni | DUBOIS, WY | 7,298 ft | 1 | 6,700 ft |
| KSNY SNY | Sidney Muni/Lloyd W Carr Fld | SIDNEY, NE | 4,314 ft | 2 | 6,600 ft |
| KDGW DGW | Converse County | DOUGLAS, WY | 4,932 ft | 2 | 6,534 ft |
| KEEO EEO | Meeker Coulter Fld | MEEKER, CO | 6,415 ft | 1 | 6,503 ft |
| 74V | Roosevelt Muni | ROOSEVELT, UT | 5,176 ft | 1 | 6,501 ft |
| 4V0 | Rangely | RANGELY, CO | 5,278 ft | 1 | 6,409 ft |
| KSPF SPF | Black Hills-Clyde Ice Fld | SPEARFISH, SD | 3,933 ft | 3 | 6,401 ft |
| KHSG HSG | Hot Springs County | THERMOPOLIS, WY | 4,891 ft | 1 | 6,370 ft |
| KIBM IBM | Kimball Muni/Robert E Arraj Fld | KIMBALL, NE | 4,925 ft | 1 | 6,199 ft |
| KBYG BYG | Johnson County | BUFFALO, WY | 4,970 ft | 1 | 6,143 ft |
| 33U | Dutch John | DUTCH JOHN, UT | 6,561 ft | 2 | 6,000 ft |
| KCDR CDR | Chadron Muni | CHADRON, NE | 3,297 ft | 2 | 5,998 ft |
| KEAN EAN | Phifer Airfield | WHEATLAND, WY | 4,779 ft | 1 | 5,900 ft |
| 33V | Walden-Jackson County | WALDEN, CO | 8,153 ft | 2 | 5,900 ft |
| KFMM FMM | Fort Morgan Muni | FORT MORGAN, CO | 4,595 ft | 3 | 5,731 ft |
| KTOR TOR | Torrington Muni | TORRINGTON, WY | 4,206 ft | 2 | 5,703 ft |
| 48U | Gtr Green River Intergalactic Spaceport | GREEN RIVER, WY | 7,182 ft | 1 | 5,652 ft |
| KCAG CAG | Craig-Moffat | CRAIG, CO | 6,197 ft | 1 | 5,606 ft |
| 20V | Mc Elroy Airfield | KREMMLING, CO | 7,415 ft | 1 | 5,540 ft |
| KCUT CUT | Custer County | CUSTER, SD | 5,619 ft | 1 | 5,500 ft |
| KRYA RYA | Wray Muni | WRAY, CO | 3,677 ft | 1 | 5,399 ft |
| 82V | Pine Bluffs Muni | PINE BLUFFS, WY | 5,152 ft | 1 | 5,330 ft |
| KECS ECS | Mondell Fld | NEWCASTLE, WY | 4,177 ft | 1 | 5,310 ft |
| 40U | Manila | MANILA, UT | 6,178 ft | 1 | 5,305 ft |
| KSTK STK | Sterling Muni | STERLING, CO | 4,037 ft | 2 | 5,201 ft |
| KGRN GRN | Gordon Muni | GORDON, NE | 3,562 ft | 2 | 5,196 ft |
| KOGA OGA | Searle Fld | OGALLALA, NE | 3,279 ft | 2 | 5,102 ft |
| 49B | Sturgis Muni | STURGIS, SD | 3,254 ft | 2 | 5,100 ft |
| KGUR GUR | Camp Guernsey | GUERNSEY, WY | 4,401 ft | 4 | 5,060 ft |
| KLSK LSK | Lusk Muni | LUSK, WY | 4,966 ft | 1 | 5,058 ft |
| KIML IML | Imperial Muni | IMPERIAL, NE | 3,276 ft | 2 | 5,022 ft |
| KGNB GNB | Granby-Grand County | GRANBY, CO | 8,207 ft | 1 | 5,001 ft |
| KADT ADT | Atwood/Rawlins County | ATWOOD, KS | 2,990 ft | 2 | 5,000 ft |
| KHEQ HEQ | Holyoke | HOLYOKE, CO | 3,729 ft | 1 | 5,000 ft |
| KLND LND | Hunt Fld | LANDER, WY | 5,588 ft | 1 | 5,000 ft |
| KIEN IEN | Pine Ridge | PINE RIDGE, SD | 3,332 ft | 1 | 5,000 ft |
| KSUO SUO | Rosebud Sioux Tribal | ROSEBUD, SD | 2,724 ft | 1 | 4,801 ft |
| KLMO LMO | Vance Brand | LONGMONT, CO | 5,055 ft | 1 | 4,799 ft |
| KGGF GGF | Grant Muni | GRANT, NE | 3,424 ft | 1 | 4,797 ft |
