Official FAA digital chart — free GeoTIFF and PDF download
| Format | What you get | Size | |
|---|---|---|---|
| GeoTIFF | Georeferenced raster at 300 dpi, with world file and FGDC metadata | 59.3 MB | Download |
| Print-ready chart, no georeferencing | 121.3 MB | Download |
Not for navigation. For flight simulation and reference use only. Check the effective dates above, and obtain official charts from the FAA for real-world flight.
These are big files. This chart alone is 121.3 MB. Guest downloads are rate limited; PRO members get full-speed, unthrottled downloads across every chart and all 24,000+ add-ons in the library.
Go PROSan Antonio sits near the centre of a sheet stretching from the coastal country around Corpus Christi north towards Waco, and west across the Hill Country to the Pecos region. It brings together several distinct Texas landscapes: low coastal plains and bays, South Texas brush country, the limestone ridges and valleys of the Edwards Plateau, and increasingly dry, open ground towards the western edge.
That range gives the chart a marked east–west contrast. The central corridor around San Antonio and Austin gives way to more broken terrain across the Hill Country, while the far west has the broader spacing and semi-arid character associated with West Texas.
Routes continuing east pass onto the Houston sheet, while El Paso carries the coverage west. Dallas–Ft Worth adjoins to the north and Brownsville to the south. At the corners, Albuquerque provides the north-west continuation and Memphis the north-east, making the San Antonio sheet a central link between Gulf Coast, southern, northern and Trans-Pecos coverage.
| ID | Airport | City | Elev | Rwys | Longest |
|---|---|---|---|---|---|
| KAUS AUS | Austin-Bergstrom Intl | AUSTIN, TX | 541 ft | 5 | 12,250 ft |
| KSKF SKF | Kelly Fld | SAN ANTONIO, TX | 690 ft | 1 | 11,550 ft |
| KGRK GRK | Robert Gray AAF | FORT HOOD (KILLEEN), TX | 1,015 ft | 4 | 9,997 ft |
| KMAF MAF | Midland Intl Air And Space Port | MIDLAND, TX | 2,872 ft | 4 | 9,501 ft |
| KVCT VCT | Victoria Rgnl | VICTORIA, TX | 115 ft | 3 | 9,111 ft |
| KBPG BPG | Big Spring/Mc Mahon-Wrinkle | BIG SPRING, TX | 2,572 ft | 2 | 8,803 ft |
| KCNW CNW | Tstc Waco | WACO, TX | 470 ft | 2 | 8,600 ft |
| KSAT SAT | San Antonio Intl | SAN ANTONIO, TX | 809 ft | 3 | 8,505 ft |
| KSJT SJT | San Angelo Rgnl/Mathis Fld | SAN ANGELO, TX | 1,918 ft | 3 | 8,054 ft |
| TX2 | Chase Fld Industrial | BEEVILLE, TX | 184 ft | 1 | 8,000 ft |
| KCRP CRP | Corpus Christi Intl | CORPUS CHRISTI, TX | 46 ft | 2 | 7,510 ft |
| KFST FST | Fort Stockton-Pecos County | FORT STOCKTON, TX | 3,011 ft | 5 | 7,508 ft |
| KACT ACT | Waco Rgnl | WACO, TX | 516 ft | 2 | 7,107 ft |
| KTPL TPL | Draughon-Miller Central Texas Rgnl | TEMPLE, TX | 682 ft | 2 | 7,000 ft |
| KCLL CLL | Easterwood Fld | COLLEGE STATION, TX | 320 ft | 2 | 7,000 ft |
| KBAZ BAZ | New Braunfels Ntl | NEW BRAUNFELS, TX | 658 ft | 2 | 6,503 ft |
| T89 | Lajitas Intl | LAJITAS, TX | 2,630 ft | 1 | 6,501 ft |
| KHYI HYI | San Marcos Rgnl | AUSTIN, TX | 594 ft | 3 | 6,330 ft |
| KDRT DRT | Del Rio Intl | DEL RIO, TX | 1,002 ft | 3 | 6,300 ft |