| KEIK EIK | Erie Muni | ERIE, CO | 5,119 ft | 1 | 4,700 ft |
| KOKS OKS | Garden County/King Rhiley Fld | OSHKOSH, NE | 3,394 ft | 1 | 4,699 ft |
| 49U | Shoshoni Muni | SHOSHONI, WY | 4,818 ft | 2 | 4,650 ft |
| KHSR HSR | Hot Springs Muni | HOT SPRINGS, SD | 3,150 ft | 2 | 4,506 ft |
| KSBS SBS | Steamboat Springs/Bob Adams Fld | STEAMBOAT SPRINGS, CO | 6,882 ft | 1 | 4,452 ft |
| 6V4 | Wall Muni | WALL, SD | 2,813 ft | 2 | 4,419 ft |
| 76V | Thomas Meml | GLENDO, WY | 4,666 ft | 1 | 4,397 ft |
| 7V5 | Brush Muni | BRUSH, CO | 4,280 ft | 1 | 4,300 ft |
| 2V6 | Yuma Muni | YUMA, CO | 4,137 ft | 2 | 4,201 ft |
| KBDU BDU | Boulder Muni | BOULDER, CO | 5,288 ft | 2 | 4,100 ft |
| 7V8 | Julesburg Muni | JULESBURG, CO | 3,495 ft | 1 | 4,100 ft |
| 18V | Platte Valley Airpark | HUDSON, CO | 4,965 ft | 2 | 4,100 ft |
| KCNP CNP | Billy G Ray Fld | CHAPPELL, NE | 3,681 ft | 1 | 4,000 ft |
| 11V | Easton/Valley View | GREELEY, CO | 4,820 ft | 2 | 4,000 ft |
| 8F6 | Murdo Muni | MURDO, SD | 2,270 ft | 1 | 4,000 ft |
| KPHP PHP | Philip | PHILIP, SD | 2,209 ft | 2 | 3,998 ft |
| 1V2 | Grant County | HYANNIS, NE | 3,737 ft | 1 | 3,975 ft |
| 9V5 | Modisett | RUSHVILLE, NE | 3,751 ft | 1 | 3,909 ft |
| 6V0 | Edgemont Muni | EDGEMONT, SD | 3,593 ft | 2 | 3,900 ft |
| 17V | Haxtun Muni | HAXTUN, CO | 4,035 ft | 2 | 3,860 ft |
| KHAD HAD | Irwins Sky Ranch | CASPER, WY | 5,370 ft | 1 | 3,810 ft |
| 83V | Upton Muni | UPTON, WY | 4,290 ft | 1 | 3,710 ft |
| 9V6 | Martin Muni | MARTIN, SD | 3,294 ft | 1 | 3,699 ft |
| 80V | Medicine Bow | MEDICINE BOW, WY | 6,658 ft | 2 | 3,170 ft |
| 7Q7 | White River Muni | WHITE RIVER, SD | 2,151 ft | 1 | 3,000 ft |
| 64V | Wallace Muni | WALLACE, NE | 3,101 ft | 1 | 2,800 ft |
| 4V6 | Hay Springs Muni | HAY SPRINGS, NE | 3,831 ft | 1 | 2,775 ft |
| 5V8 | Kadoka Muni | KADOKA, SD | 2,466 ft | 2 | 2,600 ft |
| TF9 | Taylor Flat | DUTCH JOHN, UT | 5,638 ft | 1 | 2,500 ft |
93 public-use airports within this chart's coverage, ordered by runway length. A further 161 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Wyoming is available as a single 34.0 MB archive (134 charts) — see the Wyoming airports.
It spans 39.8°N to 44.6°N and 110.2°W to 100.6°W. Airports on the sheet fall within Colorado, Kansas, Nebraska, South Dakota, Utah and Wyoming. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (74.0 MB). Take the PDF to print it or read it on a second screen (153.2 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Omaha to the east, Salt Lake City to the west, Billings to the north, Wichita to the south-east, Denver to the south-west and Great Falls to the north-west. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