| KPEQ PEQ | Pecos Muni | PECOS, TX | 2,613 ft | 2 | 6,236 ft |
| KODO ODO | Odessa-Schlemeyer Fld | ODESSA, TX | 3,003 ft | 3 | 6,200 ft |
| KEDC EDC | Austin Exec | AUSTIN, TX | 620 ft | 2 | 6,025 ft |
| KCOT COT | Cotulla-La Salle County | COTULLA, TX | 474 ft | 1 | 6,005 ft |
| KERV ERV | Kerrville Muni/Louis Schreiner Fld | KERRVILLE, TX | 1,616 ft | 2 | 6,004 ft |
| 11R | Brenham Muni | BRENHAM, TX | 317 ft | 1 | 6,003 ft |
| KOZA OZA | Ozona Muni | OZONA, TX | 2,376 ft | 1 | 6,003 ft |
| E38 | Alpine-Casparis Muni | ALPINE, TX | 4,514 ft | 2 | 6,002 ft |
| KHDO HDO | South Texas Rgnl At Hondo | HONDO, TX | 930 ft | 4 | 6,002 ft |
| KALI ALI | Alice Intl | ALICE, TX | 178 ft | 2 | 5,997 ft |
| KDZB DZB | Horseshoe Bay Resort | HORSESHOE BAY, TX | 1,093 ft | 1 | 5,977 ft |
| 10X | Ox Ranch | UVALDE, TX | 1,305 ft | 1 | 5,744 ft |
| KRKP RKP | Aransas County | ROCKPORT, TX | 23 ft | 2 | 5,608 ft |
| KBWD BWD | Brownwood Rgnl | BROWNWOOD, TX | 1,386 ft | 2 | 5,599 ft |
| KMDD MDD | Midland Airpark | MIDLAND, TX | 2,805 ft | 2 | 5,571 ft |
| 5T9 | Maverick County Meml Intl | EAGLE PASS, TX | 887 ft | 1 | 5,506 ft |
| KPWG PWG | Mc Gregor Exec | WACO, TX | 591 ft | 2 | 5,501 ft |
| KILE ILE | Skylark Fld | KILLEEN, TX | 847 ft | 1 | 5,495 ft |
| KUVA UVA | Garner Fld | UVALDE, TX | 941 ft | 1 | 5,256 ft |
| E41 | Reagan County | BIG LAKE, TX | 2,705 ft | 2 | 5,035 ft |
| T30 | Mc Kinley Fld | PEARSALL, TX | 586 ft | 1 | 5,027 ft |
| KMNZ MNZ | Hamilton Muni | HAMILTON, TX | 1,304 ft | 1 | 5,012 ft |
| 5C1 | Boerne Stage Airfield | SAN ANTONIO, TX | 1,383 ft | 1 | 5,006 ft |
| KCRS CRS | C David Campbell Fld-Corsicana Muni | CORSICANA, TX | 448 ft | 2 | 5,004 ft |
| KPKV PKV | Calhoun County | PORT LAVACA, TX | 32 ft | 2 | 5,004 ft |
| KGTU GTU | Georgetown Exec | GEORGETOWN, TX | 789 ft | 2 | 5,004 ft |
| KJCT JCT | Kimble County | JUNCTION, TX | 1,753 ft | 2 | 5,004 ft |
| KCZT CZT | Dimmit County | CARRIZO SPRINGS, TX | 598 ft | 1 | 5,003 ft |
| KINK INK | Winkler County | WINK, TX | 2,821 ft | 2 | 5,003 ft |
| T82 | Gillespie County | FREDERICKSBURG, TX | 1,694 ft | 1 | 5,002 ft |
| TX0 | Shank N Bank | LA WARD, TX | 29 ft | 1 | 5,002 ft |
| KBMQ BMQ | Burnet Muni/Kate Craddock Fld | BURNET, TX | 1,283 ft | 1 | 5,001 ft |
| KCVB CVB | Castroville Muni | CASTROVILLE, TX | 773 ft | 1 | 5,001 ft |
| 3T5 | Fayette Rgnl Air Center | LA GRANGE, TX | 324 ft | 1 | 5,000 ft |
| KLXY LXY | Mexia-Limestone County | MEXIA, TX | 544 ft | 1 | 5,000 ft |
| 7T7 | Skywest Inc | MIDLAND, TX | 2,805 ft | 2 | 5,000 ft |
| KSSF SSF | Stinson Muni | SAN ANTONIO, TX | 577 ft | 2 | 5,000 ft |
| KTFP TFP | Ingleside Rgnl | INGLESIDE, TX | 17 ft | 1 | 4,999 ft |
| E26 | Lea County/Jal | JAL, NM | 3,118 ft | 2 | 4,704 ft |
| 1E2 | Terlingua Ranch | ALPINE, TX | 3,769 ft | 1 | 4,700 ft |
| KBBD BBD | Curtis Fld | BRADY, TX | 1,827 ft | 2 | 4,605 ft |
| KBEA BEA | Beeville Muni | BEEVILLE, TX | 272 ft | 2 | 4,553 ft |
| 6R6 | Terrell County | DRYDEN, TX | 2,323 ft | 2 | 4,526 ft |
| KCOM COM | Coleman Muni | COLEMAN, TX | 1,696 ft | 1 | 4,506 ft |
| KMKN MKN | Comanche County-City | COMANCHE, TX | 1,386 ft | 1 | 4,497 ft |
| KRFG RFG | Rooke Fld | REFUGIO, TX | 54 ft | 1 | 4,361 ft |
| T69 | Sinton | SINTON, TX | 47 ft | 2 | 4,323 ft |
| 27R | Eldorado | ELDORADO, TX | 2,448 ft | 1 | 4,300 ft |
| E01 | Roy Hurd Meml | MONAHANS, TX | 2,614 ft | 2 | 4,268 ft |
| E13 | Crane County | CRANE, TX | 2,554 ft | 2 | 4,258 ft |
| 63F | Stanton Muni | STANTON, TX | 2,731 ft | 1 | 4,240 ft |
| KSEP SEP | Stephenville Clark Rgnl | STEPHENVILLE, TX | 1,321 ft | 1 | 4,209 ft |
| 81R | San Saba County Muni | SAN SABA, TX | 1,255 ft | 1 | 4,206 ft |
| KLZZ LZZ | Lampasas | LAMPASAS, TX | 1,214 ft | 1 | 4,202 ft |
| KAQO AQO | Llano Muni | LLANO, TX | 1,101 ft | 2 | 4,202 ft |
| 88R | Spicewood | SPICEWOOD, TX | 830 ft | 1 | 4,185 ft |
| T50 | Menard County | MENARD, TX | 1,933 ft | 1 | 4,100 ft |
| E48 | Upton County | MC CAMEY, TX | 2,433 ft | 1 | 4,100 ft |
| 2F0 | Iraan Muni | IRAAN, TX | 2,200 ft | 2 | 4,085 ft |
| KECU ECU | Edwards County | ROCKSPRINGS, TX | 2,372 ft | 1 | 4,050 ft |
| KSOA SOA | Sonora Muni | SONORA, TX | 2,139 ft | 1 | 4,037 ft |
| KLHB LHB | Hearne Muni | HEARNE, TX | 284 ft | 1 | 4,001 ft |
| 50R | Lockhart Muni | LOCKHART, TX | 531 ft | 1 | 4,001 ft |
| KGYB GYB | Giddings-Lee County | GIDDINGS, TX | 484 ft | 1 | 4,000 ft |
| KPEZ PEZ | Pleasanton Muni | PLEASANTON, TX | 430 ft | 1 | 4,000 ft |
| 84R | Smithville Crawford Muni | SMITHVILLE, TX | 323 ft | 1 | 4,000 ft |
| T74 | Taylor Muni | TAYLOR, TX | 600 ft | 1 | 4,000 ft |
| KINJ INJ | Hillsboro Muni | HILLSBORO, TX | 685 ft | 1 | 3,998 ft |
| 49R | Real County | LEAKEY, TX | 1,640 ft | 1 | 3,975 ft |
| 3R9 | Lakeway Airpark | LAKEWAY, TX | 909 ft | 1 | 3,930 ft |
| E30 | Bruce Fld | BALLINGER, TX | 1,738 ft | 1 | 3,909 ft |
| KRYW RYW | Lago Vista Tx/Rusty Allen | LAGO VISTA, TX | 1,230 ft | 1 | 3,808 ft |
| 66R | Robert R Wells Jr | COLUMBUS, TX | 242 ft | 1 | 3,800 ft |
| 8T6 | Live Oak County | GEORGE WEST, TX | 128 ft | 1 | 3,799 ft |
| T92 | Mason County | MASON, TX | 1,514 ft | 1 | 3,716 ft |
| KRBO RBO | Nueces County | ROBSTOWN, TX | 79 ft | 1 | 3,700 ft |
| 20R | Crystal City Muni | CRYSTAL CITY, TX | 608 ft | 1 | 3,550 ft |
| 2TX | Salado | SALADO, TX | 689 ft | 1 | 3,494 ft |
| KRAS RAS | Mustang Beach | PORT ARANSAS, TX | 5 ft | 1 | 3,482 ft |
| T85 | Yoakum Muni | YOAKUM, TX | 365 ft | 1 | 3,444 ft |
| E70 | Huber Airpark Civic Club Llc | SEGUIN, TX | 556 ft | 1 | 3,415 ft |
| 24R | Dilley Airpark | DILLEY, TX | 542 ft | 1 | 3,400 ft |
| KGOP GOP | Gatesville Muni | GATESVILLE, TX | 905 ft | 1 | 3,400 ft |
| 23R | Devine Muni | DEVINE, TX | 702 ft | 1 | 3,399 ft |
| 26R | Jackson County | EDNA, TX | 61 ft | 1 | 3,393 ft |
| KRWV RWV | Caldwell Muni | CALDWELL, TX | 390 ft | 1 | 3,252 ft |
| 2R9 | Kenedy Rgnl | KENEDY, TX | 288 ft | 1 | 3,218 ft |
| 34R | Hallettsville Muni | HALLETTSVILLE, TX | 277 ft | 1 | 3,210 ft |
| 77F | Winters Muni | WINTERS, TX | 1,871 ft | 1 | 3,204 ft |
| 07R | Bishop-Windham | BISHOP, TX | 55 ft | 1 | 3,200 ft |
| T35 | Cameron Muni Airpark | CAMERON, TX | 402 ft | 1 | 3,200 ft |
| 9F0 | Dublin Muni | DUBLIN, TX | 1,495 ft | 1 | 3,200 ft |
| T19 | Duval-Freer | FREER, TX | 564 ft | 1 | 3,200 ft |
| T37 | Goldthwaite Muni | GOLDTHWAITE, TX | 1,457 ft | 1 | 3,200 ft |
| T20 | Roger M Dreyer Meml | GONZALES, TX | 354 ft | 1 | 3,200 ft |
| 67T | Old Hoppe Place | AGUA DULCE, TX | 96 ft | 1 | 3,164 ft |
| 9F1 | Valley Mills Muni | VALLEY MILLS, TX | 751 ft | 2 | 3,028 ft |
| T15 | Marlin | MARLIN, TX | 410 ft | 1 | 3,021 ft |
| 7F7 | Clifton Muni/Isenhower Fld | CLIFTON, TX | 760 ft | 1 | 3,000 ft |
| 1T7 | Kestrel Airpark | SAN ANTONIO, TX | 1,261 ft | 1 | 3,000 ft |
| 49F | Rankin | RANKIN, TX | 2,543 ft | 1 | 3,000 ft |
| 8T8 | San Geronimo Airpark | SAN ANTONIO, TX | 1,040 ft | 1 | 3,000 ft |
| 73F | Wings For Christ Intl Flt Academy | WACO, TX | 455 ft | 1 | 3,000 ft |
| T26 | Flying V Ranch | LOUISE, TX | 60 ft | 1 | 2,990 ft |
| KRCK RCK | H H Coffield Rgnl | ROCKDALE, TX | 474 ft | 1 | 2,962 ft |
| T71 | Cuero Muni | CUERO, TX | 214 ft | 1 | 2,800 ft |
| 53T | Cannon Fld | SOMERSET, TX | 610 ft | 1 | 2,790 ft |
| 1T8 | Bulverde Airpark | SAN ANTONIO, TX | 1,088 ft | 1 | 2,783 ft |
| 2KL | Sunrise Beach | SUNRISE BEACH VILLAGE, TX | 854 ft | 1 | 2,649 ft |
| 3T8 | Wildcat Canyon | CHINA SPRING, TX | 660 ft | 1 | 2,450 ft |
| 11T | Rocking L | SONORA, TX | 2,339 ft | 1 | 2,432 ft |
| 74R | Horizon | SAN ANTONIO, TX | 551 ft | 2 | 2,360 ft |
| 9R5 | Hunt | PORTLAND, TX | 38 ft | 2 | 2,350 ft |
| T94 | Twin-Oaks | SAN ANTONIO, TX | 873 ft | 1 | 2,225 ft |
| 2G5 | Granite Shoals/ Bob Sylvester Airpark | GRANITE SHOALS, TX | 860 ft | 1 | 2,000 ft |
134 public-use airports within this chart's coverage, ordered by runway length. A further 539 private and restricted landing facilities are not listed. Source: FAA NASR 28-day subscription.
Approach plates and airport diagrams for every airport in the states this sheet covers:
Flying the area on this sheet? Every approach plate and airport diagram for Texas is available as a single 393.0 MB archive (2,019 charts) — see the Texas airports.
It spans 27.6°N to 32.3°N and 103.9°W to 96.3°W. Airports on the sheet fall within New Mexico and Texas. The full list of public-use airports within its coverage is on this page.
Take the GeoTIFF if you are loading the chart into moving-map software or a flight planner — it is georeferenced, so the software can place it correctly on a map, and it ships with a world file and FGDC metadata at 300 dpi (59.3 MB). Take the PDF to print it or read it on a second screen (121.3 MB); it is the same chart without georeferencing.
This is the FAA edition effective 9 July 2026, which is superseded on 3 September 2026. Visual charts are reissued every 56 days and we publish each new edition on the day it takes effect. It is for flight simulation and reference only — not for real-world navigation.
Houston to the east, El Paso to the west, Brownsville to the south, Dallas-Ft Worth to the north, Albuquerque to the north-west and Memphis to the north-east. Each is linked from this page, so a route running off one edge can be continued on the next sheet.
Yes, with no account required. FAA charts are United States Government works and are not subject to copyright protection in the US under 17 U.S.C. § 105. Guest downloads are speed-capped, so a sheet this size takes a while; PRO members download at full line speed and can take the whole family as one archive.
